Da ta S heet, Versio n 1.2, 2 007-02-26
TDA5255 E1
ASK/FSK 434MHz Wireless
Transceiver
Wireless Components
N e v e r
s t o p
t h i n k i n g .
Edition 2007-02-26
Published by Infineon Technologies AG,
Am Campeon 1-12,
D-85579 Neubiberg, Germany
©
Infineon Technologies AG 3/7/07.
All Rights Reserved.
Attention please!
The information herein is given to describe certain components and shall not be considered as warranted
characteristics.
Terms of delivery and rights to technical change reserved.
We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
Infineon Technologies is an approved CECC manufacturer.
Information
For further information on technology, delivery terms and conditions and prices please contact your nearest
Infineon Technologies Office in Germany or our Infineon Technologies Representatives worldwide (see address
list).
Warnings
Due to technical requirements components may contain dangerous substances. For information on the types in
question please contact your nearest Infineon Technologies Office.
Infineon Technologies Components may only be used in life-support devices or systems with the express written
approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure
of that life-support device or system, or to affect the safety or effectiveness of that device or system. Life support
devices or systems are intended to be implanted in the human body, or to support and/or maintain and sustain
and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other persons may
be endangered.
Da ta S heet, Versio n 1.2, 2 007-02-26
TDA5255 E1
ASK/FSK 434MHz Wireless
Transceiver
Wireless Components
N e v e r
s t o p
t h i n k i n g .
Data Sheet
Revision History:
Previous Version:
Page
5
5, 9
76
2007-02-26
Version 1.1 as of 2002-11-28
TDA5255 E1
Subjects (major changes since last revision)
Indication of the Ordering Code
Correction of the Package Name
Indication of the ESD-integrity values
For questions on technology, delivery and prices please contact the Infineon
Technologies Offices in Germany or the Infineon Technologies Companies and
Representatives worldwide: see our webpage at http://www.infineon.com
ABM
®
, AOP
®
, ARCOFI
®
, ARCOFI
®
-BA, ARCOFI
®
-SP, DigiTape
®
, EPIC
®
-1, EPIC
®
-S,
ELIC
®
, FALC
®
54, FALC
®
56, FALC
®
-E1, FALC
®
-LH, IDEC
®
, IOM
®
, IOM
®
-1, IOM
®
-2,
IPAT
®
-2, ISAC
®
-P, ISAC
®
-S, ISAC
®
-S TE, ISAC
®
-P TE, ITAC
®
, IWE
®
, MUSAC
®
-A,
OCTAT
®
-P, QUAT
®
-S, SICAT
®
, SICOFI
®
, SICOFI
®
-2, SICOFI
®
-4, SICOFI
®
-4µC,
SLICOFI
®
are registered trademarks of Infineon Technologies AG.
ACE™, ASM™, ASP™, POTSWIRE™, QuadFALC™, SCOUT™ are trademarks of
Infineon Technologies AG.
Controller Area Network (CAN): License of Robert Bosch GmbH
ASK/FSK 434MHz Wireless Transceiver
TDA5255 E1
Version 1.2
Product Info
General Description
The IC is a low power consumption single chip FSK/ASK
Transceiver for half duplex low datarate communication in the
433-435MHz band. The IC offers a very high level of integration
and needs only a few external components. It contains a highly
efficient power amplifier, a low noise amplifier (LNA) with AGC,
a double balanced mixer, a complex direct conversion stage, I/
Q limiters with RSSI generation, an FSK demodulator, a fully
integrated VCO and PLL synthesizer, a tuneable crystal
oscillator, an onboard data filter, a data comparator (slicer),
positive and negative peak detectors, a data rate detection
circuit and a 2/3-wire bus interface. Additionally there is a power
down feature to save battery power.
Features
– Low supply current (I
s
= 9mA typ. receive, I
s
= 13mA typ. transmit mode)
– Supply voltage range 2.1 - 5.5V
– Power down mode with very low supply
current consumption
– FSK and ASK modulation and demodulation
capability
– Fully integrated VCO and PLL
synthesizer and loop filter on-chip with on
chip crystal oscillator tuning
– I
2
C/3-wire µController Interface
– On-chip low pass channel select filter and
data filter with tuneable bandwidth
– Data slicer with self-adjusting threshold and
2 peak detectors
– FSK sensitivity <-109dBm, ASK sensitivity <
–109dBm
– Transmit power up to +13dBm
– Datarates up to 100kBit/s Manchester
Encoded
– Self-polling logic with ultra fast data rate
detection
Application
– Low Bitrate Communication
Systems
– Keyless Entry Systems
– Remote Control Systems
– Alarm Systems
Type
TDA5255 E1
Data Sheet
Ordering Code
SP000014555
5
– Telemetry Systems
– Electronic Metering
– Home Automation Systems
Package
PG-TSSOP-38
2007-02-26
