IllumInatIon
luXEon t
A bright, versatile and high efficacy emitter
LUXEON T is designed to deliver high efficacy with high flux density to
enable tight beam control in directional and high lumen applications.
With
Freedom from Binning
and leading performance, LUXEON T LEDs are
specified, targeted and tested hot, at real world operating temperatures,
85°C, to ensure in-application performance. LUXEON T LEDs allow system
optimization by blending the perfect combination of high efficacy and low
system cost, while tight correlated color temperature ensures consistency
in system color point.
FEaturEs and BEnEFIts
3 & 5-step MacAdam ellipse:
Freedom from Binning
for superior
Quality of Light
Low V
f
and thermal resistance enables smaller heatsinks and higher lumens
High luminance and small optical source for precise beam control in
directional applications
Superior efficacy and light output from a compact source
PrImary aPPlIcatIons
Downlights
High Bay & Low Bay
Indoor Area Lighting
Lamps
Outdoor
LUXEON T product performance at 700mA and 350mA, T
j
=85°C.
nomInal
cct
3000K
4000K
5000K
5700K
6500K
2700K
3000K
3500K
4000K
5000K
3000K
mInImum
crI
[1]
70
70
70
70
70
80
80
80
80
80
95 typ
lumInous FluX
[2]
(lm)
mInImum
200
210
220
220
220
170
180
190
190
190
130
tyPIcal
700ma
218
249
255
255
255
186
197
208
212
222
160
111
127
130
130
130
95
101
106
108
113
82
117
133
136
136
136
100
106
112
114
120
86
tyPIcal
lumInous
EFFIcacy (lm/W)
tyPIcal
lumInous
FluX (lm)
tyPIcal
lumInous
EFFIcacy (lm/W)
350ma
123
140
143
143
143
105
112
118
120
127
91
LXH7-FW30
LXH7-FW40
LXH7-FW50
LXH7-FW57
LXH7-FW65
LXH8-FW27-x
LXH8-FW30-x
LXH8-FW35-x
LXH8-FW40-x
LXH8-FW50-x
LXH9-FW30-x
Part numBEr
Notes:
1. Lumileds maintains a tolerance of ±2 on CRI measurements.
2. Lumileds maintains a tolerance of ±6.5% on luminous flux measurements.
LUXEON T Royal Blue product performance at test current, T
j
=85°C.
PEak WaVElEnGtH (nm)
mInImum
445
maXImum
460
radIomEtrIc PoWEr (mW)
mInImum
950
tyPIcal
1040
Part numBEr
LXH1-FWRB
Notes:
1. Lumileds maintains a tolerance of ±2nm on peak wavelength measurements.
Mechanical Dimensions
.
Notes:
1. Drawings are not scale.
2. All dimensions are in millimeters.
©2015 Lumileds Holding B.V. All rights reserved.
LUXEON is a registered trademark of the Lumileds Holding B.V.
in the United States and other countries.
lumileds.com
Neither Lumileds Holding B.V. nor its affiliates shall be liable for any kind of loss of data or any
other damages, direct, indirect or consequential, resulting from the use of the provided
information and data. Although Lumileds Holding B.V. and/or its affiliates have attempted to
provide the most accurate information and data, the materials and services information and data
are provided “as is,” and neither Lumileds Holding B.V. nor its affiliates warrants or guarantees
the contents and correctness of the provided information and data. Lumileds Holding B.V. and its
affiliates reserve the right to make changes without notice. You as user agree to this disclaimer
and user agreement with the download or use of the provided materials, information and data.
PB106 LUXEON T Product Brief 20151028
