48-Lane 12-Port PCIe
®
Gen3
System Interconnect Switch
x8/x4/x2/x1
SerDes
DL/Transaction Layer
Route Table
Frame Buffer
DL/Transaction Layer
SerDes
x8/x4/x2/x1
x8/x4/x2/x1
SerDes
DL/Transaction Layer
x8/x4/x2/x1
SerDes
DL/Transaction Layer
Port Arbitration
Scheduler
DL/Transaction Layer
SerDes
x8/x4/x2/x1
POWER MANAGEMENT | ANALOG & RF |
INTERFACE & CONNECTIVITY
| CLOCKS & TIMING | MEMORY & LOGIC | TOUCH & USER INTERFACE | VIDEO & DISPLAY | AUDIO
FEATURES
• High
Performance Non-Blocking
Switch Architecture
– 48-lane 12-port PCIe switch
– Integrated SerDes supports 8.0 GT/s Gen3, 5.0
GT/s Gen2 and 2.5 GT/s Gen1 operation
– Delivers up to 96 GBps (768 Gbps) of
switching capacity
– Low latency cut-through architecture
– Multicast compliant to Spec
– Supports up to 2 KB maximum payload size
– Request metering for maximum system throughput
• Standards
and Compatibility
– PCI Express Base Specification 3.0 compliant
– Implements the following optional
PCI Express features:
- Advanced Error Reporting (AER) on all ports
- Access Control Services (ACS)
- Alternative Routing ID (ARI) ECN
- Internal Error Reporting (IER) ECN
- Atomic operations ECN
- TLP processing hints (TPH) ECN
- Latency Tolerance Reporting (LTR) ECN
- Optimized Buffer Flush/Fill (OBFF) ECN
– PCI Power Management Spec
- Supports D0, D3hot and D3 power
management states
– Active State Power Management (ASPM)
• Switch
Initialization /Configurability
– Supports x8, x4, x2 and x1 ports
– Automatic per port link width negotiation
– Automatic lane reversal
– Autonomous and software managed link width
and speed control
– Per lane SerDes configuration
– Supports Global and Local reference port clock input
– Crosslink support
– 9 General Purpose I/O
– Supports Root (BIOS, OS, or driver), Serial EEPROM,
pin strapping, or SMBus switch initialization
– No power sequencing requirements
• Multi-Root
Support
– Supports up to 12 fully independent switch partitions
– Configurable downstream port device numbering
– Supports dynamic reconfiguration of switch partitions
– Movable upstream port within and between
switch partitions
• Reliability,
Availability and Serviceability (RAS)
– ECRC support
– AER on all ports
– SECDED ECC protection on all internal RAMs
– End-to-end data path parity protection
– Ability to generate an interrupt (INTx or MSI) on
link up/down transitions
– Hot-plug supported on all downstream switch ports
– On-chip link activity and status outputs available
including the upstream ports
– Supports IEEE 1149.6 AC JTAG and IEEE 1149.1 JTAG
• Development
Tools
– 89KTPES48H12G3 Evaluation Board
– PCIe Browser Software
– Provides ODS (On-Die Scope)
– Built-in PRBS generator and checker
– Documentation and support at:
www.IDT.com
• Packaged
in a 27mm x 27mm 676-ball FCBGA
12-Port Switch Core
DL/Transaction Layer
SerDes
x8/x4/x2/x1
48 PCI Express Lanes - Up to 6 x8 ports or 12 x4 ports
Device Overview
The 89H48H12G3 is a 48-lane, 12-port system interconnect switch optimized for PCI Express
®
Gen3 packet
switching in high-performance applications, supporting multiple simultaneous peer-to-peer traffic flows. Target
applications include servers, storage, communications, embedded systems, and multi-host or intelligent I/O
based systems with inter-domain communication.
Utilizing standard PCI Express Gen3 interconnect, the 89H48H12G3 provides the most efficient system
interconnect switching solution for applications requiring high throughput, low latency, and simple board layout
with a minimum number of board layers. It provides 96 GBps (768 Gbps) of aggregated, full-duplex switching
capacity through 48 integrated serial lanes, using proven and robust IDT technology. Each lane is capable of 8
GT/s of bandwidth in both directions and is fully compliant with PCI Express Base specification 3.0.
Memory
CPU 0
CPU 1
Memory
Storage IO
Gen 3
PCIe Switch
PCIe
Slot
PCIe
Slot
PCIe
Slot
®
Network IO
Network IO
Partition 0
PCIe
Slot
Partition 1
Enterprise Server
SSD-1
SSD-2
SSD-3
SSD-14
Gen 3
PCIe Switch
®
Gen 3
PCIe Retimer
IO Module
®
Cable
to
RC
SSD Storage
SSD Storage Array
