684-60-S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Topical application> Test and measurement> 684-60-S

684-60-S: DescriptionLEAD TEST ALLIG CLIP 60" SET/10; CategoryTopical application Test and measurement; File Size33KB，1 Pages; ManufacturerE-Z-HOOK; Environmental Compliance

Download Datasheet Parametric Compare View All

684-60-S Overview

LEAD TEST ALLIG CLIP 60" SET/10

684-60-S Parametric

Parameter Name	Attribute value
Configuration	short alligator clip to short alligator clip
first connector	Terminal clamp, insulated
Second connector	Terminal clamp, insulated
cable length	60.0"（1524.00mm）
content	10 leads, multiple colors
Material - Insulation	Polyvinyl chloride (PVC)
Wire gauge	18 AWG
Voltage - Rated	5000VDC（5kV）
Rated current	4A
temperature range	221°F（105°C）

Preview

Download Datasheet

View All

REVISIONS

LTR

DESCRIPTION

DATE

APPROVED

UNLESS OTHERWISE SPECIFIED

DIMENSIONS ARE IN INCHES

TOLERANCES ARE:

FRACTIONS DECIMALS ANGLES

.XX ±

.XXX ±

CONTRACT NO.

APPROVALS

DRAWN

MATERIAL

APPROVED BY

DATE

DESCRIPTION

DIVISION OF TEKTEST INC.

ARCADIA, CA 91006 U.S.A.

FINISH

NEXT ASSY

USED ON

APPLICATION

DO NOT SCALE DRAWING

SIZE

CODE IDENT NO. DRAWING NO.

DRAWING NO.

REV.

A 08505

SCALE

SHEET

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY TO E-Z-HOOK. THE INFORMATION IS NOT TO BE REPRODUCED WITHOUT PRIOR WRITTEN PERMISSION OF E-Z-HOOK, DIV. OF TEKTEST INC.

MAXIMUM TESTED RATINGS IN A HANDS-FREE CONTROLLED ENVIRONMENT. MAXIMUM RATINGS ARE NOT TO BE USED CONCURRENTLY.

684-60-S Related Products

	684-60-S	684-24BLU	684-12-S	684-36-S	684-24-S	684-36 R/B	684-60 R/B	684-12 R/B	684-24 R/B
Description	LEAD TEST ALLIG CLIP 60" SET/10	LEAD TEST ALLIG CLIP 24" BLUE	LEAD TEST ALLIG CLIP 12" SET/10	LEAD TEST ALLIG CLIP 36" SET/10	LEAD TEST ALLIG CLIP 24" SET/10	LEAD TEST ALLIG CLIP 36" RED/BLK	LEAD TEST ALLIG CLIP 60" RED/BLK	LEAD TEST ALLIG CLIP 12" RED/BLK	LEAD TEST ALLIG CLIP 24" RED/BLK
Configuration	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip	short alligator clip to short alligator clip
first connector	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated
Second connector	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated	Terminal clamp, insulated
cable length	60.0"（1524.00mm）	24.0"（609.60mm）	12.0"（304.80mm）	36.0"（914.40mm）	24.0"（609.60mm）	36.0"（914.40mm）	60.0"（1524.00mm）	12.0"（304.80mm）	24.0"（609.60mm）
content	10 leads, multiple colors	1 lead, blue	10 leads, multiple colors	10 leads, multiple colors	10 leads, multiple colors	2 leads, black and red	2 leads, black and red	2 leads, black and red	2 leads, black and red
Material - Insulation	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)
Wire gauge	18 AWG	18 AWG	18 AWG	18 AWG	18 AWG	18 AWG	18 AWG	18 AWG	18 AWG
Voltage - Rated	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）	5000VDC（5kV）
Rated current	4A	4A	4A	4A	4A	4A	4A	4A	4A
temperature range	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）	221°F（105°C）
