MLCC Tin/Lead Termination “B”
C0G (NP0) – General Specifications
AVX Corporation will support those customers for
commercial and military Multilayer Ceramic Capacitors with
a termination consisting of 5% minimum lead. This
termination is indicated by the use of a “B” in the 12th
position of the AVX Catalog Part Number. This fulfills AVX’s
commitment to providing a full range of products to our
customers. AVX has provided in the following pages a full
range of values that we are currently offering in this special
“B” termination. Please contact the factory if you require
additional information on our MLCC Tin/Lead Termination
“B” products.
Not RoHS Compliant
PART NUMBER (see page 2 for complete part number explanation)
LD05
Size
LD02 - 0402
LD03 - 0603
LD04 - 0504*
LD05 - 0805
LD06 - 1206
LD10 - 1210
LD12 - 1812
LD13 - 1825
LD14 - 2225
LD20 - 2220
5
Voltage
6.3V = 6
10V = Z
16V = Y
25V = 3
35V = D
50V = 5
100V = 1
200V = 2
500V = 7
A
Dielectric
C0G (NP0) = A
X7R = C
X5R = D
X8R = F
101
Capacitance
Code (In pF)
2 Sig. Digits +
Number of
Zeros
J
A
B
2
A
Special
Code
A = Std.
Product
B
C
D
F
G
J
K
M
Capacitance
Failure
Terminations
Packaging
Tolerance
Rate
2 = 7" Reel
B = 5% min lead
= ±.10 pF (<10pF) A = Not X = FLEXITERM
®
4 = 13" Reel
= ±.25 pF (<10pF) Applicable
with 5% min
= ±.50 pF (<10pF)
Contact Factory
lead**
= ±1% (≥ 10 pF)
For
= ±2% (≥ 10 pF)
Multiples
**X7R only
= ±5%
= ±10%
= ±20%
*LD04 has the same CV ranges as LD03.
NOTE: Contact factory for availability of Tolerance Options for Specific Part Numbers.
Contact factory for non-specified capacitance values.
See FLEXITERM
®
section for CV options
Insulation Resistance (Ohm-Farads)
Insulation Resistance vs Temperature
10,000
1,000
100
0
0
20
40
60
80
100
Temperature
°C
40
112916
MLCC Tin/Lead Termination “B”
C0G (NP0) – Specifications and Test Methods
Parameter/Test
Operating Temperature Range
Capacitance
Q
Insulation Resistance
Dielectric Strength
NP0 Specification Limits
-55ºC to +125ºC
Within specified tolerance
<30 pF: Q≥ 400+20 x Cap Value
≥30 pF: Q≥ 1000
100,000MΩ or 1000MΩ - μF,
whichever is less
No breakdown or visual defects
Measuring Conditions
Temperature Cycle Chamber
Freq.: 1.0 MHz ± 10% for cap ≤ 1000 pF
1.0 kHz ± 10% for cap > 1000 pF
Voltage: 1.0Vrms ± .2V
Charge device with rated voltage for
60 ± 5 secs @ room temp/humidity
Charge device with 250% of rated voltage for
1-5 seconds, w/charge and discharge current
limited to 50 mA (max)
Note: Charge device with 150% of rated
voltage for 500V devices.
Deflection: 2mm
Test Time: 30 seconds
Resistance to
Flexure
Stresses
Appearance
Capacitance
Variation
Q
Insulation
Resistance
No defects
±5% or ±.5 pF, whichever is greater
Meets Initial Values (As Above)
≥ Initial Value x 0.3
≥ 95% of each terminal should be covered
with fresh solder
No defects, <25% leaching of either end terminal
≤ ±2.5% or ±.25 pF, whichever is greater
Meets Initial Values (As Above)
Meets Initial Values (As Above)
Meets Initial Values (As Above)
No visual defects
≤ ±2.5% or ±.25 pF, whichever is greater
Meets Initial Values (As Above)
Meets Initial Values (As Above)
Meets Initial Values (As Above)
No visual defects
≤ ±3.0% or ± .3 pF, whichever is greater
≥ 30 pF:
≥10 pF, <30 pF:
<10 pF:
Q≥ 350
Q≥ 275 +5C/2
Q≥ 200 +10C
Solderability
Appearance
Capacitance
Variation
Resistance to
Solder Heat
Q
Insulation
Resistance
Dielectric
Strength
Appearance
Capacitance
Variation
Q
Insulation
Resistance
Dielectric
Strength
Appearance
Capacitance
Variation
Q
(C=Nominal Cap)
Insulation
Resistance
Dielectric
Strength
Appearance
Capacitance
Variation
Load
Humidity
Q
Insulation
Resistance
Dielectric
Strength
Dip device in eutectic solder at 230 ± 5ºC
for 5.0 ± 0.5 seconds
Dip device in eutectic solder at 260ºC for 60
seconds. Store at room temperature for 24 ± 2
hours before measuring electrical properties.
Step 1: -55ºC ± 2º
Step 2: Room Temp
Step 3: +125ºC ± 2º
Step 4: Room Temp
30 ± 3 minutes
≤ 3 minutes
30 ± 3 minutes
≤ 3 minutes
Thermal
Shock
Repeat for 5 cycles and measure after
24 hours at room temperature
Charge device with twice rated voltage in
test chamber set at 125ºC ± 2ºC
for 1000 hours (+48, -0).
Remove from test chamber and stabilize at
room temperature for 24 hours
before measuring.
Load Life
≥ Initial Value x 0.3 (See Above)
Meets Initial Values (As Above)
No visual defects
≤ ±5.0% or ± .5 pF, whichever is greater
≥ 30 pF:
≥10 pF, <30 pF:
<10 pF:
Q≥ 350
Q≥ 275 +5C/2
Q≥ 200 +10C
Store in a test chamber set at 85ºC ± 2ºC/
85% ± 5% relative humidity for 1000 hours
(+48, -0) with rated voltage applied.
Remove from chamber and stabilize at
room temperature for 24 ± 2 hours
before measuring.
≥ Initial Value x 0.3 (See Above)
Meets Initial Values (As Above)
112916
41
MLCC Tin/Lead Termination “B”
X8R – General Specifications
AVX Corporation will support those customers for
commercial and military Multilayer Ceramic Capacitors with
a termination consisting of 5% minimum lead. This
termination is indicated by the use of a “B” in the 12th
position of the AVX Catalog Part Number. This fulfills AVX’s
commitment to providing a full range of products to our
customers. AVX has provided in the following pages a full
range of values that we are currently offering in this special
“B” termination. Please contact the factory if you require
additional information on our MLCC Tin/Lead Termination
“B” products.
Not RoHS Compliant
PART NUMBER (see page 2 for complete part number explanation)
LD05
Size
LD02 - 0402
LD03 - 0603
LD04 - 0504*
LD05 - 0805
LD06 - 1206
LD10 - 1210
LD12 - 1812
LD13 - 1825
LD14 - 2225
LD20 - 2220
5
Voltage
6.3V = 6
10V = Z
16V = Y
25V = 3
35V = D
50V = 5
100V = 1
200V = 2
500V = 7
F
Dielectric
X8R = F
101
Capacitance
Code (In pF)
2 Sig. Digits +
Number of
Zeros
J
A
B
2
A
Special
Code
A = Std.
Product
B
C
D
F
G
J
K
M
Capacitance
Failure
Terminations
Packaging
Tolerance
Rate
2 = 7" Reel
B = 5% min lead
= ±.10 pF (<10pF) A = Not X = FLEXITERM
®
4 = 13" Reel
= ±.25 pF (<10pF) Applicable
with 5% min
= ±.50 pF (<10pF)
Contact Factory
lead**
= ±1% (≥ 10 pF)
For
= ±2% (≥ 10 pF)
Multiples
**X7R only
= ±5%
= ±10%
= ±20%
*LD04 has the same CV ranges as LD03.
NOTE: Contact factory for availability of Tolerance Options for Specific Part Numbers.
Contact factory for non-specified capacitance values.
See FLEXITERM
®
section for CV options
44
112916
