Part Number:
5405FE
Security & Sound, #20-7c, BC, Shielded, CMR
Product Description
Security & Sound Cable, Riser-CMR, 7-20 AWG stranded bare copper conductors with polyolefin insulation, Beldfoil® shield and PVC jacket with ripcord
Technical Specifications
Physical Characteristics (Overall)
Conductor
AWG Stranding
20
7x28
Material
No. of Conductors
BC - Bare Copper 7
7
20 AWG
Conductor Count:
Conductor Size:
Insulation
Material
Nominal Wall Thickness
PP - Polypropylene 0.008 in
Color Chart
Color
Black
Red
White
Green
Brown
Blue
Orange
Outer Shield Material
Type
Material
Material Trade Name Coverage [%] Drainwire Material
100 %
Drainwire AWG Drainwire Construction n x D
Solid
Tape Aluminum/Polyester Beldfoil®
Outer Jacket Material
Material
TC - Tinned Copper 24
Nominal Diameter Nominal Wall Thickness Ripcord
0.018 in
Yes
PVC - Polyvinyl Chloride 0.189 in
Construction and Dimensions
Print Legend:
NEW GENERATION(R) BY BELDEN-M 5405FE CMR 75C 7C20 SHIELDED (UL) E108998 OR C(UL) CMG (2 FT., 7 DIGIT SEQUENTIAL) FEET
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR Nominal Outer Shield DCR
10.2 Ohm/1000ft
Capacitance
Nom. Capacitance Conductor to Conductor Nom. Capacitance Conductor to Other Conductor to Shield
26 pF/ft
46.75 pF/ft
10.5 Ohm/1000ft
Current
Max. Recommended Current [A]
2.6 Amps per conductor @ 25°C A
Voltage
UL Voltage Rating
300 V RMS
Mated Connection
Min. Balanced TCL TIA* (dB)
30 dB
Temperature Range
UL Temp Rating:
Operating Temp Range:
75°C
-20°C To +75°C
Mechanical Characteristics
Bulk Cable Weight:
Max Recommended Pulling Tension:
Min Bend Radius/Minor Axis:
34 lbs/1000ft
97.3 lbs
1.875 in
Standards
NEC Articles:
NEC/(UL) Specification:
CEC/C(UL) Specification:
800
CMR
CMG
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (ROHS II):
EU Directive 2012/19/EU (WEEE):
EU Directive Compliance:
EU CE Mark:
Yes
Yes
Yes
Yes
EU Directive 2003/11/EC (BFR)
Yes
EU RoHS Compliance Date (yyyy-mm-dd): 2005-04-01
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Yes
Yes
Flammability, LS0H, Toxicity Testing
UL Flammability:
CSA Flammability:
UL voltage rating:
UL1666 Riser
FT4
300 V RMS
Plenum/Non-Plenum
Plenum (Y/N):
No
Part Number
Variants
Item #
5405FE 0081000
Color Footnote
Gray
C
5405FE 008U1000 Gray
Footnote:
C - CRATE REEL PUT-UP.
