42051
NEGATIVE VOLTAGE REGULATORS
Commercial or Military
MICROPAC
MICROCIRCUITS PRODUCTS
DIVISION
Mii
Features:
•
•
•
Output current to 5 Amps
Output voltage To –34 V
Internal short circuit protection
Applications:
•
Military and Hi Rel industrial applications where
hermetically sealed product is required.
DESCRIPTION
The 42051 series of regulators covers the voltage range from –5 V through –34 V. These regulators are fabricated
using hybrid techniques. The devices are complete with internal short circuit protection, which includes voltage
shutdown and current fold-back. To insure circuit stability under all load combinations it is recommended that a
minimum of 2.0 µF capacitance (solid tantalum) be connected between power ground and the input to the regulator.
ABSOLUTE MAXIMUM RATINGS
Output Current - I
OUT
.......................................................................................................................................................5 A
Power Dissipation @ 25°C Case Temperature ........................................................................................................120W
Operating Temperature............................................................................................................................ -55°C to +125°C
Storage Temperature ............................................................................................................................... -65°C to +150°C
Input Voltage - V
IN
.......................................................................................................................................................-40 V
NOTE: Lead Temperature (Soldering, 10 sec.) 300
°
C
Micropac Industries
cannot assume any responsibility for any circuits shown or represent that they are free from patent infringement.
Micropac
reserves the right to make changes at any time in order to improve design and to supply the best product possible.
MICROPAC INDUSTRIES, INC MICROCIRCUITS PRODUCTS DIVISION
•
905 E. Walnut St., Garland, TX 75040
•
(972) 272-3571
•
Fax (972) 494-2281
5/22/02
www.micropac.com
E-MAIL:
microsales@micropac.com
Pg. 1 of 3
42051
ELECTRICAL CHARACTERISTICS (Note 1)
NEGATIVE VOLTAGE REGULATORS
PARAMETER
Output Voltage
Differential Voltage
V
IN
- V
OUT
Line Regulation (Note 3)
SYMBOL
V
OUT
∆
V
TEST CONDITIONS
I
OUT
= 1A, V
IN
= V
O
-5V
I
OUT
= I
MAX
-V
IN
= V
OUT
-5V to -V
IN
=
-40V
I
OUT
= .25A to -I
OUT =
-I
MAX
V
IN
= V
O
-5V
f = 50 to 500 Hz
1.0V (P-P)
V
IN
– V
OUT
= 5V
0°C
≤
T
C
≤
100
°
C
MIN
V
OUT
+ .1V
5
TYP
V
OUT
MAX
V
OUT
– .1V
UNIT
VDC
VDC
.1
% V
OUT
Load Regulation (Note 2)
Ripple Rejection
40
50
mV
dB
Temperature Coefficient
Standby Current
Thermal Resistance
Long Term Stability
T
C
I
S
θ
jc
.05
25
1
0.1
%/
°
C
mA
°
C/W
%/1000 hrs
Note 1: Case temperature 25
°
C unless otherwise specified.
Note 2: Voltage measured at Pin 2 within .05 inches from case.
Note 3: Instantaneous regulation, average chip temperature changes must be accounted for separately
.
Standard Outputs
TYPE
42051 - 055
065
075
085
095
105
124
144
154
164
184
204
223
243
263
283
303
323
343
V
OUT
(VDC)
-5
-6
-7
-8
-9
-10
-12
-14
-15
-16
-18
-20
-22
-24
-26
-28
-30
-32
-34
MAX I
OUT
(A)
5
5
5
5
5
5
4
4
4
4
4
4
3
3
3
3
3
3
3
TYP I
KNEE
6.5
6.5
6.5
6.5
6.5
6.5
5
5
5
5
5
5
4
4
4
4
4
4
4
(A)
TYP I
SC
(A)
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2
2
2
2
2
2
1.5
1.5
1.5
1.5
1.5
1.5
Micropac Industries
cannot assume any responsibility for any circuits shown or represent that they are free from patent infringement.
Micropac
reserves the right to make changes at any time in order to improve design and to supply the best product possible.
MICROPAC INDUSTRIES, INC MICROCIRCUITS PRODUCTS DIVISION
•
905 E. Walnut St., Garland, TX 75040
•
(972) 272-3571
•
Fax (972) 494-2281
5/22/02
www.micropac.com
E-MAIL:
microsales@micropac.com
Pg. 2 of 3
42051
NEGATIVE VOLTAGE REGULATORS
Mechanical Configuration
ELECTRICAL CONNECTIONS
Case
Pin 1
Pin 2
V
IN
Ground
V
OUT
Micropac Industries
cannot assume any responsibility for any circuits shown or represent that they are free from patent infringement.
Micropac
reserves the right to make changes at any time in order to improve design and to supply the best product possible.
MICROPAC INDUSTRIES, INC MICROCIRCUITS PRODUCTS DIVISION
•
905 E. Walnut St., Garland, TX 75040
•
(972) 272-3571
•
Fax (972) 494-2281
5/22/02
www.micropac.com
E-MAIL:
microsales@micropac.com
Pg. 3 of 3
