ZH
Solenoid Tumbler ZH
The solenoid tumbler ZH is,
in combination with the functio-
nal handles on page 268 to 303
a electromechanical locking sys-
tem for pushable and revolving
doors.
Design and mode
of operation:
On the solenoid tumbler, the
switching element with interlock
is not physically connected to
the actuator, but functionally
separated or brought together
on opening or closing of the
door. Interlocking is carried out
by a latching bolt, which
prevents the actuator from being
pulled out of the interlock.
By opening and closing the door,
switching contacts in the
interlock are positively operated.
Altogether states like door
open/closed or door locked/
unlocked can be found out over
these switching contacts.
Power to unlock/
Power to lock:
Two variations of interlocking are
offered.
In the case of power to unlock,
the latching bolt prevents the
actuator from being pulled out
by spring pressure. When the
deinterlocking coil is energized,
the interlock is removed.
The guarding device can be
opened.
For power to lock, the mode of
operation is reserved.
Note:
Interlocks in other contact
variations and further actuators
on request.
Solonoid tumbler
ZH-01
26
6
Actuator opening
ZH-02
6
90
6
72
13
44
32
2,3
8
29
Manual unlocking
7
Cable junction
6
6
5,5
35
15
6
Actuator
opening
12
Actuator opening
72
Cable junction
116
56
30
Manual
unlocking
8
30
M20
130
29,5
22,5
6
22
12
17,5 23,5
Movable actuators
ZH-01
15
°
ZH-02
48
6,5
57,5
8,5
16
32
25
ø 5,5
40
R min
11
. 95
60
16,5
R min
. 350
39
13,5
Typ
ZH-01
Components
Solenoid tumbler
Modes of interlock
Power to unlock
Arbeitsstromprinzip
Power to lock
38
15°
44
Order no.
ZH-01.R01.01
ZH-01.A01.01
ZH-01.000.02
Actuator
ZH-02
Solenoid tumbler
Power to unlock
Power to lock
Actuator
ZH-02.R01.01
ZH-02.A01.01
ZH-02.000.02
www.daviesmolding.com
3
15
°
15
°
178
Technical data
Typ
Standards:
Enclosure:
Actuator and locking bolt:
Contact material:
Protection class:
Termination:
Cable section:
Cable entry:
Rated impulse withstand voltage U
imp
:
Rated insulation voltage U
i
:
Thermal test current I
the
:
Rated operating current/ voltage I
e/Ue
:
Rated control voltage U
s
:
Ambient temperature:
Holding force F max:
Actuating head:
ZH-01
IEC/EN 60947-5-1, BG-GS-ET-19,
IEC 60947-5-1
glass fibre reinforced thermoplastic
stainless steel 1.4301
Silver
IP 67
ZH-02
IEC/EN 60947-5-1, BG-GS-ET-19,
IEC 60947-5-1
glass fibre reinforced thermoplastic
Zinc plated steel / zinc diecast, chromated
Silver
IP 67
ZH
Screw clamps
Screw clamps
max. 1.5 mm
2
(incl. Conductor ferrules) max. 1.5 mm
2
(incl. Conductor ferrules)
4 x M16 x 1,5
4 kV
250 V
10 A
2,5 A / 24 VDC
24 VAC/DC
- 25°C......+ 60°C
2000 N
2 x M20 x 1,5
2,5 kV
250 V
10 A
5 A / 24 VDC
24 VDC
0°C......+ 50°C
1750 N
3 Actuator openings
Can be repositioned by 4 x 90°
Manual release
for manual unlocking by
triangular key
emergency exit device and
emergency release optional available
for manual unlocking by
triangular key
emergency release available optionally
Modes of tumbler
Power to unlock
ZH-01
A1
A2
13
21
41
14
22
42
51 71 63
ZH-02
33 21
52 72 64
34 22
A1
A2
11
12
Power to lock
A1 51 71 63
33 21
A2
13
21
41
14
22
42
52 72 64
34 22
A2
11
12
A1
All dimensions in mm.
