Sockets for RMI Relays
ZMI 2NA – ZMI 4NA
mm/inches
TOP VIEW
3.2/0.13”
A1 13
11
21
9
PLATE
5
14
72/2.83”
1
12
22.5/0.88”
6
NO
7
8
24
NC
34
44
4
42
A2 14
41
3
32
COM
31
11
12
9/0.35”
75/2.95”
mm/inches
LATERAL VIEW
ZMI 4NA
40/1.57”
75/2.95”
General data
Socket Material
Socket colour
Contact Material
Contact surface
Terminals
Terminal type
Screws
Screw type
PA66 +GF – V2
RAL 7035 / Pantone 1C
Cu Ni
5µm tin plated
8µm zinc plated steel
Screw cage
5µm nickel plated 8.8 steel
M3 with combi head
(slotted, Philips Gr.1, Pozi)
Ratings
UL Rating
Operating temp.
Insulation voltage
Creepage and Clearance
Maximum Screw torque
Max Wire section
Flex / compact wire
Cable End
Terminal Protection degree
10A 300VAC
10A x 2 or 5A x 4 @ 300VAC
-25° to +70°C (-13° to +158°F)
>4kV
Gr.C250, VDE 0110b / 2.79
1.0N/m
2 x 2.5mm
2
(14AWG)
2 x 1.5mm
2
(16AWG)
IP 20 (EN60529)
Approvals
R
I
N
E73404
8
6
Ordering
Ordering
Ordering
Ordering
code
code
code
code
2
4
2
4
contacts
contacts
contacts
contacts
version
version
version
version
for
for
for
for
RMI
RMI
RMI
RMI
A
A
A
A
2
4
2
4
10 xxx with Plastic hold down spring :
5 xxx with Plastic hold down spring :
10 xxx with Metal hold down spring :
5 xxx with Metal hold down spring :
ZMI2NA / ZMI4NA
ZMI4NA
ZMI2NA-M / ZMI4NA-M
ZMI4NA-M
Box content: 10 sockets, 10 labels, 10 Plastic hold down springs
Box size: (W 155 x D 165 x H 70) mm
Weight: 750g
(W 6.10 x D 6.50 x H 2.75) inches Weight: 26.45oz
Optional Accessories (to be ordered separately if required)
Metal spare hold down Spring SZMI36M
Plastic spare hold down Spring SZMI35
Plastic spare hold down Spring 6.73.00.61.4
Labels
Bridging bar
Modules
6.73.00.61.3
ZMI-BB
1
27/1.06”
2
22
10
A
Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network
1
1
Optional Springs for ZMI series
SZMI 36M
General data
23/0.90”
5/0.20”
Spring material
Stainless steel
Packaging
Box content:
Weight:
38/1.50”
1 plastic bag, 10pcs.
~5g (0.18oz)
3.8/0.15”
10°
53°
10/0.39”
SZMI 36M
mm/inches
SZMI 35
General data
Spring material
Spring colour
Packaging
Box content:
Weight:
59/2.32”
PA66 + GF (V0)
RAL 7035 / Pantone 1C
1 plastic bag, 10pcs.
~20g (0.70oz)
23/0.91”
25/0.98”
mm/inches
SZMI 35
6.73.00.61.4
General data
Spring material
Spring colour
Packaging
Box content:
Weight:
59/2.32”
PA6 + GF (V2)
RAL 7035 / Pantone 1C
1 plastic bag, 10pcs.
~20g (0.70oz)
23/0.91”
25/0.98”
mm/inches
6.73.00.61.4
2
Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.
Optional sockets bridging bars
ZMI-BB
General data
Plastic insulator material
Plastic insulator colour
Metal jumper
PA66 + GF (V0)
Black
Tinned copper
Packaging
Box content:
Weight:
1 plastic bag, 10pcs.
~50g (~1.76oz)
ZMI-BB
mm/inches
Optional Function Modules
Modules for ZMI and ZD sockets
mm/inches
DIMENSIONS
13/0.51”
3/0.12”
MODULE 12
6/230
VDC
9/0.35”
23.5/0.93”
2/
0.08”
+A2
-A1
3.4/0.13”
7.62/3”
5.45/0.21”
12.25/0.48”
MODULE 42
Approvals
General data
Module material
Module colour
PA66+GF (V0)
RAL 7035 / Pantone 1C
European low-voltage
directive compliant
Packaging
Box content:
1 bag, 100pcs.
Box size: W 160 x D 70 x H 80 mm Weight: ~350g
(W 6.30 x D 2.75 x H 3.15) inches Weight: ~12.3oz
31.5/1.24”
1.5/0.06”
Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network
3
Types and electrical configurations
Diagram
Type
Description
Operating
voltage
LED
Colour
Ordering code
ZMI, ZD, ZDM
Sockets
Notes
ZPD9, ZPD11
-A1
+A2
12
Free wheeling diode A2 +
6 / 230VDC
n.a.
MODULE12
MODULE11
M
+A1
-A2
22
Free wheeling diode A1 +
6 / 230VDC
n.a.
MODULE22
MODULE21
-A1
32
+A2
+A1
42
-A2
6 / 24VDC
24 / 60VDC
110 / 230VDC
Free wheeling diode A2 +,
with LED
6 / 24VDC
24 / 60VDC
110 / 230VDC
6 / 24VDC
24 / 60VDC
110 / 230VDC
Free wheeling diode A1 +,
with LED
6 / 24VDC
24 / 60VDC
110 / 230VDC
RC Filter
110/240VAC
6 / 24VAC
24 / 60VAC
6 / 24V
Red
Green**
Red
Green**
MODULE32
MODULE32B
MODULE32C
MODULE32/G
MODULE32B/G
MODULE32C/G
MODULE42
MODULE42B
MODULE42C
MODULE42/G
MODULE42B/G
MODULE42C/G
MODULE52
Only for DC
relays
n.a.
MODULE51
MODULE51B
MODULE51D
Only for AC
relays
A1
A2
52
RC Filter
RC Filter
n.a.
MODULE52B
MODULE52D
MODULE62
+A1
~
-A2
~
62
Signalling LED
92
24 / 60V
110 / 230V
6 / 24V
Red
MODULE62E
MODULE92
MODULE62/G
Green**
+A1
~
-A2
~
62
Signalling LED
92
24 / 60V
110 / 230V
6 / 24V
MODULE62E/G
MODULE92/G
n.a.
MODULE62C
Can work with AC
and DC Relays
+A1
~
-A2
~
62
Signalling LED, with
Varistor
24 / 60V
110 / 230V
6 / 24V
Red
MODULE62D
MODULE92C
92
MODULE62C/G
Green**
+A1
~
-A2
~
62
Signalling LED, with
Varistor
24 / 60V
110 / 230V
6 / 24VAC
MODULE62D/G
MODULE92C/G
MODULE72
MODULE71
MODULE71A
MODULE81
92
A1
A2
72
Varistor
82
115VAC
230VAC
n.a.
MODULE72A
MODULE82
A1
A2
102
Resistor
110 / 230VAC
n.a.
MODULE102
n.a.
** Non standard devices normally not in stock and production upon request
4
Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.
