ISL6840IB-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> ISL6840IB-T

ISL6840IB-T: DescriptionIC REG CTRLR BOOST/FLYBACK 8SOIC; CategoryPower/power management The power supply circuit; File Size681KB，14 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric View All

ISL6840IB-T Overview

IC REG CTRLR BOOST/FLYBACK 8SOIC

ISL6840IB-T Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC
package instruction	PLASTIC, MS-012AA, SOIC-8
Contacts	8
Reach Compliance Code	not_compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	14 V
Minimum input voltage	7.5 V
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	8
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP8,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	SINGLE
Maximum switching frequency	2000 kHz
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

DATASHEET

ISL6840, ISL6841, ISL6842, ISL6843, ISL6844, ISL6845

Improved Industry Standard Single-Ended Current Mode PWM Controller

The ISL6840, ISL6841, ISL6842, ISL6843, ISL6844,

ISL6845 family of adjustable frequency, low power, pulse

width modulating (PWM) current mode controllers is

designed for a wide range of power conversion applications

including boost, flyback, and isolated output configurations.

Peak current mode control effectively handles power

transients and provides inherent overcurrent protection.

This advanced BiCMOS design is pin compatible with the

industry standard 384x family of controllers and offers

significantly improved performance. Features include low

operating current, 60µA start-up current, adjustable

operating frequency to 2MHz, and high peak current drive

capability with 20ns rise and fall times.

PART NUMBER

ISL6840

ISL6841

ISL6842

ISL6843

ISL6844

ISL6845

RISING UVLO (V) MAX. DUTY CYCLE (%)

7.0

14.4

8.4

14.4

8.4

100

FN9124

Rev 13.00

February 18, 2015

Features

• 1A MOSFET Gate Driver

• 60µA Start-up Current, 100µA Maximum

• 25ns Propagation Delay Current Sense to Output

• Fast Transient Response with Peak Current Mode Control

• Adjustable Switching Frequency to 2MHz

• 20ns Rise and Fall Times with 1nF Output Load

• Trimmed Timing Capacitor Discharge Current for Accurate

Deadtime/Maximum Duty Cycle Control

• High Bandwidth Error Amplifier

• Tight Tolerance Voltage Reference Over Line, Load, and

Temperature

• Tight Tolerance Current Limit Threshold

• Pb-Free Available (RoHS Compliant)

Applications

• Telecom and Datacom Power

• Wireless Base Station Power

• File Server Power

• Industrial Power Systems

• PC Power Supplies

• Isolated Buck and Flyback Regulators

• Boost Regulators

Pinouts

ISL6840, ISL6841, ISL6842, ISL6843, ISL6844, ISL6845

(8 LD SOIC, MSOP)

TOP VIEW

COMP 1

FB 2

CS 3

RTCT 4

8 VREF

7 VDD

6 OUT

5 GND

ISL6840, ISL6841, ISL6842, ISL6843, ISL6844, ISL6845

(8 LD DFN)

TOP VIEW

COMP

RTCT

VREF

VDD

OUT

GND

FN9124 Rev 13.00

February 18, 2015

Page 1 of 14
