Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 10.16 mm (0.400 inch) - SU/BU | Plug
connectors, solder connection, pitch 10.16 | SU 10.16HP/90 | SU 10.16HP/90SF
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Fitted to PCB
Outgoing elbow
Pitch
Pitch in inch
No. of poles
Solder pin length
Can be coded
No. of rows
No. of solder pins per pole
Dia. of fitting hole
Fitting hole tolerance
L1 in mm
L1 in inch
Insulation resistance
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
1851110000
SU10.16HP/09/90SF 3.5AGSW
PCB plug-in connector, Male connectors, Soldered
connection, Pitch: 10.16 mm, No. of poles: 9, 90°,
Box
4032248382071
20 pc(s).
Soldered connection
90°
10.16 mm
0.4 inch
9
3.5 mm
Yes
1
2
1.6 mm
+ 0.1 mm
81.28 mm
3.2 inch
1 MΩ
IP20 plugged
Safe from finger touch, plugged
PBT GF
black
Similar to RAL 9011
IIIa
V-0
>= 600
Copper alloy
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 10.16 mm (0.400 inch) - SU/BU | Plug
connectors, solder connection, pitch 10.16 | SU 10.16HP/90 | SU 10.16HP/90SF
Material data
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group C)
Rated current (Use group C)
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group C)
Rated current (Use group C)
Rated voltage (Use group D)
Rated current (Use group D)
Approvals
Approvals institutes
silver-plated
-25 °C
120 °C
-25 °C
55 °C
80 %
76 A
72 A
690 V
8 kV
1,000 V
8 kV
1,000 V
6 kV
3 x 1s with 1000 A
300 V
54 A
600 V
5A
300 V
54 A
600 V
5A
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 10.16 mm (0.400 inch) - SU/BU | Plug
connectors, solder connection, pitch 10.16 | SU 10.16HP/90 | SU 10.16HP/90SF
Approvals
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
SU.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1851040000
1851050000
1851060000
1851070000
1851080000
1851090000
1851100000
Part designation
SU10.16HP/02/90SF 3.5AGSW
SU10.16HP/03/90SF 3.5AGSW
SU10.16HP/04/90SF 3.5AGSW
SU10.16HP/05/90SF 3.5AGSW
SU10.16HP/06/90SF 3.5AGSW
SU10.16HP/07/90SF 3.5AGSW
SU10.16HP/08/90SF 3.5AGSW
Version
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 2, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 3, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 5, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 7, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 10.16 mm, No. of poles: 8, 90°, Box
-3-
