Datasheet for 76650-0136
General Information
76650-0136
Part Number:
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Mini Mi II Connector Kit
IDT Panel Mount Adaptor and Receptacle
Mini Mi II™
(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
Mini Mi II™ wire harness system is designed for high-density harness applications.
Mini Mi II provides the same 1.5 amperes of current as similar 2.00mm (.079") pitch
systems, but in a more compact design. Molex's Integrated Product Division
provides the new Mini MiII system in both wire-to-board and wire-to-wire options
with different custom lengths and wire configurations enabling multi-branch
harnessing configurations, similar to Molex's existing 2.00mm (.079") pitch MiII
system. The system saves about 45% of PCB space compared to 2.00mm MiII.
Mini MiII is available in 2 to 40 circuits in single/dual row and SMT/through-hole
styles.
Features and Benefits
• 1.5 amps meets office automation
standards
• Internal positive lock for secure retention
• IDT housing for cost effective termination
Applications
• Security devices
• Car audio, car multimedia, car HVAC
• Office equipment
• Set-up boxes
Wire-to-Wire
1.25mm (.049")
IDT Receptacles and Adaptors
2, 4, 8, 14, 18 and 20
1.5 Amps
100 Volts
28-26 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0136
Bill of Materials for Part No. 76650-0136
Country
Molex Part No. of Origin
54596-0210
54596-0410
54596-0810
54596-1410
54596-1810
54596-2010
55482-0219
55482-0419
55482-0819
55482-1419
55482-1819
55482-2019
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Description
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 2 Circuits
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 4 Circuits
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 8 Circuits
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 14 Circuits
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 18 Circuits
1.25mm (.049") Pitch Mini Mi II IDT receptacle, 20 Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 2
Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 4
Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 8
Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 14
Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 18
Circuits
1.25mm (.049") Pitch Mini Mi II™ Wire-to-Wire Adapter, 20
Circuits
Quantity in
Kit
10
10
10
10
10
10
5
5
5
5
5
5
No Recommended Molex Tool for Part No. 76650-0136
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
