Application
Dialight Optopipe
®
actuator extensions are designed for use with
C&K K5V2 lighted tactile switches. These snap-in clear lenses do not
need to sit on the edge of a PCB and is offered in a verity of sizes to
accommodate a range of panel depths. Dialight Optopipe
actuator extensions are ideal for server, storage, network infrastructure,
automotive, and medical applications.
Optopipe
®
Lightpipe
Actuator Extensions
“L” (SEE NOTES)
.315
(8
)
.177
(4.5
)
Ø.240
(6.1
)
Ø.157
(4
)
.065
(1,65
)
.035 (0,89
)
SUPPORT PERMISSIBLE
.010 MAX (4PLCS)
ITT/CONNON
K5V SWITCH
(REF. ONLY)
Ø.200
(5,08
)
Ø.240
(6.1
)
Ø.157
(4
)
R.010
(0,25
)
.050
(1,27
)
“L” (SEE NOTES)
3.15
(8
)
.177
(4,5
)
Ø.240
(6.1
)
ITT/CONNON K5V SWITCH
(REF. ONLY)
Order Code
515-114 X-
XXX
-F
.065
(1,65
)
Ø.118
(3
)
TYP
Ø.240
(6.1
)
.035
(0,89
)
SUPPORT PERMISSIBLE
.010 MAX (4PLCS)
Length in (mm)
Diameter (mm)
Ø.197
(5
)
Part Numbers: 4mm diameter
Part Number
Length
10mm
12mm
12.5mm
13mm
19.5mm
22.5mm
23.5mm
25mm
515-1140-100F
515-1140-120F
515-1140-125F
515-1140-130F
515-1140-195F
515-1140-225F
515-1140-235F
515-1140-250F
Part Numbers: 3mm diameter
Part Number
515-1149-145F
Length
14.5mm
Ø.118
(3
)
Features & Benefits
•
•
•
•
•
•
•
Fits C&K K5V2 illuminated LED switch
Available in 3mm and 4mm diameters
Variable length from 10mm to 25mm
RoHS compliant
Custom color options available (consult factory)
Custom length options available (consult factory)
Opaque colors available for use with C&K K5V2
nonilluminated switches
Dialight reserves the right to make changes at any time in order to supply the best product possible.
The most current version of this document will always be available at:
http://www.dialight.com/Assets/Brochures_And_Catalogs/Indication/MDELPE515X001.pdf
MDELPE515X001_A
