F1772S X2
www.vishay.com
Vishay Roederstein
Interference Suppression Film Capacitor - Class X2
Radial MKT - 310 V
AC
- Series Impedance - 85 °C / 85 % RH
FEATURES
• Stable capacitance in severe ambient
conditions 85 °C; 85 % RH, 240 V
AC
, 1000 h
• 15 mm to 27.5 mm lead pitch
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
High stability grade X2 capacitors for series impedance and
across the line applications.
See also application note:
www.vishay.com/doc?28153
QUICK REFERENCE DATA
Capacitance range (E12 series)
Capacitance tolerance
Rated AC voltage
Climatic testing class according to IEC 60068-1
Rated temperature
10 nF to 2.2 μF (preferred values according to E6)
± 10 %; ± 20 %
310 V
AC
55/110/56
C
1 μF: 110 °C
C > 1 μF: 105 °C
IEC 60384-14 ed-4 and EN 60384-14
Reference standards
IEC 60065 requires pass. flamm. class:
B for volumes > 1750 mm
3
C for volumes
1750 mm
3
UL 60384-14; CSA-E384-14
Dielectric
Electrodes
Construction
Plastic case, epoxy resin sealed, flame retardant
UL-class 94 V-0
Tinned wire
C-value; tolerance; rated voltage; sub-class; manufacturer’s type;
code for dielectric material; manufacturer location, year and week;
manufacturer's logo or name; safety approvals
Polyester film
Metallized
Series construction
Encapsulation
Leads
Marking
Notes
• For more detailed data and test requirements, contact
rfi@vishay.com
• For general information like characteristics and definitions used for film capacitors follow the link:
www.vishay.com/doc?28147
DIMENSIONS
in millimeters
l
w
h
l
t
P
Ø d
t
Revision: 26-Feb-18
Document Number: 26062
1
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772S X2
www.vishay.com
COMPOSITION OF CATALOG NUMBER
Vishay Roederstein
MULTIPLIER (nF)
0.1
1
10
100
1000
10 000
2
3
4
5
6
7
CAPACITANCE CODE
(numerically)
P
1
(mm)
15
22.5
PITCH CODE
F
I
K
Example:
310
410
510
10 nF
100 nF
1000 nF
0.01 μF
0.1 μF
1.0 μF
27.5
SPECIAL
VOLTAGE
31 = 310 V
AC
0 =
Standard
Other =
Special
1 2
3
4 5 6
F 1 7 7 2
S
7 8
X 2
9
4
10 11
1
0
12 13
3
1
14
M
15
F
16
M
17
B
18
0
TOLERANCE
CLASS
M
K
TYPE
A
± 20 %
± 10 %
Special
tolerance
l
t
(mm)
3.5 ± 0.3
5±1
25 ± 2
LEAD LENGTH CODE
P
M
I
0:
Space
holder
PITCH (mm)
≥ 15
All
All
PACKING CODE
B/T
W
PACKING
STYLE
Bulk/loose
(1)
Tape and reel (H: 18.5 mm; 500 mm)
Notes
• For detailed tape specifications refer to packaging information
www.vishay.com/doc?28139
(1)
Packaging will be bulk for all capacitors with pitch
15 mm and such with long leads (> 5 mm).
Capacitors with short leads up to 5 mm and pitch > 15 mm will be in tray and asking code will be “T”.
Revision: 26-Feb-18
Document Number: 26062
2
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772S X2
www.vishay.com
Vishay Roederstein
VALUE
310 V
AC
630 V
DC
100 x 10
-4
at 1 kHz
100 V/μs
> 15 000 M
> 5000 s
> 30 000 M
1800 V; 1 min
1500 V; 1 min
2120 V; 1 min
C
1 μF: 110 °C
C > 1 μF: 105 °C
SPECIFIC REFERENCE DATA
DESCRIPTION
Rated AC voltage (U
RAC
)
Rated DC voltage (U
RDC
)
Tangent of loss angle
Rated voltage pulse slope (dU/dt)
R
at 435 V
DC
R between leads, for C
0.33 μF at 100 V; 1 min
RC between leads, for C > 0.33 μF at 100 V; 1 min
R between leads and case; 100 V; 1 min
Withstanding (DC) voltage (cut off current 10 mA)
(1)
; rise time
1000 V/s:
C
1.0 μF
C > 1.0 μF
Withstanding (AC) voltage between leads and case
Maximum application temperature
Note
(1)
See “Voltage Proof Test for Metalized Film Capacitors”:
www.vishay.com/doc?28169
ELECTRICAL DATA AND ORDERING INFORMATION
CATALOG NUMBER F1772S X2... AND PACKAGING
U
RAC
(V)
CAP.
(μF)
DIMENSIONS
wxhxl
(mm)
LOOSE IN BOX
MASS
(g)
(3)
SHORT LEADS
l
t
= 3.5 mm
± 0.3 mm
l
t
= 5.0 mm
± 1.0 mm
SPQ
LONG LEADS
l
t
= 25.0 mm
± 2.0 mm
SPQ
REEL
(1)(2)
Ø = 500 mm
H = 18.5 mm;
P
0
= 12.7 mm
31031MF0W0
31531MF0W0
32231MF0W0
33331MF0W0
34731MF0W0
36831MF0W0
41031MF0W0
41531MF0W0
42231MF0W0
43331MF0W0
31031KF0W0
31231KF0W0
31531KF0W0
31831KF0W0
32231KF0W0
32731KF0W0
33331KF0W0
33931KF0W0
34731KF0W0
35631KF0W0
36831KF0W0
38231KF0W0
41031KF0W0
41231KF0W0
41531KF0W0
41831KF0W0
42231KF0W0
42731KF0W0
43331KF0W0
SPQ
0.010
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
5.0 x 11.0 x 17.5
6.0 x 12.0 x 17.5
8.5 x 15.0 x 17.5
10.0 x 16.5 x 17.5
10.5 x 17.5 x 18.0
310
5.0 x 11.0 x 17.5
6.0 x 12.0 x 17.5
7.0 x 13.5 x 17.5
8.5 x 15.0 x 17.5
10.0 x 16.5 x 17.5
10.5 x 17.5 x 18.0
11.0 x 18.5 x 18.0
PITCH = 15 mm ± 0.4 mm; d
t
= 0.60 mm ± 0.06 mm; C-TOL. = ± 20 %
31031MFPB0
31031MFMB0
31031MFIB0
31531MFPB0
31531MFMB0
31531MFIB0
1.0
32231MFPB0
32231MFMB0
1250
32231MFIB0
1000
33331MFPB0
33331MFMB0
33331MFIB0
34731MFPB0
34731MFMB0
34731MFIB0
36831MFPB0
36831MFMB0
36831MFIB0
1.4
1000
1000
41031MFPB0
41031MFMB0
41031MFIB0
PITCH = 15 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 20 %
2.4
41531MFPB0
41531MFMB0
750
41531MFIB0
500
3.0
42231MFPB0
42231MFMB0
500
42231MFIB0
450
4.0
43331MFPB0
43331MFMB0
250
43331MFIB0
400
PITCH = 15 mm ± 0.4 mm; d
t
= 0.60 mm ± 0.06 mm; C-TOL. = ± 10 %
31031KFPB0
31031KFMB0
31031KFIB0
31231KFPB0
31231KFMB0
31231KFIB0
31531KFPB0
31531KFMB0
31531KFIB0
31831KFPB0
31831KFMB0
31831KFIB0
32231KFPB0
32231KFMB0
32231KFIB0
1.0
1250
1000
32731KFPB0
32731KFMB0
32731KFIB0
33331KFPB0
33331KFMB0
33331KFIB0
33931KFPB0
33931KFMB0
33931KFIB0
34731KFPB0
34731KFMB0
34731KFIB0
35631KFPB0
35631KFMB0
35631KFIB0
36831KFPB0
36831KFMB0
36831KFIB0
1.4
1000
1000
38231KFPB0
38231KFMB0
38231KFIB0
PITCH = 15 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 10 %
41031KFPB0
41031KFMB0
41031KFIB0
1.8
750
500
41231KFPB0
41231KFMB0
41231KFIB0
41531KFPB0
41531KFMB0
41531KFIB0
2.4
750
500
41831KFPB0
41831KFMB0
41831KFIB0
3.0
42231KFPB0
42231KFMB0
500
42231KFIB0
450
4.0
42731KFPB0
42731KFMB0
250
42731KFIB0
400
5.0
43331KFPB0
43331KFMB0
225
43331KFIB0
350
1100
900
650
600
600
1100
900
800
650
600
600
550
Revision: 26-Feb-18
Document Number: 26062
3
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772S X2
www.vishay.com
Vishay Roederstein
CATALOG NUMBER F1772S X2... AND PACKAGING
ELECTRICAL DATA AND ORDERING INFORMATION
DIMENSIONS
wxhxl
(mm)
LOOSE IN BOX
MASS
(g)
(3)
SHORT LEADS
l
t
= 3.5 mm
± 0.3 mm
l
t
= 5.0 mm
± 1.0 mm
SPQ
LONG LEADS
l
t
= 25.0 mm
± 2.0 mm
SPQ
REEL
(1)(2)
Ø = 500 mm
H = 18.5 mm;
P
0
= 12.7 mm
41531MI0W0
42231MI0W0
43331MI0W0
44131MI0W0
44731MI0W0
46831MI0W0
51031MI0W0
51531MI0W0
41031KI0W0
41231KI0W0
41531KI0W0
41831KI0W0
42231KI0W0
42731KI0W0
43331KI0W0
43931KI0W0
44131KI0W0
44731KI0W0
45631KI0W0
46831KI0W0
48231KI0W0
51031KI0W0
51231KI0W0
U
RAC
(V)
CAP.
(μF)
SPQ
0.15
0.22
0.33
0.41
0.47
0.68
1.0
1.5
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.41
0.47
0.56
0.68
0.82
1.0
1.2
0.39
0.41
0.47
0.68
1.0
1.5
2.2
0.39
0.41
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
6.0 x 15.5 x 26.0
7.0 x 16.5 x 26.0
8.5 x 18.0 x 26.0
10.0 x 19.5 x 26.0
12.0 x 22.0 x 26.0
15.5 x 26.5 x 26.5
18.0 x 29.5 x 26.5
6.0 x 15.5 x 26.0
7.0 x 16.5 x 26.0
8.5 x 18.0 x 26.0
10.0 x 19.5 x 26.0
12.0 x 22.0 x 26.0
12.5 x 22.5 x 26.5
15.5 x 26.5 x 26.5
310
9.0 x 19.0 x 31.5
11.0 x 21.0 x 31.0
15.0 x 23.0 x 31.0
18.0 x 28.0 x 31.5
21.0 x 31.0 x 31.0
9.0 x 19.0 x 31.5
11.0 x 21.0 x 31.0
15.0 x 25.0 x 31.5
18.0 x 28.0 x 31.5
21.0 x 31.0 x 31.0
PITCH = 22.5 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 20 %
2.4
41531MIPT0
41531MIMT0
300
41531MIIB0
250
2.9
42231MIPT0
42231MIMT0
200
42231MIIB0
250
43331MIPT0
43331MIMT0
43331MIIB0
3.8
200
250
44131MIPT0
44131MIMT0
44131MIIB0
6.8
44731MIPT0
44731MIMT0
200
44731MIIB0
200
7.8
46831MIPT0
46831MIMT0
150
46831MIIB0
200
9.0
51031MIPT0
51031MIMT0
110
51031MIIB0
275
10.0
51531MIPT0
51531MIMT0
90
51531MIIB0
250
PITCH = 22.5 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 10 %
41031KIPT0
41031KIPT0
41031KIB0
2.4
300
250
41231KIPT0
41231KIMT0
41231KIIB0
41531KIPT0
41531KIMT0
41531KIIB0
2.9
41831KIPT0
41831KIMT0
200
41831KIIB0
250
42231KIPT0
42231KIMT0
42231KIIB0
42731KIPT0
42731KIMT0
42731KIIB0
3.8
200
250
43331KIPT0
43331KIMT0
43331KIIB0
43931KIPT0
43931KIMT0
43931KIIB0
6.8
44131KIPT0
44131KIMT0
200
44131KIIB0
200
44731KIPT0
44731KIMT0
44731KIIB0
45631KIPT0
45631KIMT0
45631KIIB0
7.8
150
200
46831KIPT0
46831KIMT0
46831KIIB0
8.2
48231KIPT0
48231KIMT0
140
48231KIIB0
400
51031KIPT0
51031KIMT0
51031KIIB0
9.0
275
110
51231KIPT0
51231KIMT0
51231KIIB0
PITCH = 27.5 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 20 %
43931MKPT0
43931MKMT0
43931MKIB0
5.5
44131MKPT0
44131MKMT0
100
44131MKIB0
150
44731MKPT0
44731MKMT0
44731MKIB0
7.4
46831MKPT0
46831MKMT0
100
46831MKIB0
125
11.0
51031MKPT0
51031MKMT0
100
51031MKIB0
100
12.3
51531MKPT0
51531MKMT0
100
51531MKIB0
100
16.1
52231MKPT0
52231MKMT0
50
52231MKIB0
75
PITCH = 27.5 mm ± 0.4 mm; d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 10 %
43931KKPT0
43931KKMT0
43931KKIB0
5.5
44131KKPT0
44131KKMT0
100
44131KKIB0
150
44731KKPT0
44731KKMT0
44731KKIB0
45631KKPT0
45631KKMT0
45631KKIB0
7.4
46831KKPT0
46831KKMT0
100
46831KKIB0
125
48231KKPT0
48231KKMT0
48231KKIB0
11.0
51031KKPT0
51031KKMT0
100
51031KKIB0
125
51231KKPT0
51231KKMT0
51231KKIB0
12.3
100
100
51531KKPT0
51531KKMT0
51531KKIB0
51831KKPT0
51831KKMT0
51831KKIB0
16.1
50
75
52231KKPT0
52231KKMT0
52231KKIB0
600
500
450
350
300
250
200
600
500
450
350
300
300
250
-
-
-
-
Notes
• SPQ = Standard Packing Quantity
(1)
Reel diameter = 356 mm is available on request
(2)
H = in-tape height; P = sprocket hole distance; for detailed specifications refer to “Packaging Information”
0
(3)
Weight for short lead product only
Revision: 26-Feb-18
Document Number: 26062
4
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772S X2
www.vishay.com
Vishay Roederstein
VOLTAGE
310 V
AC
310 V
AC
310 V
AC
310 V
AC
VALUE
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
FILE NUMBERS
40005079
E354331
E354331
DE1-58410
LINK
www.vishay.com/doc?28225
www.vishay.com/doc?28231
www.vishay.com/doc?28226
APPROVALS
SAFETY APPROVALS X2
EN 60384-14 (ENEC)
(= IEC 60384-14 ed-4)
UL 60384-14
CSA-E384-14
CB-test certificate
The ENEC-approval together with the CB-certificate replace all national marks of the following countries (they have already signed the
ENEC-agreement): Austria; Belgium; Czech. Republic; Denmark; Finland; France; Germany; Greece; Hungary; Ireland; Italy; Luxembourg;
Netherlands; Norway; Portugal; Slovenian; Spain; Sweden, Switzerland and United Kingdom.
MOUNTING
Normal Use
The capacitor unit is designed for mounting on a printed-circuit board. The capacitors packed in bandoliers are designed for
mounting on printed-circuit boards by means of automatic insertion machines.
For detailed tape specifications refer to packaging information
www.vishay.com/docs?28139
Specific Method of Mounting to Withstand Vibration and Shock
In order to withstand vibration and shock tests, it must be ensured that the stand-off pips are in good contact with the
printed-circuit board. The capacitor shall be mechanically fixed by the leads and the body clamped.
• For pitches
15 mm the capacitors shall be mechanically fixed by the leads
• For larger pitches the capacitors shall be mounted in the same way and the body clamped
Space Requirements on Printed-Circuit Board
The maximum space for length (l
max.
), width (w
max.
) and height (h
max.
) of film capacitors to take in account on the printed circuit
board is shown in the drawings.
• For products with pitch
15 mm,
w
=
l
= 0.3 mm and
h
= 0.1 mm
• For products with 15 mm < pitch
27.5 mm,
w
=l = 0.5 mm and
h
= 0.1 mm
Eccentricity defined as in drawing. The maximum eccentricity is smaller than or equal to the lead diameter of the product
concerned.
w
max.
= w +
Δw
Eccentricity
I
max.
= I +
ΔI
CBA116
h
max.
= h +
Δh
Seating plane
Revision: 26-Feb-18
Document Number: 26062
5
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
