BL620 Series
Central Mode BLE Module Featuring
smart
BASIC
The BL600 Series modules from Laird
have been enhanced with the addition
of the BL620 part numbers. The
BL620 uses the same module
hardware as the BL600 but has a new
firmware supporting Central mode connectivity.
The BL620 makes it easy to add single-mode Bluetooth Low Energy (BLE), also
known as Bluetooth Smart™, to small, portable, power-conscious devices,
including those powered by AAA or coin cell batteries.
The unique feature of this module is
smart
BASIC, an event-driven programming
language that enables standalone operation of the module.
smart
BASIC on BL620
enables wireless connections to peripheral devices that are in turn connected to
sensors so that the data can be collected via GATT operations.
smart
BASIC has
been proven to speed time to market and significantly simplifies BLE integration
for embedded devices.
Based on the award winning Nordic Semiconductor nRF51822 chipset, BL620
modules provide exceptionally low power consumption with outstanding wireless
range, all within a compact footprint of 19 mm x 12.5 mm. The modules
incorporate all the hardware and firmware required to support development of
BLE Central mode applications, including:
Radio hardware
UART, SPI, I2C, ADC, and GPIO interfaces for connecting peripherals and
sensors
A complete BLE software stack
Central role functionality with GATT client and server
-
Ability to connect up to four simultaneous connections
Custom Services to suit any application’s needs
Series addition of a packaged USB Dongle - BL620-US
Support Portal:
http://ews-support.lairdtech.com
USA: +1.800.492.2320
Europe: +44.1628.858.940
Asia: +852.2268.6567
wirelessinfo@lairdtech.com
www.lairdtech.com/bluetooth
The BL620-US USB Dongle has been developed to take advantage of the BL620
module, providing the ability to add BLE Central Mode capabilities to Windows
operating systems supporting a USB interface and virtual COM port. The control
and configuration is via a standard virtual COM port and
smart
BASIC. The dongle
provides the ability to load smartBASIC applications over the air (OTA) to a BL600
peripheral mode module.
In addition to carrying FCC modular, IC, and CE approvals, BL620 modules are
fully qualified as a Bluetooth End Products, enabling designers to integrate the
modules in devices without the need for further Bluetooth Qualification testing.
Customers can use the DVK-BL600 series low-cost developer’s kit including simple
software tools to develop with the BL620 central mode firmware.
BL620 Series
Central Mode BLE Module Featuring
smart
BASIC
CATEGORIES
Wireless Specification
FEATURE
Bluetooth®
Frequency
Max Transmit Power
Receive Sensitivity
Whisper Mode
Link Budget
Raw Data Rates
Total
UART
IMPLEMENTATION
V4.0 – Single-Mode – Central mode
2.402 - 2.480 GHz
4dBm
-91dBm (typical)
Down to -55dBm (Transmit)
95 dB (@ 1 Mbps)
1 Mbps (over the air)
28 lines – multi function
TX, RX, CTS, RTS
DTR, DSR, DCD, RI can be implemented in
smar
tBASIC
(CTS, RTS, DTR, DSR, DCD, and RI are NOT connected on
the BL620-US)
Default 9600, N, ,8, 1
From 1,200 to 115,200bps
Up to 28 lines
3 lines
2 lines
6 lines (plus ADC reference)
GATT Client and Server Capability
Any that can be implemented using
smart
BASIC
128 bit using CCM encryption
1.8V – 3.6V – internal LDO
2.1V – 3.6V – internal DCDC converter
‘System Idle’ – 3.5uA
‘Transmit’ – 10.5mA @ 0dBm
19mm x 12.5mm x 3mm
-40° to +85° C when powered at 3.3 V +/- 10%
-25° to +75° C when powered at 1.8V
(contact Laird for any query)
-40°C to +85°C
Lead-free and RoHS compliant
Limited Lifetime Warranty
Development board and free Software Tools **
End Product Listing (EPL)
All BL620 Series
Host Interfaces
GPIO
SPI
I2C
ADC
Services
Control Protocols
Encryption
Supply Voltage
Power Consumption
Physical
Environmental
AES
Supply
Current
Dimensions
Operating Temperature
Storage Temperature
Lead Free
Warranty
Development Kit
Bluetooth®
FCC / IC / CE
Miscellaneous
Development Tools
Approvals
*The details contained within the document are subject to change. Download the product specification from
www.lairdtech.com/bluetooth
for the most current specification.
Ordering Information
BL620-SA-0x
BL620-SC-0x
BL620-ST-0x
BL620-US-0x
DVK-BL600-SA / ST / SC-0x
Single Mode BLE Module featuring
smart
BASIC (internal antenna)
Single Mode BLE Module featuring
smart
BASIC (IPEX MHF4 antenna connector)
Single Mode BLE Module featuring
smart
BASIC (trace pin)
Packaged BL620 USB Dongle
Development kit for each BL620 series module
**Use
standard DVK-BL600 and upgrade the firmware
Version
1.0
Date
10/15/14
Description
Initial Release
Approver
JK
