08020SA (80
NMBTC.COM / 248.919.2250
X
20
L
)
General Specifications
Motor Protection:
Auto Restart/Polarity Protection
Characteristic Curves
In H
2
O
.24
.20
Static Pressure
.16
.12
.08
.04
0
60
50
M
(Pa)
P-Q Curve
Speed Curve
Insulation Resistance:
4800
4000
10M Ω or over with a DC500V Megger
-10°C ~ +70°C (Operating)
-40°C ~ +70°C (Storage)
(non-condensing environment)
K
30
20
L
K
M
J
2400
1600
800
0
Ps
Expected Life
Failure Rate: 10%
60°C
40,000 Hours (AA/EA)
10
0
J
0
0.20
0.40
0.60
0.80
1.00
1.20
(m
3
/min)
CFM
0
7.06
14.12
21.18
28.24
35.3
42.36
Material
Casing : Plastic (Black) UL94V-0
Impeller : Plastic (Black) UL94V-0
Bearing : Ball Bearing
Lead Wire : UL3385, AWG26, +Red, -Black
Air Flow
Outline
Panel Cut-Outs
inch
Units: (mm)
.169
(4 –
φ4.3)
.169
(4 –
φ4.3)
11.82
min (300)
A
ROTATION
0.169
(4−φ4.3
± 0.2
)
B
3.15
(80.0
± 0.5
)
2.81
(71.5
± 0.3
)
2.81
(71.5)
2.99
(76.0)
2.81
(71.5)
2.99
(76.0)
22 )
3. 1.8
8
(
φ
22 )
3. 1.8
8
(
φ
NAME
PLATE
2.81
(71.5)
2.99
(76.0)
INLET SIDE
2.81
(71.5)
2.99
(76.0)
OUTLET SIDE
B
2.81
(71.5
± 0.3
)
3.15
(80.0
± 0.5
)
A
0.15
(4.0
± 0.3
)
0.78
(20.0
± 0.3
)
Specifications
Rated
Operating
Voltage
Current
(A)
*1
0.05
0.07
0.09
0.13
0.05
0.06
0.07
0.09
Input
Power
Speed
Max.
Air Flow
Max. Static
Pressure
Noise
(dB)
*1
27.0
31.0
34.0
37.5
27.0
31.0
34.0
37.5
Mass
(g)
80
80
80
80
80
80
80
80
MODEL
Voltage
(V)
08020SA-12J-AA-00
08020SA-12K-AA-00
08020SA-12L-AA-00
08020SA-12M-AA-00
08020SA-24J-AA-00
08020SA-24K-AA-00
08020SA-24L-AA-00
08020SA-24M-AA-00
Rotation: Clockwise
(V)
6.0 ~ 13.8
6.0 ~ 13.8
6.0 ~ 13.8
6.0 ~ 13.2
9.0 ~ 27.6
9.0 ~ 27.6
9.0 ~ 27.6
9.0 ~ 27.6
(W)
*1
0.60
0.84
1.08
1.56
1.20
1.44
1.68
2.16
(min
-1
)
*1
CFM
*1
(m
3
/min)
*1
in H
2
O
2600
2900
3300
3700
2600
2900
3300
3700
27.5
31.1
36.0
39.9
27.5
31.1
36.0
39.9
0.78
0.88
1.02
1.13
0.78
0.88
1.02
1.13
0.11
0.14
0.17
0.21
0.09
0.11
0.14
0.18
(Pa)
*1
28.3
34.9
43.6
52.8
23.5
28.5
35.0
44.0
12
12
12
12
24
24
24
24
Airflow Outlet: Air Out Over Struts
*1: Average Values in Free Air
Note: PWM/Locked Rotor/Tach Available
Speed
Dielectric Withstand Voltage:
AC 700V 1s
Allowable Ambient Temperature Range:
DC Axial Fans
