ITEM
1
2
3
4
5
6
Q'TY
1
1
1
1
1
2
PART NUMBER
PM5-XXX
5XXX
BWS24-1007-RD
BWS24-1007-BK
2665S020000
2653TPB0001
PART DESCRIPTION
LED Holder, Panel Mount, Press Fit, (5mm)
PM5 (Standard LED), PM5-5V (5V LED), & PM5-12V (12V LED)
T-1¾ (5mm) Non-Flange LED, See Page 2.
24AWG Wire Lead U.L. 1007, Red
24AWG Wire Lead U.L. 1007, Black
Leoco 2665 Series 2.54 (.100") Crimp Type Socket, 1x
Leoco Terminal# 2653TPB0001 (Reel), 2653TPB00A1 (Bulk)
REV.
DESCRIPTION
DATE
APPROVED
D
Updated 5XXXL Specs
06/26/09
E
Added PM5BWCWX.X-CC Specs
08/14/09
F
Added PM5UGCWX.X-CC Specs
08/19/09
G
Added 5BC-Y/G Specs
02/09/10
H
LED Updates
01/19/11
J
Updated BOM Item #1 and Updated LED offering
11/13/12
09/15/15
K
Updated LED Optical Characteristics
T. Y.
T. Y.
T. Y.
T. Y.
T. Y.
T. Y.
J. C.
0.190 [4.8mm]
0.030 [0.8mm]
0.530 [13.5mm]
X.X
0.550 [14.0mm]
0.20 [5.1mm]
0.10 [2.5mm]
Ø.280 [Ø7.1mm]
Flange
SINGLE
COLOR
5V
or
12V
(+) Red
Wire
BI-COLOR
2
1
0.12 [3.0mm]
Ø.190 [Ø4.8mm]
LED
0.10 [2.54mm]
2
1
2
1
( ) Black
Wire
2
1
2
1
3
4
5 6
Ø.245 [Ø6.2mm]
Body
BI-COLOR POLARITY
LED P/N (2) Cathode (1) Cathode
5BC
5BC-Y/G
5BC-R/Y
5BC-A/G
Green
Green
Yellow
Green
Red
Yellow
Red
Amber
Ø.250+.003
-.002
EXAMPLE:
PM5RDW6.5*-CC
Connector
Wire Length "X.X"
LED Color & Lens Appearance.
Series
Recommended Mounting Hole
ABSOLUTE MAXIMUM RATINGS (Ta = 25°C)
REVERSE VOLTAGE
REVERSE CURRENT ( VR=5V)
OPERATING TEMPERATURE RANGE
STORAGE TEMPERATURE
LEAD SOLDERING TEMPERATURE (1/16" FROM BODY)
5V
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
DECIMALS
ANGULAR
®
100
µ
A
-25°C ~ 85°C
-30°C ~ 100°C
260°C for 5 Seconds
.X
.XX
.XXX
DESIGNED:
± .1
± .02
± .010
X°
± 1°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
DATE:
Dan Beckman
CHECKED:
06/28/07
DATE:
TITLE:
T-1¾ (5mm) PANEL MOUNT ASSEMBLY
REVISION:
PART NO:
PM5XXWX.X-CC
CAGE CODE : 32559
K
T. Yin
06/28/07
SHEET #
1
OF
4
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
REV.
DESCRIPTION
DATE
APPROVED
SEE SHEET #1.
LED Assy.No.
PM5BWCWX.X‐CC
PM5BWDWX.X‐CC
PM5BWTWX.X‐CC
PM5GCWX.X‐CC
PM5GDWX.X‐CC
PM5GTWX.X‐CC
PM5PGCWX.X‐CC
PM5PGDWX.X‐CC
PM5PGTWX.X‐CC
PM5YCWX.X‐CC
PM5YDWX.X‐CC
PM5YTWX.X‐CC
PM5ACWX.X‐CC
PM5ADWX.X‐CC
PM5ATWX.X‐CC
PM5HCWX.X‐CC
PM5HDWX.X‐CC
PM5HTWX.X‐CC
PM5RCWX.X‐CC
PM5RDWX.X‐CC
PM5RTWX.X‐CC
PM5BCWX.X‐CC‐A/G
PM5BCWX.X‐CC
PM5BCWX.X‐CC‐R/Y
PM5BCWX.X‐CC‐Y/G
Material
GaN/SiC
GaN/SiC
GaN/SiC
GaP/GaP
GaP/GaP
GaP/GaP
GaP/GaP
GaP/GaP
GaP/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaAsp/GaP
GaP/GaP
GaP/GaP
GaP/GaP
GaAsp/GaP
GaP/GaP
GaAsp/GaP
GaP/GaP
GaAsp/GaP
GaP/GaP
GaAsp/GaP
GaP/GaP
Chip
Peak
Wave
Length
430
430
430
568
568
568
555
555
555
590
590
590
605
605
605
625
625
625
700
700
700
605
568
625
568
625
590
590
568
Emitted Color
BLUE
BLUE
BLUE
GREEN
GREEN
GREEN
PURE GREEN
PURE GREEN
PURE GREEN
YELLOW
YELLOW
YELLOW
AMBER
AMBER
AMBER
HE RED
HE RED
HE RED
RED
RED
RED
AMBER
GREEN
RED
GREEN
RED
YELLOW
YELLOW
GREEN
Lens
Appearance
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WHITE DIFFUSED
WHITE DIFFUSED
WHITE DIFFUSED
WHITE DIFFUSED
Electro‐Optical Data @20mA
Vf
lf
lv
(V)
(mA)
(mcd)
MAX
TYP
MAX
TYP
25
4.0
4.5
25
25
4.0
4.5
15
25
4.0
4.5
30
30
2.1
2.8
40
30
2.1
2.8
25
30
2.1
2.8
40
30
2.2
2.8
10
30
2.2
2.8
10
30
2.2
2.8
10
30
2.0
2.8
40
30
2.0
2.8
25
30
2.0
2.8
40
30
2.0
2.8
40
30
2.0
2.8
25
30
2.0
2.8
40
30
2.0
2.8
40
30
2.0
2.8
25
30
2.0
2.8
40
20
2.1
2.8
2
20
2.1
2.8
2
20
2.1
2.8
2
30
2.0
2.8
6
30
2.1
2.8
6
30
2.0
2.8
6
30
2.1
2.8
8
30
2.0
2.8
6
30
2.0
2.8
5
30
2.0
2.8
5
30
2.1
2.8
8
Viewing
Angle
2 θ 1/2
(Deg)
20
45
20
35
45
35
35
45
35
35
45
35
35
45
35
35
45
35
35
45
35
45
45
45
45
LED P/N
5BWC
5BWD
5BWT
5GC
5GD
5GT
5PGC
5PGD
5PGT
5YC
5YD
5YT
5AC
5AD
5AT
5HC
5HD
5HT
5RC
5RD
5RT
5BC‐A/G
5BC
5BC‐R/Y
5BC‐Y/G
®
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
±10% ALL VALUES
ANGULAR
X°
± 5°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
DESIGNED:
DATE:
Dan Beckman
CHECKED:
06/28/07
DATE:
TITLE:
T-1¾ (5mm) PANEL MOUNT ASSEMBLY
REVISION:
PART NO:
PM5XXWX.X-CC
CAGE CODE : 32559
K
T. Yin
06/28/07
SHEET #
2
OF
4
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
REV.
DESCRIPTION
DATE
APPROVED
SEE SHEET #1.
LED Assy.No.
PM5UBWCWX.X‐CC
PM5SGCWX.X‐CC
PM5SGDWX.X‐CC
PM5SGTWX.X‐CC
PM5SYCWX.X‐CC
PM5SYDWX.X‐CC
PM5SYTWX.X‐CC
PM5SRCWX.X‐CC
PM5SRDWX.X‐CC
PM5SRTWX.X‐CC
PM5UGCWX.X‐CC
PMTSUGCWX.X‐CC
PM5UYCWX.X‐CC
PM5SUYCWX.X‐CC
PM5UOCWX.X‐CC
PM5UOCWX.X‐CC
PM5SUOCWX.X‐CC
PM5URCWX.X‐CC
PM5SURCWX.X‐CC
PM5UWCWX.X‐CC
Material
lnGaN/SiC
GaP/GaP
GaP/GaP
GaP/GaP
GaAsP/GaP
GaAsP/GaP
GaAsP/GaP
GaAIAs/GaAs
GaAIAs/GaAs
GaAIAs/GaAs
AlGalnP
AlGalnP
AlGalnP
AlGalnP
AlGalnP
AlGalnP
AlGalnP
GaAIAs/GaAs
AlGalnP
lnGaN/SiC
Chip
Peak
Wave
Length
468
568
568
568
590
590
590
645
645
645
570
570
590
590
590
625
625
645
640
6500K
Emitted Color
BLUE
GREEN
GREEN
GREEN
YELLOW
YELLOW
YELLOW
SUPER RED
SUPER RED
SUPER RED
GREEN
GREEN
YELLOW
YELLOW
YELLOW
ORANGE
ORANGE
RED
RED
WHITE
Lens
Appearance
WATER CLEAR
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
DIFFUSED
TINTED
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
WATER CLEAR
Electro‐Optical Data @20mA
lf
lv
Vf
(mA)
(mcd)
(V)
MAX
TYP
MAX
TYP
50
3.2
3.6
5000
30
2.1
2.8
60
30
2.1
2.8
50
30
2.1
2.8
60
30
2.0
2.8
600
30
2.0
2.8
150
30
2.0
2.8
600
30
1.7
2.4
60
30
1.7
2.4
40
30
1.7
2.4
60
30
2.1
2.4
600
30
2.1
2.4
300
30
2.0
2.4
1000
30
2.0
2.4
700
30
2.0
2.4
500
30
1.8
2.4
1400
30
1.8
2.4
1300
30
1.7
2.4
400
30
1.8
2.4
500
100
3.5
4.2
2700
Viewing
Angle
LED P/N
2 θ 1/2
(Deg)
15
5BWC2.515
35
5SGC
40
5SGD
35
5SGT
35
5SYC
40
5SYD
35
5SYT
35
5SRC
40
5SRD
35
5SRT
35
5UGC
35
5SUGC
30
5UYC
35
5SUYC
35
5UUYC
35
5UOC
35
5SUOC
30
5URC
35
5SURC
30
5WC2.730
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
±10% ALL VALUES
ANGULAR
®
X°
± 5°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
DESIGNED:
DATE:
Dan Beckman
CHECKED:
06/28/07
DATE:
TITLE:
T-1¾ (5mm) PANEL MOUNT ASSEMBLY
REVISION:
PART NO:
PM5XXWX.X-CC
CAGE CODE : 32559
K
T. Yin
06/28/07
SHEET #
3
OF
4
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
REV.
DESCRIPTION
DATE
APPROVED
SEE SHEET #1.
LED Assy. No.
Peak Wave
Length
λ
p(nm )
430
555
568
590
605
625
645
Max. Rating
Em itted
Color
Lens
Appearance
If
(m A)
MAX
BLUE
PURE GREEN
GREEN
YELLOW
AMBER
HE RED
SUPER RED
DIFFUSED
DIFFUSED
DIFFUSED
DIFFUSED
DIFFUSED
DIFFUSED
DIFFUSED
7
7
7
7
7
7
7
Electro-Optical Data @ 2m A
Vf
(V)
TYP
3.8
2.1
2.1
2.0
2.0
2.0
1.7
MAX
4.2
2.6
2.6
2.6
2.6
2.6
2.3
Iv
(m cd)
TYP
4
1
5
4
4
5
6
View ing
Angle
2 ½
(Deg)
45
45
45
45
45
45
45
LED P/N
PM5BWDLWX.X-CC
PM5PGDLWX.X-CC
PM5GDLWX.X-CC
PM5YDLWX.X-CC
PM5ADLWX.X-CC
PM5HDLWX.X-CC
PM5SRDLWX.X-CC
5BWDL
5PGDL
5GDL
5YDL
5ADL
5HDL
5SRDL
LED Assy. No.
5 Volt
PM5BWD5VWX.X-CC
PM5GC5VWX.X-CC
PM5GD5VWX.X-CC
PM5GT5VWX.X-CC
PM5AD5VWX.X-CC
PM5HD5VWX.X-CC
PM5RD5VWX.X-CC
PM5YD5VWX.X-CC
12 Volt
PM5GC12VWX.X-CC
PM5GD12VWX.X-CC
PM5HC12VWX.X-CC
PM5HD12VWX.X-CC
PM5RC12VWX.X-CC
PM5RD12VWX.X-CC
PM5YC12VWX.X-CC
PM5YD12VWX.X-CC
Peak Wave
Length
λp(nm)
BLUE
GREEN
GREEN
GREEN
AMBER
HE RED
RED
YELLOW
GREEN
GREEN
HE RED
HE RED
RED
RED
YELLOW
YELLOW
Emitted
Color
Lens
Appearance
430
568
568
568
605
625
700
590
568
568
625
625
700
700
590
590
DIFFUSED
WATER CLEAR
DIFFUSED
TINTED
DIFFUSED
DIFFUSED
DIFFUSED
DIFFUSED
WATER CLEAR
DIFFUSED
WATER CLEAR
DIFFUSED
WATER CLEAR
DIFFUSED
WATER CLEAR
DIFFUSED
Electro-Optical Data
Vf
If
Iv
(V)
(mA)
(mcd)
MAX
TYP
MAX
TYP
Data @ 5V
-
-
5
15
-
-
5
40
-
-
5
25
-
-
5
40
-
-
5
25
-
-
5
30
-
-
5
1.5
-
-
5
25
Data @ 12V
-
-
12
40
-
-
12
25
-
-
12
50
-
-
12
30
-
-
12
2
-
-
12
1.5
-
-
12
25
-
-
12
20
±10% ALL VALUES
Viewing
Angle
2
θ½
(Deg)
40
40
40
40
40
40
40
40
35
40
35
40
35
40
35
40
ANGULAR
LED P/N
5BWD5V
5GC5V
5GD5V
5GT5V
5AD5V
5HD5V
5RD5V
5YD5V
5GC12V
5GD12V
5HC12V
5HD12V
5RC12V
5RD12V
5YC12V
5YD12V
®
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
X°
± 5°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
TITLE:
T-1¾ (5mm) PANEL MOUNT ASSEMBLY
DESIGNED:
DATE:
Dan Beckman
CHECKED:
06/28/07
DATE:
PART NO:
REVISION:
PM5XXWX.X-CC
K
T. Yin
06/28/07
CAGE CODE : 32559
SHEET #
4
OF
4
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
京公网安备 11010802033920号
EEWORLD
