Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.08 mm (0.200 inch) - SLA/BLA | Plug
connectors, solder connection pitch 5.08 | SLAD 90 | SLAD 90
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Fitted to PCB
Outgoing elbow
Pitch
Pitch in inch
No. of poles
Solder pin length
Can be coded
No. of rows
No. of solder pins per pole
Dia. of fitting hole
Fitting hole tolerance
L1 in mm
L1 in inch
Insulation resistance
1372860000
SLAD 16/90 3.2SN OR
PCB plug-in connector, Male connectors, Soldered
connection, Pitch: 5.08 mm, No. of poles: 16, 90°,
Box
4008190014148
20 pc(s).
Soldered connection
90°
5.08 mm
0.2 inch
16
3.2 mm
Yes
2
1
1.3 mm
+ 0.1 mm
35.56 mm
1.4 inch
1 MΩ
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.08 mm (0.200 inch) - SLA/BLA | Plug
connectors, solder connection pitch 5.08 | SLAD 90 | SLAD 90
System parameters
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
Safe from back-of-hand touch, plugged
PBT GF
orange
Similar to RAL 2000
IIIa
V-0
>= 200
CuSn
tinned
-25 °C
120 °C
-25 °C
55 °C
80 %
10 A
7A
8.5 A
6A
250 V
4 kV
320 V
4 kV
400 V
4 kV
3 x 1s with 70 A
300 V
7A
300 V
10 A
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.08 mm (0.200 inch) - SLA/BLA | Plug
connectors, solder connection pitch 5.08 | SLAD 90 | SLAD 90
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
SLAD.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1320060000
1320160000
1372460000
1372560000
1372660000
1372760000
1372960000
1373060000
1373160000
1373260000
Part designation
SLAD 4/90 3.2SN OR
SLAD 6/90 3.2SN OR
SLAD 8/90 3.2SN OR
SLAD 10/90 3.2SN OR
SLAD 12/6/90 3.2SN OR
SLAD 14/90 3.2SN OR
SLAD 18/90 3.2SN OR
SLAD 20/90 3.2SN OR
SLAD 22/90 3.2SN OR
SLAD 24/6/90 3.2SN OR
Version
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 8, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 10, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 12, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 14, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 18, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 20, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 22, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 24, 90°, Box
-3-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.08 mm (0.200 inch) - SLA/BLA | Plug
connectors, solder connection pitch 5.08 | SLAD 90 | SLAD 90
1373360000
1373460000
1373560000
1373660000
1373760000
1373860000
1373960000
1374060000
1374160000
1374260000
1374360000
1374460000
SLAD 26/90 3.2SN OR
SLAD 28/90 3.2SN OR
SLAD 30/90 3.2SN OR
SLAD 32/90 3.2SN OR
SLAD 34/90 3.2SN OR
SLAD 36/6/90 3.2SN OR
SLAD 38/90 3.2SN OR
SLAD 40/90 3.2SN OR
SLAD 42/90 3.2SN OR
SLAD 44/90 3.2SN OR
SLAD 46/90 3.2SN OR
SLAD 48/6/90 3.2SN OR
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 26, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 28, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 30, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 32, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 34, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 36, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 38, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 40, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 42, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 44, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 46, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 5.08 mm, No. of poles: 48, 90°, Box
-4-
