FSI-150-10-L-D-AD-TR datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> FSI-150-10-L-D-AD-TR

Preview

FSI-150-10-L-D-AD-TR: Description1MM SINGLE ELEMENT INTERFACE; CategoryThe connector The connector; File Size78KB，2 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

FSI-150-10-L-D-AD-TR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FSI-150-10-L-D-AD-TR	-	-	View	Buy Now

FSI-150-10-L-D-AD-TR Overview

1MM SINGLE ELEMENT INTERFACE

FSI-150-10-L-D-AD-TR Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SAMTEC
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	2 weeks
Other features	DUAL SIDE PIN, TAPE&REEL PKG
Board mount options	POSITIONING PIN
body width	0.355 inch
subject depth	0.394 inch
body length	1.998 inch
Body/casing type	RECEPTACLE
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
DIN compliance	NO
Filter function	NO
IEC compliance	NO
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	FSI
Plug contact pitch	0.039 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	10u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	1 A
Guideline	UL
reliability	COMMERCIAL
Terminal length
Terminal pitch	1 mm
Termination type	SURFACE MOUNT
Total number of contacts	100
Base Number Matches	1

Preview

Download Datasheet

View All

REVISION G

RECOMMENDED BOARD LAYOUT FOR FSI (6mm & 10mm)

(No OF POS x .03937[1.0000]) + .285[7.24]

.1622 4.12 REF

(No OF POS -1) X .03937[1.0000]

.0394 1.00

.1000 2.54 (TYP)

NON-PLATED THRU HOLE

(-TH OPTION)

01

FIG 1

FOR -10, -20, -30 POS(THREADED)

OR -05 THRU -50 POS (NON-THREADED)

.1730 4.39

.0445 1.13 (TYP)

.0240 0.61 (TYP)

02

.0470 1.19

NON-PLATED THRU HOLE

(-AT, -AD OPTION)

(No OF POS x .03937[1.0000]) +.600[15.24]

(No OF POS. x .03937[1.0000])/2 + .300[7.62]

.1000 2.54 (TYP)

NON-PLATED THRU HOLE

(-TH OPTION)

.3543 9.00

.1622 4.12

REF (TYP)

(No OF POS. x .03937[1.0000]) + .276[7.00]

FIG 2

FOR -40 AND -50 POS (THREADED)

NOTE:

PROPRIETARY NOTE

THIS DOCUMENT CONTAINS INFORMATION

CONFIDENTIAL AND PROPRIETARY TO

SAMTEC, INC. AND SHALL NOT BE REPRODUCED

OR TRANSFERRED TO OTHER DOCUMENTS OR

DISCLOSED TO OTHERS OR USED FOR ANY

PURPOSE OTHER THAN THAT WHICH IT WAS

OBTAINED WITHOUT THE EXPRESSED WRITTEN

CONSENT OF SAMTEC, INC.

G

1.NOTE DELETED.

ALL OTHER DIMENSIONS ARE THE SAME AS ABOVE

F:\DWG\MISC\mktg\FOOTPRNT\FSI-06-10.SLDDRW

520 PARK EAST BLVD, NEW ALBANY, IN 47150

PHONE: 812-944-6733

FAX: 812-948-5047

e-Mail info@SAMTEC.com

code 55322

SHEET

1

OF

2
