F-219
PCIE–098–02–F–D–EMS2
PCIE–064–02–F–D–RA
(1.00 mm) .0394"
PCIE–036–02–F–D–TH
PCIE SERIES
PCI EXPRESS CARD SOCKETS
®
Polarized
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?PCIE
Insulator Material:
–TH=Black Nylon
–EMS2 & –RA=LCP
Contact:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
2.2 A per pin
(2 adjacent pins powered)
Operating Temp:
-55 °C to +125 °C
Card Insertion Depth:
(7.65 mm) .301" nominal
RoHS Compliant:
Yes
Lead–Free Solderable:
–RA & –EMS2=Yes
–TH=Wave only
Card Mates:
(1.60 mm) .062" card
Cable Mates:
PCIEC
Supports one,
four, eight and
sixteen PCI
Express
®
links
Accepts
1.60 mm
(.062") card
Note:
While optimized for
50
W
applications, this
connector with alternative
signal/ground patterns may
also perform well in certain
75
W
applications.
Choice of
card–edge mount
or PCB mount
Alignment
pins
HIGH-SPEED CHANNEL PERFORMANCE
PCIE
Rating based on Samtec reference channel.
For full SI performance data visit Samtec.com
or contact SIG@samtec.com
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
14
G b p s
Four rows on
2 mm pitch
ALSO AVAILABLE
(MOQ Required)
• Other platings
PCIE
NO. OF
POSITIONS
02
PLATING
OPTION
D
TAIL
OPTION
OTHER
SOLUTIONS
PCI Express
®
Jumpers &
Extenders call for PCIEC Series
–036, –064, –098, –164
A
B2
B1
= Gold flash on contact,
Tin on tail
–F
= Edge Mount
–EMS2
–TH
= Through-hole
= Right-angle
(1.00) .03937
B
(1.78) .070
(11.00)
.433
(15.40)
.606
(2.05)
.081
DIA
(1.35) .053
C
D
A
B
(9.45)
.372
A1
A2
A1
–RA
(11.65)
.459
(8.61)
.339
(7.50)
.295
(11.05)
.435
(4.50)
.177
(7.30)
.287
(7.65)
.301
• Loop back Extender
(From one PCIe
®
slot to
another PCIe
®
slot)
• Ser-Des Physical Extender
(From one PCIe
®
slot to
another PCIe
®
Ser-Des)
• Physical Extender for easy
troubleshooting of PCIe
®
card
debug and analysis (PCIe
®
slot to Emulator or Analyzer)
(2.31)
.091
(10.00)
.394
(2.50)
.098
(2.00)
.079
–TH
(1.50)
.059
–EMS2
POSITIONS
–036 (X1)
–064 (X4)
A
(25.00)
.984
(39.00)
1.535
(56.00)
2.205
(89.00)
3.504
(1.80) .071
B1
B
(7.65)
.301
(21.65)
.852
(38.65)
1.522
(71.65)
2.821
C
(6.00)
.236
(20.00)
.787
(37.00)
1.457
(70.00)
2.756
D
(9.15)
.360
(23.15)
.911
(40.15)
1.581
(73.15)
2.880
PCI-SIG
®
, PCI Express
®
and
the PCIe
®
design marks are
registered trademarks and/or
service marks of PCI-SIG.
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(1.00) .03937
C
D
(10.00)
.394
(4.50)
.177
(6.50)
.256
(2.50)
.098
–098 (X8)
–164 (X16)
–RA
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
