DESCRIPTION: QUIK-LOQ - FEMALE - RIGHT ANGLE - PANEL MOUNT - IP67
M16*1.0
0.118
3.00
0.236
6.00
(MAX. PANEL THICKNESS)
0.787
20.00
UNITS = MM [INCHES]
CHARACTERISSTICS
MATERIALS
SHELL : BRASS
SHELL PLATING : NICKEL
NUT : BRASS
NUT PLATING : NICKEL
LATCH SLEEVE : BRASS
LATCH SLEEVE PLATING : NICKEL
CONTACTS : COPPER ALLOY
CONTACT PLATING : 7µ" GOLD PLATED OVER 196µ" NICKEL MIN.
INSULATOR : PPS (HIGH TEMPERATURE)
O-RING: SILICONE
MECHANICAL
DURABILITY: 5000 CYCLES
OPERATING TEMP. RANGE: -40 C ~ +200 C
PROCESS TEMPERATURE : 260 C FOR 5 SECONDS
MAX. TORQUE VALUE : 7.0 Nm [61.0 IN/lbs]
SHIELDING: 75dB @ 10MHz
40dB @ 1GHz
IP RATING: 67
0.945
24.00
0.394
10.00
821K R YY - 2 1 3 R 00 1
SERIES
13.00 [0.512]
R = RIGHT ANGLE
0.787
20.00
1 = GOLD FLASH
RoHS COMPLIANT
NICKEL/CHROME PLATED SHELL
BOARD MOUNT (PANEL MOUNT)
# OF POSITIONS
(Ex. 002)
**SEE CHART A**
2 = FEMALE
**NOTE**
SEE PAGE 2 FOR BOARD LAYOUTS
CHART A
1
1
= KEY LOCATION
1
1
**VIEW FROM TERMINATION END**
1
1
63
[0.
.10
16
4]
2 POSITION
15 AMP MAX.
PIN
= 1.30 [0.051]
3 POSITION
12 AMP MAX.
PIN
= 1.30 [0.051]
4 POSITION
7 AMP MAX.
PIN
= 0.70 [0.028]
5 POSITION
6.5 AMP MAX.
PIN
= 0.70 [0.028]
6 POSITION
2.5 AMP MAX.
PIN
= 0.50 [0.020]
7 POSITION
2.5 AMP MAX.
PIN
= 0.50 [0.020]
0.575
14.60
CONTACT
RESISTANCE
= 5 m
Ω
TEST VOLTAGE
= 1500V
WORKING VOLTAGE
= 500V
CONTACT
RESISTANCE
= 5 m
Ω
TEST VOLTAGE
= 1300V
WORKING VOLTAGE
= 430V
CONTACT
RESISTANCE
= 7.5 m
Ω
TEST VOLTAGE
= 850V
WORKING VOLTAGE
= 280V
CONTACT
RESISTANCE
= 7.5 m
Ω
TEST VOLTAGE
= 850V
WORKING VOLTAGE
= 280V
CONTACT
RESISTANCE
= 10 m
Ω
TEST VOLTAGE
= 850V
WORKING VOLTAGE
= 280V
CONTACT
RESISTANCE
= 10 m
Ω
TEST VOLTAGE
= 800V
WORKING VOLTAGE
= 260V
PANEL CUTOUT
TOLERANCE = +0.10, -0.0
[+0.004, -0.00]
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
DRAWN:
DATE:
SCALE:
SHEET
OF
REV:
M. SIGMON
CHECKED:
DATE:
02-29-16
N.T.S.
1
DWG NO.
2
2
821KRYY-213R001
DESCRIPTION:
QUIK-LOQ - FEMALE - RIGHT ANGLE - PANEL MOUNT - IP67
UNITS = MM [INCHES]
BOARD LAYOUTS
= KEY LOCATION
0.100
2.54
TYP.
5
3
0.200
5.08
4
0.100
2.54
0.050
1.27
0.100
2.54
3
4
1
A
2
1
2
0.100
2.54
0.100
2.54
1
2
1
3
2
0.100
2.54
OF
2 POS
HOLE
= 0.80 [0.031]
HOLE
3 POS
= 0.80 [0.031]
HOLE
4 POS
= 0.80 [0.031]
HOLE
5 POS
= 0.80 [0.031]
0.100
2.54
TYP.
5
6
0.200
5.08
0.100
2.54
4
0.200
5.08
0.100
2.54
6
7
1
2
5
4
1
2
3
3
6 POS
HOLE
= 0.80 [0.031]
HOLE
7 POS
= 0.80 [0.031]
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
DRAWN:
DATE:
SCALE:
SHEET
REV:
M. SIGMON
CHECKED:
DATE:
02-26-16
N.T.S.
2
DWG NO.
2
2
821KRYY-213R001
