MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
TMOS FET Transistors
N–Channel — Enhancement
3 DRAIN
2
GATE
1 SOURCE
MPF6659
MPF6660
MPF6661
MAXIMUM RATINGS
Rating
Drain – Source Voltage
Drain – Gate Voltage
Gate–Source Voltage
— Continuous
— Non–repetitive (tp
≤
50
µs)
Drain Current
Continuous(1)
Pulsed(2)
Total Device Dissipation
@ TC = 25°C
Derate above 25°C
Total Device Dissipation
@ TA = 25°C
Derate above 25°C
Operating and Storage Junction
Temperature Range
Symbol
VDS
VDG
VGS
VGSM
ID
IDM
PD
2.5
20
PD
1.0
8.0
TJ, Tstg
– 55 to +150
Watts
mW/°C
°C
Watts
mW/°C
MPF6659
35
35
MPF6660
60
60
±
20
±
40
2.0
3.0
MPF6661
90
90
Unit
Vdc
Vdc
Vdc
Vpk
Adc
1
2
3
CASE 29–05, STYLE 22
TO–92 (TO–226AE)
ELECTRICAL CHARACTERISTICS
(TA = 25°C unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
OFF CHARACTERISTICS
Zero–Gate–Voltage Drain Current
(VDS = Maximum Rating, VGS = 0)
Gate–Body Leakage Current
(VGS = 15 Vdc, VDS = 0)
Drain–Source Breakdown Voltage
(VGS = 0, ID = 10
µAdc)
MPF6659
MPF6660
MPF6661
IDSS
IGSS
V(BR)DSX
35
60
90
—
—
—
—
—
—
—
—
—
—
10
100
µAdc
nAdc
Vdc
ON CHARACTERISTICS(2)
Gate Threshold Voltage
(VDS = VGS, ID = 1.0 mAdc)
Drain–Source On–Voltage
(VGS = 10 Vdc, ID = 1.0 Adc)
MPF6659
MPF6660
MPF6661
MPF6659
MPF6660
MPF6661
VGS(Th)
VDS(on)
—
—
—
—
—
—
—
—
—
0.8
0.9
0.9
1.8
3.0
4.0
1.5
1.5
1.6
0.8
1.4
2.0
Vdc
Vdc
(VGS = 5.0 Vdc, ID = 0.3 Adc)
1. The Power Dissipation of the package may result in a lower continuous drain current.
2. Pulse Test: Pulse Width
300
µs,
Duty Cycle
2.0%.
v
v
REV 2
Motorola Small–Signal Transistors, FETs and Diodes Device Data
4–93
MPF6659 MPF6660 MPF6661
ELECTRICAL CHARACTERISTICS
(TA = 25°C unless otherwise noted) (Continued)
Characteristic
Symbol
Min
Typ
Max
Unit
ON CHARACTERISTICS(2) (Continued)
Static Drain–Source On Resistance
(VGS = 10 Vdc, ID = 1.0 Adc)
rDS(on)
MPF6659
MPF6660
MPF6661
ID(on)
—
—
—
1.0
—
—
—
2.0
1.8
3.0
4.0
—
Amps
Ω
On–State Drain Current
(VDS = 25 Vdc, VGS = 10 Vdc)
SMALL– SIGNAL CHARACTERISTICS
Input Capacitance
(VDS = 25 Vdc, VGS = 0, f = 1.0 MHz)
Reverse Transfer Capacitance
(VDS = 25 Vdc, VGS = 0, f = 1.0 MHz)
Output Capacitance
(VDS = 25 Vdc, VGS = 0, f = 1.0 MHz)
Forward Transconductance
(VDS = 25 Vdc, ID = 0.5 Adc)
Ciss
Crss
Coss
gfs
—
—
—
170
30
3.6
20
—
—
—
—
—
pF
pF
pF
mmhos
SWITCHING CHARACTERISTICS(2)
Rise Time
Fall Time
Turn–On Time
Turn–Off Time
2. Pulse Test: Pulse Width
tr
tf
ton
—
—
—
—
—
—
—
—
5.0
5.0
5.0
5.0
ns
ns
ns
ns
v
300
µs,
Duty Cycle
v
2.0%.
toff
RESISTIVE SWITCHING
+25 V
23
Ω
PULSE GENERATOR
50
Ω
Vin
40 pF
50
Ω
20 dB
50
Ω
ATTENUATOR
TO SAMPLING SCOPE
50
Ω
INPUT
Vout
ton
90%
toff
90%
10%
90%
50%
INPUT
Vin
10%
PULSE
WIDTH
50%
10 V
1.0 MΩ
OUTPUT
V
INVERTED out
Figure 1. Switching Test Circuit
Figure 2. Switching Waveforms
4–94
Motorola Small–Signal Transistors, FETs and Diodes Device Data
MPF6659 MPF6660 MPF6661
2.0
V GS(th), THRESHOLD VOLTAGE
1.6
VDS = VGS
ID = 1.0 mA
I D(on) , DRAIN CURRENT (AMPS)
2.0
VGS = 10 V
1.6
9.0 V
8.0 V
1.2
7.0 V
6.0 V
5.0 V
0.4
4.0 V
0
–50
0
100
50
TJ, JUNCTION TEMPERATURE
150°C
0
1.0
2.0
3.0
VDS, DRAIN – SOURCE VOLTAGE (VOLTS)
4.0
1.2
0.8
0.8
0.4
Figure 3. VGS(th) Normalized versus Temperature
Figure 4. On–Region Characteristics
2.0
I D(on) , DRAIN CURRENT (AMPS)
VGS = 10 V
9.0 V
8.0 V
C, CAPACITANCE (pF)
100
1.6
80
VGS = 0 V
1.2
7.0 V
0.8
6.0 V
0.4
5.0 V
4.0 V
0
20
10
30
VDS, DRAIN – SOURCE VOLTAGE (VOLTS)
40
60
40
Ciss
20
Coss
Crss
0
10
40
50
60
20
30
VDS, DRAIN – SOURCE VOLTAGE (VOLTS)
Figure 5. Output Characteristics
Figure 6. Capacitance versus
Drain–To–Source Voltage
V DS , DRAIN–SOURCE VOLTAGE (VOLTS)
10
5.0
VGS = 10 V
ID = 1.5 A
1.0 A
0.5 A
1.0
0.5
0.4
0.3
0.2
0.1
–50
–30
–10
90
110
10
30
50
70
TJ, JUNCTION TEMPERATURE (°C)
130
150
Figure 7. On–Voltage versus Temperature
Motorola Small–Signal Transistors, FETs and Diodes Device Data
4–95
