BC807-16
BC807-25
BC807-40
PNP Silicon
General Purpose
Transistors
SOT-23
A
D
•
•
Features
•
•
•
•
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Capable of 0.3Watts of Power Dissipation.
Collector-current 0.5A
Collector-base Voltage 50V
Operating and storage junction temperature range: -55
O
C to +150
O
C
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
Mechanical Data
Case: SOT-23 Molded Plastic
Terminals: Solderable per MIL-STD-202, Method 208
Weight: 0.008 grams (approx.)
Device Marking:
BC807-16
5A
BC807-25
5B
BC807-40
5C
Symbol
Parameter
Collector-Emitter Breakdown Voltage
(I
C
=10mAdc, I
B
=0)
Collector-Base Breakdown Voltage
(I
C
=10µAdc, I
E
=0)
Collector-Emitter Breakdown Voltage
(I
E
=1.0µAdc, I
C
=0)
Collector Cutoff Current
(V
CB
=45Vdc,I
E
=0)
Collector Cutoff Current
(V
CE
=40V dc,I
E
=0)
Emitter Cutoff Current
(V
EB
=4.0Vdc, I
C
=0)
DC Current Gain
(I
C
=100mAdc, V
CE
=1.0Vdc)
BC807-16
BC807-25
BC807-40
DC Current Gain
(I
C
=500mAdc, V
CE
=1.0Vdc)
Collector-Emitter Saturation Voltage
(I
C
=500mAdc, I
B
=50mAdc)
Base-Emitter Saturation Voltage
(I
C
=500mAdc,I
B
=50mAdc)
T
A
= 25°C
3
C
B
C
B
F
E
E
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Min
45
50
5.0
---
---
---
Max
---
---
---
0.1
0.2
0.1
Units
G
H
J
OFF CHARACTERISTICS
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
I
CBO
I
CEO
I
EBO
Vdc
K
Vdc
Vdc
DIM
A
B
C
D
E
F
G
H
J
K
DIMENSIONS
INCHES
MIN
MAX
.110
.120
.083
.104
.047
.055
.035
.041
.070
.081
.018
.024
.0005
.0039
.035
.044
.003
.007
.015
.020
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
NOTE
µAdc
µAdc
µAdc
ON CHARACTERISTICS
h
FE(1)
Suggested Solder
Pad Layout
100
160
250
40
---
---
---
250
400
600
---
0.7
1.2
403
---
---
---
---
Vdc
Vdc
°C/W
.037
.950
.037
.950
.031
.800
.035
.900
.079
2.000
inches
mm
h
FE(2)
V
CE(sat)
V
BE(sat)
R
θJA
SMALL SIGNAL CHARACTERISTICS
f
T
Current-Gain-Bandwidth Product
(V
CE
=5.0V, f=100MHz, I
C
=10mA)
100
---
MHz
www.mccsemi.com
Revision: D
1
of 3
2013/06/04
MCC
Micro Commercial Components
R
BC807-16 thru BC807-40
VCE = -1.0 V
TA = 25°C
hFE, DC CURRENT GAIN
θ
V, TEMPERATURE COEFFICIENTS (mV/
°
C)
1000
+1.0
θ
VC for VCE(sat)
0
100
-1.0
θ
VB for VBE
-2.0
10
-0.1
-1.0
-10
-100
IC, COLLECTOR CURRENT (mA)
-1000
-1.0
-10
-100
IC, COLLECTOR CURRENT
-1000
Figure 1. DC Current Gain
VCE , COLLECTOR-EMITTER VOLTAGE (VOLTS
)
-1.0
TJ = 25°C
-0.8
-0.6
-0.4
IC = -300 mA
-0.2
0
-0.01
IC = -10 mA
-0.1
-1.0
IB, BASE CURRENT (mA)
-10
-100
IC = -100 mA
IC =
-500 mA
V, VOLTAGE (VOLTS)
-0.8
-0.6
-0.4
-0.2
-1.0
Figure 4. Temperature Coefficients
TA = 25°C
VBE(sat) @ IC/IB = 10
VBE(on) @ VCE = -1.0 V
VCE(sat) @ IC/IB = 10
0
-1.0
-10
-100
-1000
IC, COLLECTOR CURRENT (mA)
Figure 2. Saturation Region
400
See Note 1
Figure 5. “On” Voltages
P
d
, POWER DISSIPATION (mW)
300
200
100
0
0
100
50
150
T
JA
, Junction to Ambient Air
(°C)
200
Figure 3. Power Derating Curve
www.mccsemi.com
Revision: D
2
of 3
2013/06/04
