SAW Components
SAW Duplexer
Datasheet
Application
s
Low-loss SAW duplexer for mobile telephone
s
s
s
s
s
s
B8572
782.0 / 751.0 MHz
LTE Band 13 systems
Low insertion attenuation
High isolation
Usable passband 10 MHz
Single-ended to balanced transformation in Anten-
na-Rx path
Impedance transformation 50
Ω
to 100
Ω
in Anten-
na-Rx path
Very small size and low height
Features
s
s
s
s
s
s
s
0.3
1
2
3
0.35
0.475 max.
Package size 1.8 * 1.4 mm
2
Package height: maximum 0.475 mm
RoHS compatible
Package for
Surface Mount Technology
(SMT)
Ni, Au-plated terminals
Electrostatic Sensitive Device
(ESD)
Moisture Sensitivity Level
3
0.7
7
6
5
0.25
0.25
4
8
4
bottom view
side view
1.8
7
6
5
1.4
8
top view
1
2
3
Pin configuration
s
s
s
s
3
1, 8
6
2, 4, 5, 7
Tx input
Rx output (balanced)
Antenna
To be grounded
Please read
cautions and warnings and
important notes
at the end of this document.
2
June 19, 2013
SAW Components
SAW Duplexer
Datasheet
Characteristics
Temperature range for specification:
TX terminating impedance:
ANT terminating impedance:
RX teminating impedance:
Characteristics Tx-Antenna
Center frequency
Maximum insertion attenuation
777.0 ... 787.0
Amplitude ripple
(p-p)
777.0 ...
787.0
f
c
α
MHz
∆α
MHz
MHz EVM
1)
MHz EVM
1)
-
-
-
0.7
3.4
3.4
1.5
4.0
4.5
dB
%
%
-
1.8
2.5
dB
T = –30 ˚C to +85 ˚C
Z
Tx
= 50
Ω
Z
Ant
= 50
Ω
|| 15 nH
Z
Rx
= 100
Ω
(balanced)
min.
typ.
@ 25 ˚C
782.0
max.
MHz
B8572
782.0 / 751.0 MHz
Error Vector Magnitude @ 25˚C
@ f
Carrier
779.4 ... 784.6
Error Vector Magnitude
@ f
Carrier
779.4 ...
Input VSWR (Tx port)
777.0 ...
Output VSWR (Ant Port)
777.0 ...
784.6
787.0
787.0
MHz
MHz
-
-
1.3
1.5
2.0
2.0
Harmonic Level CW tone @ 782 MHz
2)
Second Harmonic at 1564 MHz
-
-55
-38
3)
dBm
1)
2)
3)
Error Vector Magnitude (EVM) based on definition in 3GPP TS 25.141
Power level +28 dBm at Tx port
Guaranteed by design (no 100% testing in production)
Please read
cautions and warnings and
important notes
at the end of this document.
3
June 19, 2013
