DZN
ELECTRIC DOUBLE LAYER CAPACITORS “DYNACAP”
GREEN
CAP
70˚C
Low ESR
High power type Capacitors
• Low internal resistance allows boosting charge and heavy-current discharge.
(ampere level)
• Pollution-Free ; with no pollutants such as Cd or Pb.
High power
• Unlimited number of charges
and discharges.
DZN
DZ
Marking color :
White print on a blue sleeve
Specifications
Item
Category temperature range (˚C)
Tolerance at rated capacitance (%)
Performance
−25
to
+70
−20
to
+80
Rated Capacitance (F)
Internal resistance (Ω)
0.7
0.4
1.0
0.3
3.3
0.2
4.7
0.10
10
0.10
20
0.10
50
0.03
100
0.03
Internal resistance
at 1 kHz
Characteristics at high
and low temperature
Percentage of capacitance change
Internal resistance
Within
±30%
of value at 20˚C
Less than five times of the value at 20˚C
Test time
Endurance (70˚C)
Percentage of capacitance change
Internal resistance
Shelf life (70˚C)
1000 hours
Within
±30%
of the initial measured value
Within four times of the initial specified value
Test time :1000 hours ; Same as endurance.
Outline Drawing
Unit: mm
d±0.05
copper clad steel wire(tinned)
8 to
Vent
D+0.5max.
18
Sleeve
25, 35
Sleeve
2– 2
Lug terminal details
0.9±0.1 Thickness:0.8t
2.6
6.8
10
10
±
0
.1
D+1max.
F±0.5
Markings
1.5±0.1
L+α max.
15min.
5
min.
L+2max.
øD
F
ød
α
8
3.5
0.6
12.5
5.0
2.0
18
7.5
0.8
Vent
6.3±1
(–)Negative terminal
indicated by cross notching
Position of printed
circuit board holes
2.1
Standard Ratings
Max. operating voltage(V)
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Rated capacitance(F)
0.7
1.0
3.3
4.7
10
20
50
100
Max. Leakage Current(mA) after 24h
0.1
0.1
0.2
0.3
0.5
0.8
1.0
1.0
ELNA Parts No.
DZN-2R5D704G4T
DZN-2R5D105T
DZN-2R5D335T
DZN-2R5D475T
DZN-2R5D106T
DZN-2R5D206T
DZN-2R5D506T
DZN-2R5D107T
ø DxL(mm)
8.0x15.0
8.0x22.0
12.5x23.0
12.5x31.5
18.0x35.0
18.0x40.0
25.0x40.0
35.0x50.0
Internal resistance(mΩ)
at 1kHz (measurement value)
200
100
40
30
20
20
15
8
∗
Internal resistance are not guaranteed values, but measurement value.
∗
We tailor packaged product in series and parallel arrangements according to voltage and capacitance as required.
Part numbering system (example: 2.5V10F)
DZN
Series code
—
2R5
Rated voltage
symbol
D
106
Rated capacitance
symbol
T
CAT.No.2005/2006E(2005.10.1)
152
NOTE
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
