BOARD/WIRE-TO-BOARD
CONNECTORS
1.25mm WIRE-TO-BOARD SYSTEM
OVERVIEW
FCI’s 1.25mm pitch wire-to-board connector series is
designed for a wide variety of applications in Industrial,
Automotive and Consumer markets.
The range consists of terminals, crimp housings and PCB
headers in straight and right angle, surface mount and
through mount configurations. It is a single row design,
available with from 2 to 15 circuits. A crimping application
tool is also available for wire harness assembly.
Unlike many other products for the same applications, FCI’s
1.25mm Wire-To-Board range conforms to the EU Industry
Safety Standard, PCB header material meets halogen free
requirements and the products can be operated in the
temperature range from -40°C to +105°C.
FEATURES
• Fully polarized housings
• Crimping housing is equipped with friction
• Halogen-free resin material
• Available in UL94V-0 flammability rated LCP
• Provide various types PCB header
• Plating with Tin, Gold Flash, 15u” Gold and 30u” Gold
• RoHS compliance and Lead-free
• Tape and Reel with pick up cap packaging
BENEFITS
• Prevents accidental mis-mating
• Prevents harness-to-header mis-mating
• Meet environmental requirement
• High flammability rating
• Supports various PCB applications
• Different plating options available
• Meet environmental, health and safety requirements
• Pick and place for SMT production process
1.25mm WIRE-TO-BOARD SYSTEM
TECHNICAL INFORMATION
MATERIALS
• Contact: Copper Alloy
• Plating: Matte tin, gold flash, 15µin. gold and 30µin. gold
over nickel
• Housing: Thermoplastic or thermoplastic
high temperature, UL94V-0
• Metal hold down: Copper Alloy
• Plating: Matt Tin
MECHANICAL PERFORMANCE
• Mating & Un-mating Force: conforms to EIA-364-13
• Contact Retention Force: 0.5Kgf min.
• Hold down/Housing retention force: 1.0Kgf min.
• Wire retention force: 0.5Kgf min.
• Terminal/Housing retention force: 0.5Kgf min.
• Vibration: 1µs max., EIA-364-28 Condition I
• Shock: 1µs max., EIA-364-27AHold down/Housing
• Durability: 30 cycles
ELECTRICAL PERFORMANCES
• Contact Resistance: 20mΩ max.
• Insulation Resistance: 100MΩ min.
• Voltage Rating: 125V AC, DC
• Current Rating: 1A (0.8A -32 AWG)
• Dielectric Withstand Voltage: 500V AC/minute
SPECIFICATIONS
• Product Specifications: GS-12-675
• Packaging Specifications: GS-14-1592; GS-14-1593
APPROVALS AND CERTIFICATIONS
• RoHS conforms to EU Directive 2002/95/EC
• UL approval
• Housing connector conforms to IEC 60695-2 Industry
Safety Standard (Glow Wire test)
ENVIRONMENTAL
• Resistance to reflow soldering heat:
• Pre-heat: 150°C to 180°C, 60 - 90 seconds
• Heat: 230°C min., 40 seconds min.
• Peak Temperature: 260°C max., 10 seconds max.
• Resistance to hand soldering heat:
• Soldering iron: 350±10°C
• Duration: 3 - 4 seconds min.
• Thermal Shock (temperature cycling): conforms to
EIA-364-32A
• Humidity (temperature cycling): conforms to
EIA-361-31A
• Temperature Life (heat aging): conforms to EIA-361-17A,
105°C for 96 hours
• Salt Spray: conforms to EIA-364-26B
• Solderability: solderable area to have min.
95% solder coverage
PACKAGING
• PCB Header: tape and reel
• Crimping Housing: bag
• Terminal: reel
TARGET MARKETS/APPLICATIONS
• Industrial & Instrumentation
• Industry Control
• Instrumentation/Metering
• Office Equipment
• Small Motor/Robot Control
• Security
• Alarm Systems
• Vending POS Machine
• Consumer
• Car Audio
For more information,
please contact: Communications@fci.com
or visit us at
www.fci.com
Disclaimer
Please note that the above information is subject to change without notice.
