DSC2311KL2-R0048

Description
MEMS CLOCK GENERATOR -40C-105C 2
CategoryPassive components
File Size566KB,5 Pages
ManufacturerMicrochip
Websitehttps://www.microchip.com
Download Datasheet Parametric Compare View All

DSC2311KL2-R0048 Online Shopping

Suppliers Part Number Price MOQ In stock
DSC2311KL2-R0048 - - View Buy Now

DSC2311KL2-R0048 Overview

MEMS CLOCK GENERATOR -40C-105C 2

DSC2311KL2-R0048 Parametric

Parameter NameAttribute value
typeMEMS (silicon)
Frequency - Output 124MHz
Frequency - Output 272MHz
Frequency - Output 3-
Frequency - Output 4-
Functionenable/disable
outputLVCMOS
Voltage - Power2.25 V ~ 3.6 V
frequency stability±25ppm
Operating temperature-40°C ~ 105°C
Current - Power (maximum)23mA
size/dimensions0.098" long x 0.079" wide (2.50mm x 2.00mm)
high0.035"(0.90mm)
Package/casing6-VDFN
DSC2311KL2-R0048
Crystal-less™ Configurable Clock Generator
General Description
DSC2311KL2-R0048 is a crystal-less clock generator
that is factory configurable to simultaneously output
two separate frequencies from 2.3 to 170MHz. The
clock generator uses proven silicon MEMS
technology to provide low jitter and high frequency
stability across a wide range of supply voltages and
temperatures. By eliminating the external quartz
crystal, crystal-less clock generators significantly
enhance reliability
and accelerate product
development, while meeting stringent clock
performance criteria for a variety of consumer
electronics, communications, and storage applications.
DSC2311KL2-R0048 has an output enable/disable
feature allowing it to disable the outputs when OE is
low. The device is available in a space-saving 6-pin
2.5mm x 2.0mm TDFN package that needs only a
single external bypass capacitor. This requires a PCB
footprint equivalent to that of a 1.0mm x 1.0mm
crystal-based clock generator.
Features
• Two simultaneous LVCMOS outputs:
- 24MHz
- 72MHz
• Low RMS phase jitter: <1ps (typical)
• ±25ppm frequency stability
• -40°C to +105°C ext. industrial temperature range
• High supply noise rejection: -50dBc
• High shock & vibration immunity
- Qualified to MIL-STD-883
• High reliability
- 20x higher MTBF than crystal-based clock
generator designs
• Programmable output strength for EMI reduction
and signal integrity optimization
• Supply range of 2.25 to 3.6V
• AEC-Q100 automotive qualified
• 6-pin 2.5mm x 2.0mm TDFN package
Applications
• Consumer Electronics
• Camera and Imaging Modules
• Home Automation
• Industrial and Power Conversion
• Mobile Communications, Internet, and Sensor Devices
• Solid State, Hard Drive, and Flash Drive Storage
• Automotive
Block Diagram
Control Circuitry
÷ M1
CLK0
24MHz LVCMOS
MEMS
PLL
÷ M2
OE
CLK1
72MHz LVCMOS
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (408) 944-0800 • fax + 1 (408) 474-1000 •
http://www.micrel.com
May 19, 2016
3917
Revision 1.0
tcghelp@micrel.com
or (408) 955-1690

DSC2311KL2-R0048 Related Products

DSC2311KL2-R0048 DSC2311KL2-R0048T
Description MEMS CLOCK GENERATOR -40C-105C 2 MEMS CLOCK GENERATOR -40C-105C 2
type MEMS (silicon) MEMS (silicon)
Frequency - Output 1 24MHz 24MHz
Frequency - Output 2 72MHz 72MHz
Function enable/disable enable/disable
output LVCMOS LVCMOS
Voltage - Power 2.25 V ~ 3.6 V 2.25 V ~ 3.6 V
frequency stability ±25ppm ±25ppm
Operating temperature -40°C ~ 105°C -40°C ~ 105°C
Current - Power (maximum) 23mA 23mA
size/dimensions 0.098" long x 0.079" wide (2.50mm x 2.00mm) 0.098" long x 0.079" wide (2.50mm x 2.00mm)
high 0.035"(0.90mm) 0.035"(0.90mm)
Package/casing 6-VDFN 6-VDFN
