* HS and HT modules are delivered on tape and reel
* V modules are delivered in trays
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
NDM2Z-25
│
DESCRIPTION:
AUTO COMPENSATED, DIGITAL DC-DC POL CONVERTER
date
12/21/2015
│
page
2 of 32
ABSOLUTE MAXIMUM RATINGS
parameter
operating temperature (see
thermal consideration section)
(T
P1
)
storage temperature (T
S
)
input voltage (see operating in-
formation section for input and
output voltage relations)(V
I
)
logic I/O voltage
ground voltage differential
analog pin voltage
Notes:
conditions/description
min
-40
-40
-0.3
typ
max
125
125
16
6.5
0.3
6.5
units
°C
°C
V
V
V
V
CTRL, SA0, SA1, SALERT, SCL, SDA, VSET, SYNC,
DDC, PG
-S, PREF, GND
V
O
, +S, VTRK
-0.3
-0.3
-0.3
Stress in excess of Absolute Maximum Ratings may cause permanent damage. Absolute Maximum Ratings, sometimes referred to as no destruction limits, are
normally tested with one parameter at a time exceeding the limits in the Electrical Specification. If exposed to stress above these limits, function and performance
may degrade in an unspecified manner.
Configuration File
This product is designed with a digital control circuit. The control circuit uses a configuration
fi
le which determines the
functionality and performance of the product. The Electrical Specification table shows parameter values of functionality
and performance with the default configuration
fi
le, unless otherwise specified. The default configuration
fi
le is designed
to
fi
t most application needs with focus on high efficiency. If different characteristics are required it is possible to change
the configuration
fi
le to optimize certain performance characteristics. Note that current sharing operation requires changed
configuration
fi
le.
PRODUCT ELECTRICAL SPECIFICATION, HORIZONTAL
T
P1
= -30 to +95 °C, V
I
= 4.5 to 14 V, V
I
> V
O
+ 1.0 V
Typical values given at: T
P1
= +25 °C, V
I
= 12.0 V, max I
O
, unless otherwise specified under conditions.
External C
IN
= 470
μF/10
mΩ, C
OUT
= 470
μF/10
mΩ. See Operating Information section for selection of capacitor types.
