CREAT BY ART
KBU1001 - KBU1007
Single Phase 10.0AMPS. Bridge Rectifiers
KBU
Pb
RoHS
COMPLIANCE
Features
UL Recoganized File # E-326243
Ideal for printed circuit board
High case dielectric strength
Plastic material has Underwriters laboratory
flammability Classification 94V-0
Typical IR less than 0.1uA
High surge current capability
High temperature soldering guaranteed:
260℃ / 10 seconds at 5 lbs., (2.3kg) tension
Green compound with suffix "G" on packing code &
prefix "G" on datecode.
Mechanical Data
Case: Molded plastic body
Terminals: Pure tin plated, lead free, solderable
per MIL-STD-202, Method 208
Weight: 8.0 grams
Mounting Torque: 5 in lbs max.
Dimensions in inches and (millimeters)
Marking Diagram
KBU100X
G
Y
WW
= Specific Device Code
= Green Compound
= Year
= Work Week
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
=65℃
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method)
Rating of fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage (Note 1)
@5A
@ 10 A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
@ T
A
=25
℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
It
V
F
2
KBU
1001
50
35
50
KBU
1002
100
70
100
KBU
1003
200
140
200
KBU
1004
400
280
400
10
300
373
1.0
1.1
10
500
400
25
2.2
KBU
1005
600
420
600
KBU
1006
800
560
800
KBU
1007
1000
700
1000
Units
V
V
V
A
A
AS
V
2
I
R
Cj
R
θJA
R
θJC
T
J
T
STG
uA
pF
O
Typical Junction Capacitance per leg (Note 2)
Typical Thermal Resistance (Note 3)
Operating Temperature Range
Storage Temperature Range
Note 1 : Pulse Test with PW=300 usec, 1% Duty Cycle
C/W
O
O
- 55 to + 125
- 55 to + 150
C
C
Note 2 : Measured at 1MHz and applied Reverse bias of 4.0V D.C.
Note 3 : Unit case mounted on 4" x 6" x 0.25" Al plate heat sink.
Version:F10
RATINGS AND CHARACTERISTIC CURVES (KBU1001 THRU KBU1007)
FIG.1 MAXIMUM DERATING CURVE FOR
OUTPUT CURRENT
12
PEAK FORWARD SURGE
A
CURRENT (A)
AVERAGE FORWARD
A
CURRENT (A)
10
8
6
4
2
0
0
20
40
60
80
100
o
300
250
200
150
100
50
0
120
140
160
1
AMBIENT TEMPERATURE ( C)
FIG. 2 MAXIMUM FORWARD SURGE CURRENT
PER LEG
8.3mS Single
Half Sine Wave
(JEDEC Method)
10
NUMBER OF CYCLES AT 60 Hz
100
1000
INSTANTANEOUS REVERSE CURRENT
(uA)
FIG. 3 TYPICAL REVERSE LEAKAGE
CHARACTERISTICS PER LEG
FIG. 4 TYPICAL FORWARD CHARACTERISRICS PER
LEG
100
INSTANTANEOUS FORWARD CURRENT
(A)
100
TA=125℃
10
10
1
TA=25℃
1
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (V)
0.1
0.6
0.7
0.8
0.9
1
1.1
1.2
INSTANTNAEOUS FORWARD VOLTAGE (V)
1.3
FIG. 5 TYPICAL JUNCTION CAPACITANCE
1000
JUNCTION CAPACITANCE (pF)
A
100
10
0.1
1
10
100
REVERSE VOLTAGE (V)
Version:F10
