CX7-AC01-E3-KIT: DescriptionCAP KIT CER 1000PF-47UF 240PCS; CategoryDevelopment board/suite/development tools; File Size106KB，2 Pages; ManufacturerTDK Corporation; Websitehttp://www.tdk.com; Environmental Compliance

Download Datasheet Parametric View All

CX7-AC01-E3-KIT Overview

CAP KIT CER 1000PF-47UF 240PCS

CX7-AC01-E3-KIT Parametric

Parameter Name	Attribute value
Kit type	ceramics
Capacitance range	1000pF ~ 47µF
Installation type	Surface mount, MLCC
Voltage - Rated	6.3 ~ 50 V
Tolerance	±10%， ±20%
application	Universal
characteristic	-
quantity	240 pieces (24 values - 10 pieces each)
Includes packaging	0402 ~ 2220 (1005 ~ 5750 metric)

Preview

Download Datasheet

View All

C Series—General Applications MLCC Kit

Consumer Grade General Applications Capacitor Kit

TDK’s X7R and X7S (125

C) MLCCs provide extremely dependable performance when

subjected to industrial grade temperature extremes. Through an advanced manufacturing process, TDK oﬀers

MLCCs with a unique monolithic structure to ensure superior mechanical strength and reliability. Low electric

permi vity materials are used to promote less DC bias dependence when compared to X5R (85

C) products.

This also provides improved circuit func on due to lower ESR and ESL characteris cs. Speciﬁcally, TDK’s newer

X7S ceramics provide smaller grains and increased packing density to promote longer system life and higher

capacitance in smaller packages. Both X7R and X7S capacitor are op mally suited for a variety of applica ons.

Features



Low electric permittivity materials, which have less DC bias

dependence

Unique monolithic structure to ensure superior mechanical strength

and reliability

X7S items provide smaller grains and increased packing density to

promote longer system life and higher capacitance in small

packages

Improved circuit function due to lower ESR and ESL characteristics

125°C (X7R/X7S)

Up to 50V

Consumer



Datasheet

Applications



General Electronic Equipment

LED Lighting



DC-DC Converters

Office Automation Equipment

Network Infrastructure: Servers, Switchers, Routers, etc.

Portable Electronics: Notebooks, Tablets, etc.



CX7-AC01-E3-KIT General Applications Kit Includes:

Case Size:

1005-5750 (EIA 0402-2220)

Rated Voltage:

6.3V-50V

Capacitance Range:

1000pF-47µF

Now Available at:

Click the Digi-Key logo for ordering information

Rev. 1—September 2015
