382276 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Topical application> Test and measurement> 382276

382276: DescriptionDC POWER SUPPLY 30V/20A SWITCHIN; CategoryTopical application Test and measurement; File Size138KB，1 Pages; ManufacturerFLIR

Download Datasheet Parametric Compare View All

382276 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	382276	-	-	View	Buy Now

382276 Overview

DC POWER SUPPLY 30V/20A SWITCHIN

382276 Parametric

Parameter Name	Attribute value
type	Workbench (AC to DC)
Voltage - Power	230VAC
Voltage - Output	1 ~ 30V
Current - Output	1 ~ 20A
display type	LED
Number of characters	3（2）
Number of outputs	1
size/dimensions	8.500" long x 7.900" wide x 3.500" high (215.90mm x 200.66mm x 88.90mm)
characteristic	-
Power (W)	600W
Accuracy - Voltmeter; Ammeter	0.5% + 2 digits
Voltage Regulation - Line	20mV
Voltage Regulation - Load	50mV
Current Regulation - Line	50mA
Current Regulation - Load	100mA
ripple	5mV rms
weight	-

Preview

Download Datasheet

View All

600W Single Output

Laboratory Grade DC Power Supply

Dual Action Voltage and Current Control

Push knob for fine and coarse tuning

Features:

•

0 to 30V, 20A adjustable output switching

mode power supply

•

Remote Control for output Voltage/Current

and On/Off

•

Two user-defined Voltage and Current

presets and one 13.8V/20A factory preset

•

Automatic Constant Current and Constant

Voltage crossover

•

Dual 3-Digit LED displays

•

High RFI immunity and excellent EMI

•

Thermostatic Control Fan from zero to full speed

•

Over voltage, over-temperature, and

short circuit protection

•

Low profile and small footprint

•

Complete with power cord

Specifications

Output Voltage (Res.)

Output Current (Res.)

Basic accuracy

Load Voltage Regulation

Line Voltage Regulation

Load Current Regulation

Line Current Regulation

Ripple and Noise

Power

Dimensions

Weight

Range

1 to 30V (100mV)

1 to 20A (100mA)

±(0.5%+2 digits)

50mV

20mV

100mA min

50mA min

<5mVrms

382275 - 120VAC, 50Hz/60Hz

382276 - 230V, 50Hz/60Hz

7.9 x 3.5 x 8.5" (200 x 90 x 215mm)

5.7lbs (2.6kg)

Ordering Information:

382275

..............Laboratory Grade Switching Mode DC Power Supply (120V)

382276

..............Laboratory Grade Switching Mode DC Power Supply (230V)

www.extech.com

Specifications subject to change without notice.

6/26/09 - R1

382276 Related Products

	382276	382275
Description	DC POWER SUPPLY 30V/20A SWITCHIN	600W SWITCHING MODE DC POWER SUP
type	Workbench (AC to DC)	Workbench (AC to DC)
Voltage - Power	230VAC	120VAC
Voltage - Output	1 ~ 30V	1 ~ 30VDC
Current - Output	1 ~ 20A	1 ~ 20A
display type	LED	LED
Number of characters	3（2）	3（2）
Number of outputs	1	1
size/dimensions	8.500" long x 7.900" wide x 3.500" high (215.90mm x 200.66mm x 88.90mm)	8.500" long x 7.900" wide x 3.500" high (215.90mm x 200.66mm x 88.90mm)
Power (W)	600W	600W
Accuracy - Voltmeter; Ammeter	0.5% + 2 digits	0.5% + 2 digits
Voltage Regulation - Line	20mV	20mV
Voltage Regulation - Load	50mV	50mV
Current Regulation - Line	50mA	50mA
Current Regulation - Load	100mA	100mA
ripple	5mV rms	5mV rms
