2. Ramp up rate during preheat: 1.4°C/s (from 50°C to 100°C)
3. Soaking temperature: 0.5°C/s (from 100°C to 130°C), 60±20 seconds
4. Peak temperature: 260°C, above 250°C for 3~6 seconds
5. Ramp down rate during cooling: -10°C/s (from 260°C to 150°C)
Temperature (°C)
Time (Seconds)
MECHANICAL
parameter
dimensions
weight
cooling
natural convection
conditions/description
1.913 x 0.917 x 0.806 (48.60 x 23.30 x 20.48 mm)
14
min
typ
max
units
inch
g
MECHANICAL DRAWING
units: inch [mm]
tolerance: X.XXX = ±0.020 [±0.50]
PIN
1
2
3
4
Function
ACN
ACL
+Vout
1.913 48.60
0.400 10.16
0.806 20.48 max
PIN CONNECTIONS
0.917 23.30
0.059 1.49
-Vout
0.800 20.32
1
3
4
2
0.602 15.28 max
0.173 4.40
0.039 1.00
1.800 45.72
cui.com
0.150 3.80
0.459 11.65
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VOF-10B
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
02/23/2017
│
page
4 of 5
DERATING CURVE
Output Power vs. Ambient Temperature
(Natural Convention)
100
75
50
25
0
-25 -15 -5
Load (%)
Ambient Temperature (°C)
0
5
15 25 35 45 55 65 75
EFFICIENCY CURVES
5 Vdc Output Efficiency Curve
(at 25°C)
85.0
80.0
9 Vdc Output Efficiency Curve
(at 25°C)
90.0
85.0
Efficiency (%)
75.0
70.0
65.0
60.0
55.0
10
20
30
40
50
60
70
80
85 Vac
115 Vac
230 Vac
264 Vac
Efficiency (%)
80.0
75.0
70.0
65.0
60.0
85 Vac
115 Vac
230 Vac
264 Vac
Current Load (%)
90
100
55.0
10
20
30
40
Current Load (%)
50
60
70
80
90
100
12 Vdc Output Efficiency Curve
(at 25°C)
90.0
85.0
15 Vdc Output Efficiency Curve
(at 25°C)
90.0
85.0
Efficiency (%)
Efficiency (%)
80.0
75.0
70.0
65.0
60.0
55.0
10
20
30
40
50
60
70
80
85 Vac
115 Vac
230 Vac
264 Vac
80.0
75.0
70.0
65.0
60.0
85 Vac
115 Vac
230 Vac
264 Vac
Current Load (%)
90
100
55.0
10
20
30
40
Current Load (%)
50
60
70
80
90
100
24 Vdc Output Efficiency Curve
(at 25°C)
90.0
85.0
Efficiency (%)
80.0
75.0
70.0
65.0
60.0
55.0
10
20
30
40
50
60
70
80
85 Vac
115 Vac
230 Vac
264 Vac
Current Load (%)
90
100
cui.com
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VOF-10B
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
02/23/2017
│
page
5 of 5
REVISION HISTORY
rev.
1.0
description
initial release
The revision history provided is for informational purposes only and is believed to be accurate.
date
02/23/2017
