AZ956
MICROMINIATURE
POLARIZED RELAY
FEATURES
•
Microminiature size: up to 50% less board area than
previous generation telecom relays
•
Meets FCC Part 68.302 1500 V lightning surge
•
Low power consumption: 36 mW pickup
•
Stable contact resistance for low level signal switching
•
Epoxy sealed
•
UL, CUR file E43203
•
All plastics meet UL94 V–O, 30 min. oxygen index
CONTACTS
Arrangement
Ratings
SPDT (1 Form C)
Bifurcated crossbar contacts
Resistive load:
Max. switched power: 30 W or 60 VA
Max. switched current: 1.0 A
Max. switched voltage: 150 VDC or 125 VAC
Rated Load
UL, CUR
Material
Resistance
0.5 A at 120 VAC
1.0 A at 30 VDC
Palladium nickel with gold-rhodium overlay
< 50 milliohms initally
(6 V, 10 mA method)
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Operate Time
(typical)
Release Time (typical)
Bounce (typical)
Dielectric Strength
(at sea level)
Dropout
Minimum operations
1 x 10
9
2.5 x 10
5
at 0.4 A, 125 VAC, resistive
3 x 10
6
at 1.0 A, 24 VDC, resistive
1 ms at nominal coil voltage
0.4 ms at nominal coil voltage
(with no coil suppression)
At 10 mA contact current
1 ms at operate or release
1500 Vrms contact to coil
500 Vrms between open contacts
Greater than 10% of nominal coil voltage
10
9
ohms min. at 25°C, 500 VDC,
50% RH
At nominal coil voltage
-40°C (-40°F) to 70°C (158°F)
-40°C (-40°F) to 105°C (221°F)
Operational, 40 g, 10–200 Hz
Operational, 50 g min., 11 ms
Non-destructive, 150 g min., 11 ms
Vapor phase: 215°C, 40 Sec.
Infrared: 215°C, 40 Sec.
Double wave: 260°C, 10 Sec.
80°C (176°F)
30 seconds
1.8 grams
P.B.T. polyester
Tinned copper alloy, P.C.
COIL (Polarized)
Power
At Pickup Voltage
(typical)
Max. Continuous
Dissipation
Temperature Rise
Temperature
36 mW
0.5 W at 20°C (68°F)
Insulation Resistance
Ambient Temperature
Operating
Storage
Vibration
At nominal coil voltage
8°C (15°F)
Max. 105°C (221°F)
Shock
Max. Solder Temp.
Temp./Time
Max. Solvent Temp.
Max. Immersion Time
Weight
Enclosure
Terminals
NOTES
1. All values at 20°C (68°F).
2. Relay may pull in with less than “Must Operate” value.
3. Relay has fixed coil polarity.
4. Specifications subject to change without notice.
ZETTLER
electronics GmbH
Tel. +49 89 800 97 0
Fax +49 89 800 97 200
office@ZETTLERelectronics.com
www.ZETTLERelectronics.com
2003-06-13
Junkersstrasse 3, D-82178 Puchheim, Germany
