BB831...
Silicon Variable Capacitance Diodes
•
Frequency range up to 2 GHz
•
Special design for use in TV-sat tuners
•
Pb-free (RoHS compliant) package
BB831
Type
BB831
Package
SOD323
Configuration
single
L
S
(nH)
1.8
Marking
white T
Maximum Ratings
at
T
A
= 25°C, unless otherwise specified
Parameter
Diode reverse voltage
Peak reverse voltage
(
R
≥
5kΩ )
Forward current
Operating temperature range
Storage temperature
I
F
T
op
T
stg
20
-55 ... 125
-55 ... 150
mA
°C
Symbol
V
R
V
RM
Value
30
35
Unit
V
1
2011-06-15
BB831...
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Parameter
DC Characteristics
Reverse current
V
R
= 30 V
V
R
= 30 V,
T
A
= 85 °C
AC Characteristics
Diode capacitance
V
R
= 1 V,
f
= 1 MHz
V
R
= 28 V,
f
= 1 MHz
C
T
Symbol
min.
I
R
-
-
Values
typ.
max.
Unit
nA
-
-
20
500
pF
7.8
0.85
8.8
1.02
8.6
-
1
9.8
1.2
9.5
3
-
%
Ω
Capacitance ratio
V
R
= 1 V,
V
R
= 28 V,
f
= 1 MHz
C
T1
/
C
T28
∆C
T
/
C
T
r
S
7.8
-
-
Capacitance matching
1)
V
R
= 1 V,
V
R
= 28 V,
f
= 1 MHz
Series resistance
V
R
= 1 V,
f
= 100 MHz
1
For
details please refer to Application Note 047.
2
2011-06-15
BB831...
