SMD
Power Inductors and Transformers
8409-XX
INDUCTORS:
low inductance with high current when wired in
parallel or higher inductance with lower current when wired in series
TRANSFORMERS:
(1:1) electrical isolation and a wide voltage
transformation
• Extended temperature range –40°C to +85°C
• Isolation voltage: 300 Vdc
MECHANICAL AND SCHEMATIC
(All dimensions in inches)
SUGGESTED PAD LAYOUT
SCHEMATICS
ELECTRICAL SPECIFICATIONS @ 25˚C
Parallel Ratings
Part
Number
8409-01
8409-02
8409-03
8409-04
8409-05
8409-06
8409-07
8409-08
8409-09
8409-10
8409-11
8409-12
8409-13
8409-14
8409-15
8409-16
8409-17
Rated
Inductance
(µH)
0.33
0.68
1.0
2.0
5.0
8.0
10.0
15.0
20.0
25.0
33.0
50.0
68.0
100.0
150.0
200.0
300.0
OCL
1
Nominal
±25%
(µH)
0.284
0.675
1.26
1.98
5.06
7.90
11.38
15.48
20.22
25.60
34.84
49.38
66.44
102.38
152.9
197.5
303.7
Isat.
(A)
2
Series Ratings
3
Irms.
(A)
10.9
9.4
8.22
6.74
4.34
3.50
2.89
2.69
2.24
1.89
1.56
1.28
1.07
0.75
0.68
0.64
0.58
DCR
4
@20˚C
(Ω typ.)
0.0033
0.0045
0.0058
0.0090
0.021
0.032
0.047
0.054
0.078
0.111
0.162
0.240
0.342
0.695
0.842
0.950
1.174
ISSUE: B
18.8
12.5
9.38
7.50
4.69
3.75
3.13
2.68
2.34
2.08
1.79
1.50
1.29
1.04
0.85
0.75
0.60
OCL
1
Nominal
±25%
(µH)
1.14
2.70
5.06
7.90
20.22
31.60
45.50
61.94
80.90
102.38
139.4
197.5
265.8
409.5
611.8
790.0
1215
Isat.
2
(A)
9.38
6.25
4.69
3.75
2.34
1.88
1.56
1.34
1.17
1.04
0.89
0.75
0.65
0.52
0.43
0.38
0.30
Irms.
3
(A)
5.47
4.68
4.11
3.37
2.17
1.75
1.45
1.35
1.12
0.94
0.78
0.64
0.54
0.38
0.34
0.32
0.29
DCR
4
@20˚C
(Ω typ.)
0.0132
0.0180
0.0233
0.035
0.084
0.129
0.188
0.218
0.313
0.443
0.649
0.961
1.367
2.778
3.366
3.800
4.697
09/05/02
8409
1. Measured @ 100kHz, 0.250Vrms, 0.0Adc
Parallel (1,4 – 3,2); Series (1–3) tie (2–4)
2. Peak current for approximately 30% roll-off
3. RMS current, delta temp. of 40°C ambient
temperature of 85°C
4. Values @ 20°C, Maximum DCR is +15% of typical value
5. Turns Ratio: (1-2):(4-3) 1:1
