High-current terminal block - PTPOWER 95-3L/N-F - 3260124
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
High-current terminal block, Blocked, Connection method: Push-in connection, Number of positions: 4, Cross
section: 25 mm² - 95 mm², AWG: 4 - 3/0, Width: 100 mm, Height: 99.8 mm, Color: gray/blue, Mounting type: ct
screw connection
The figure shows a version of the
article
Product Features
Quick and easy connection is now also possible for large conductors with the high-current terminal block
The Push-in connection terminal blocks are characterized by the system features of the CLIPLINE complete system and by easy and tool-free wiring
of conductors with ferrules or solid conductors
The compact design enables wiring in a confined space
In addition to using the existing test connection, pick-off terminal blocks can be connected, each of which can also accommodate two test cables
Key commercial data
Packing unit
Minimum order quantity
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 pc
2 pc
830.0 GRM
85369010
Poland
Technical data
General
Number of levels
Number of connections
Color
Insulating material
Inflammability class according to UL 94
Maximum load current
Rated surge voltage
1
2
gray/blue
PA
V0
232 A (with 95 mm conductor cross section)
8 kV
02/09/2015 Page 1 / 4
2
https://www.phoenixcontact.com/us/products/3260124
High-current terminal block - PTPOWER 95-3L/N-F - 3260124
Technical data
General
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Maximum load current
Nominal current I
N
Nominal voltage U
N
Maximum load current
Open side panel
Number of positions
3
III
I
IEC 60947-7-1
232 A (with 95 mm conductor cross section)
232 A
1500 V
232 A (with 95 mm conductor cross section)
nein
4
2
2
Dimensions
Width
Length
Height
Hole diameter
Drill hole spacing
100 mm
139.1 mm
99.8 mm
8 mm
126.40 mm
Connection data
Connection in acc. with standard
Connection method
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded min.
Conductor cross section stranded max.
Min. AWG conductor cross section, stranded
Max. AWG conductor cross section, stranded
Conductor cross section stranded, with ferrule without plastic sleeve min.
Conductor cross section stranded, with ferrule without plastic sleeve max.
Conductor cross section stranded, with ferrule with plastic sleeve min.
Conductor cross section stranded, with ferrule with plastic sleeve max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
IEC 60947-7-1
Push-in connection
25 mm²
95 mm²
4
3/0
25 mm²
95 mm²
4
4/0
25 mm²
95 mm²
25 mm²
95 mm²
95 mm²
70 mm²
95 mm²
70 mm²
02/09/2015 Page 2 / 4
https://www.phoenixcontact.com/us/products/3260124
High-current terminal block - PTPOWER 95-3L/N-F - 3260124
Technical data
Connection data
Stripping length
40 mm
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
27141120
27141120
27141120
27141120
27141120
27141120
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000897
EC000897
EC000897
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39121410
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approvals submitted
02/09/2015 Page 3 / 4
https://www.phoenixcontact.com/us/products/3260124
High-current terminal block - PTPOWER 95-3L/N-F - 3260124
Approvals
Approval details
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
4-4/0
230 A
1000 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
C
4-4/0
230 A
1000 V
EAC
cULus Recognized
Drawings
Circuit diagram
Dimensioned drawing
6,5
75
