SMAZ5V1
THRU
SMAZ39
1 Watt
Zener Diode
5.1V - 39V
Volts
DO-214AC
(SMAJ)( LEAD FRAME)
H
Features
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
1.0W Power Dissipation
High Surge Capability
Ideally Suited for Automatic Assembly
Standard V
Z
Tolerance is
+/-
5%
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
to +150
to +150
•
•
MaximumRatings
•
•
Storage Temperature Range(T
STG
): -65
Operating Temperature Range(T
j
): -65
Cathode Band
Zener Current
Power Dissipation
@ T
A
=50
o
C
Forward Voltage@I
F
= 200mA
Symbol
I
ZM
P
tot
VF
RthJT
RthJA
Value
Pd/Vz
1000
1.2
30
100
Units
mA
J
mW
V
o
o
A
C
Junction to Terminal
Thermal resistance
C/W
E
F
G
DIMENSIONS
INCHES
MIN
.079
.050
.002
---
.030
.065
.189
.157
.090
MM
MIN
2.00
1.27
.05
---
.76
1.65
4.80
4.00
2.25
C/W
D
B
DIM
A
B
C
D
E
F
G
H
J
MAX
.096
.064
.008
.02
.060
.091
.220
.181
.115
MAX
2.44
1.63
.20
.51
1.52
2.32
5.59
4.60
2.92
NOTE
SUGGESTED SOLDER
PAD LAYOUT
0.090”
0.085”
Note:
1.
High Temperature Solder Exemptions Applied, see EU Directive Annex 7a.
0.070"
Revision:
D
www.mccsemi.com
1 of 4
2014/07/24
SMAZ5V1 - SMAZ39
MCC
Micro Commercial Components
TM
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Zener Voltage
Part Number
Nom
SMAZ5V1
SMAZ5V6
SMAZ6V2
SMAZ6V8
SMAZ7V5
SMAZ8V2
SMAZ9V1
SMAZ10
SMAZ12
SMAZ15
SMAZ16
SMAZ18
SMAZ20
SMAZ22
SMAZ24
SMAZ27
SMAZ30
SMAZ33
SMAZ36
SMAZ39
5.10
5.60
6.20
6.80
7.50
8.20
9.10
10.00
12.00
15.00
16.00
18.00
20.00
22.00
24.00
27.00
30.00
33.00
36.00
39.00
V
Z
Voltages
Min
4.84
5.32
5.89
6.46
7.13
7.79
8.65
9.50
11.40
14.25
15.20
17.10
19.00
20.90
22.80
25.65
28.50
31.35
34.20
37.05
Max
5.40
5.88
6.51
7.14
7.88
8.61
9.56
10.50
12.60
15.75
16.80
18.90
21.00
23.10
25.20
28.35
31.50
34.65
37.80
40.95
Maximum Zener Maximum Zener
Impedance
Z
ZT
(OHMS)
I
ZT
(mA)
100
100
100
100
100
100
50
50
50
50
25
25
25
25
25
25
25
25
10
10
Max
5.0
2.0
2.0
2.0
2.0
2.0
4.0
4.0
7.0
10.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
40.0
40.0
Impedance
Z
ZK
(OHMS)
I
ZK
(mA)
1.0
2.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Max
500
250
200
200
450
200
200
200
150
150
150
150
180
180
180
200
250
300
350
450
Reverse
Current
I
R
(Max) @ V
R
µA
I
ZM
Max
Marking
(Note 1)
mA
196
179
161
147
133
122
110
100
83
67
63
56
50
45
42
37
33
30
28
26
Z5V1
Z5V6
Z6V2
Z6V8
Z7V5
Z8V2
Z9V1
Z10
Z12
Z15
Z16
Z18
Z20
Z22
Z24
Z27
Z30
Z33
Z36
Z39
V
1.0
2.0
3.0
4.0
5.0
6.0
7.0
7.6
9.1
11.4
12.2
13.7
15.2
16.7
18.2
20.5
22.8
25.1
27.4
29.6
2.5
5.0
5.0
5.0
5.0
5.0
5.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Notes1.Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch
Revision: D
www.mccsemi.com
2 of 4
2014/07/24
SMAZ5V1 - SMAZ39
1.2
1000
MCC
Micro Commercial Components
SMAZ5V6
TM
P
D
STEADY POWER DISSIPATION (W)
C
j
, JUNCTION CAPACITANCE (pF)
1.0
SMAZ12
0.8
100
SMAZ27
0.6
0.4
10
0.2
0
0
50
100
150
175
T
A
, AMBIENT TEMPERATURE
°C
Fig. 1 Power Dissipation vs Ambient Temperature
20
I
FM
, PEAK FORWARD CURRENT (A)
10
T
j
= 25°C
0
1
10
100
200
V
R
, REVERSE VOLTAGE (V)
Fig. 2 Junction Capacitance vs Reverse Voltage
2000
1000
T
j
= 125°C
100
10
1
1
0.1
0.01
0.1
0
0.5
1.0
1.5
2.0
2.5
0.001
1
10
100
500
V
ZT
, ZENER REGULATION VOLTAGE (V)
Fig. 4 Leakage Current vs Regulation Voltage
V
FM
, PEAK FORWARD VOLTAGE (V)
Fig. 3 Peak Forward Current vs Peak Forward Voltage
1000
I
ZT
= 5.0mA
100
I
ZT
= 10mA
10
I
ZT
= 20mA
1
I
ZT
= 100mA
0.1
1
10
100
500
V
ZT
, ZENER REGULATION VOLTAGE (V)
Fig. 5 Differential Resistance vs Regulation Voltage
Revision: D
www.mccsemi.com
3 of 4
2014/07/24
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
7.5Kpcs/Reel
