Monolithic crystal filter
MQF10.7-0750/14
Application
•
6 pol filter
•
i.f.- filter
•
use in mobile and
stationary transceivers
Limiting values
Unit
Value
Center frequency
Insertion loss
Pass band at 3.0 dB
Ripple in pass band
Stop band attenuation
Alternate attenuation
fo
±
3.00 kHz
±
8.75 kHz
± 12.5 kHz
± 12.5...300 kHz
fo
fo
fo
fo
MHz
dB
kHz
dB
dB
dB
dB
10.7
≤
3.5
±
3.75
≤
2.0
≥
45
> 65
> 65
Terminating impedance Z
R1 || C1
R2 || C2
Ohm/pF
Ohm/pF
1600 || 3.5
1600 || 3.5
Operating temp. range
°C
-20... +70
Characterstics
Pass band
MQF10.7-0750/14
Stop band
Pin connections: 1
2
3
4
Input
Input-E
Output
Output-E
