L
Vishay Sfernice
Ultra Low Value
Thin Film Resistors
FEATURES
•
NiCr + Ta
2
O
5
resistive layer
•
Pre-soldered or gold terminations
•
No inductance for high frequency applications
•
Alumina substrates for high power handling
capability
•
Resistance range: 0.1
Ω
to 9.99
Ω
•
TCR down to 100 ppm/°C
•
Power rating: Up to 1 W at + 70 °C
With extremely low resistance and high power capabilities,
these ultra low value resistors are available with solderable
or weldable terminations.
Pb-free
Available
RoHS*
COMPLIANT
DIMENSIONS
in millimeters [inches]
A
D
D
C
B
E
E
DIMENSION
CASE
SIZE
A
MAX .TOL
+ 0.64 [+ 0.025]
MIN. TOL.
- 0.13 [- 0.005]
1.27 [0.050]
1.52 [0.060]
1.91 [0.075]
2.54 [0.100]
3.20 [0.126]
3.81 [0.150]
5.08 [0.200]
B
MAX. TOL.
+ 0.26 [+ 0.010]
MIN. TOL.
- 0.13 [- 0.005]
1.27 [0.050]
0.75 [0.030]
1.27 [0.050]
1.27 [0.050]
1.60 [0.063]
1.27 [0.050]
2.54 [0.100]
C
MAX. TOL
+ 0.64 [+ 0.025]
MIN. TOL.
- 0.13 [- 0.005]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
D/E
MAX. TOL.
+ 0.13 [+ 0.005]
MIN. TOL.
- 0.13 [- 0.005]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
POWER
RATING
mW
LIMITING
ELEMENT
VOLTAGE
V
RESISTANCE
RANGE
0505
0603
0705
0805
1005
1206
1505
2010
125
125
200
250
330
500
1000
50
50
50
50
50
50
50
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
0.1
Ω...
9.99
Ω
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 53018
Revision: 19-Aug-08
For technical questions, contact: sfer@vishay.com
www.vishay.com
57
L
Vishay Sfernice
ELECTRICAL SPECIFICATIONS
Resistance range:
Resistance tolerance:
Power dissipation:
Temperature coefficient:
0.1
Ω
to 9.99
Ω
± 1 % to ± 10 %
0.125 mW to 1 W at + 70 °C
down to 100 ppm/°C
Ultra Low Value
Thin Film Resistors
PACKAGING
Several types of packaging are proposed: waffle-pack and
tape and reel
NUMBER OF PIECES PER PACKAGE
SIZE MOQ
WAFFLE PACK
2" × 2"
TAPE AND REEL
MIN.
MAX.
TAPE
WIDTH
CLIMATIC SPECIFICATIONS
Operating temp. range:
- 55 °C to + 155 °C
0402
0505
0603
0805
0705
1005
1206
1505
MECHANICAL SPECIFICATIONS
Substrate:
Resistive layer:
Coating:
Terminations:
Alumina
NiCr + Ta
2
O
5
Silicone
Solderable
B type:
SnPb over nickel barrier
N type:
SnAg over nickel barrier
G type:
gold over nickel barrier
100
4000
100
221
140
60
100
8 mm
2010
2000
8 mm
(1)
POWER DERATING CURVE
Rated Power (%)
Note
(1)
12 mm on request
100
80
60
40
20
0
PACKAGING RULES
Waffle Pack
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered exceeds maximum quantity of a
single waffle pack, the waffle packs are stacked up on the top
of each other and closed by one single cover.
To get “not stacked up” waffle pack in case of ordered
quantity > maximum number of pieces per package:
Please concult Vishay/Sfernice for specific ordering
code
Tape and Reel
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered is between the MOQ and the
maximum reel capacity, only one reel is provided.
When several reels are needed for ordered quantity
within MOQ and maximum reel capacity: Please concult
Vishay/Sfernice for specific ordering code
0
20
40
60 70
80
100
120
140 155
Ambient Temperature in °C
TOLERANCE AND TCR VERSUS OHMIC
VALUE
VALUE
RANGE
0R1 < 0R25
0R25 < 0R5
0R5 < 9R99
0R1 < 0R5
0R5 < 9R99
TIGHTEST
TOLERANCE
%
1%
1%
1%
10 %
5%
BEST TCR
(ppm/°C)
300
200
100
300
200
TERMINATIONS
N or B
N or B
N or B
G
G
www.vishay.com
58
For technical questions, contact: sfer@vishay.com
Document Number: 53018
Revision: 19-Aug-08
L
Ultra Low Value
Thin Film Resistors
PERFORMANCE
VALUES AND DRIFT
TESTS
CONDITIONS
MIL-R-55342 C
MIL-STD-702-Method 107
MIL-R-55342 C
PARA 3.10.4.7.5
MIL-R-55342 C
PARA 3.9 and 4.7.4
MIL-R-55342 C
PARA 3.12, 4.7.7, 4.7.1.2
MIL-R-55342 C
PARA 3.13 and 4.7.8
MIL-STD-202-Method 106
MIL-R-55342 C
PARA 3.11 and 4.7.6
MIL-R-55342 C
2000 h Pn at 70 °C
MIL-STD-202-Method 108
MIL-R-55342
REQUIREMENTS
± 0.25 %
± 0.10 %
± 0.25 %
± 0.25 %
TYPICAL
PERFORMANCES
± 0.02 %
± 0.01 %
± 0.01 %
± 0.04 %
Vishay Sfernice
Thermal shock
Short time overload
Low temperature operation
Resistance to solder heat
Moisture resistance
± 0.40 %
± 0.01 %
High temperature
± 0.20 %
± 0.075 %
Load life
± 0.50 %
± 0.15 %
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: L0805K1R00FBT0046
L
GLOBAL
MODEL
L
0
8
SIZE
0505
0603
0705
0805
1005
1206
1505
2010
0
5
TCR
K
1
R
VALUE
0
0
F
B
T
0
0
4
6
OPTION
leave
blank if
no option
TOLERANCE
F
=±1%
G
=±2%
H
=±3%
J
=±5%
K
= ± 10 %
TERMINATION
B:
SnPb over
nickel barrier
N:
SnAg over
nickel barrier
G:
gold over
nickel barrier
PACKAGING
(1)
blank:
Waffle pack
T:
Tape
and reel
H
= ± 50 ppm
K
= ± 100 ppm
L
= ± 200 ppm
M
= ± 300 ppm
R designated
decimal point
For values under 1R
if 3 significant digits:
Rxxx
if 2 significant digits:
xRxx
B:
Lead bearing version
N and G:
Lead (Pb)-free/
RoHS version
Historical Part Number example: L 0805 K 1R00 1 % B T R0046
L
MODEL
Note
(1)
0805
SIZE
K
TCR
1R00
VALUE
1%
TOLERANCE
B
TERMINATION
T
PACKAGING
(1)
R0046
OPTION
For specific quantity of parts per packaging please consult Sfernice
Document Number: 53018
Revision: 19-Aug-08
For technical questions, contact: sfer@vishay.com
www.vishay.com
59
