70HF(R) Series
STANDARD RECOVERY DIODE
V
RRM
= 100-1600V, I
F(AV)
= 70Amp.
Symbol
A
K
Cathode to Stud Shown
(Anode to Stud add Suffix R)
MAXIMUM RATINGS
Parameter
(Tj = 25 C unless stated otherwise)
70HF(R) 70HF(R)
-10
-20
70HF(R)
-40
70HF(R)
-60
70HF(R)
-80
70HF(R)
-100
70HF(R)
-120
70HF(R) 70HF(R)
-140
-160
Symbol
V
RRM
I
F
(AV)
I
FSM
I
2
T
T
(STG)
Tj
Unit
Volt
Amp
Amp
Repetitive Peak Reverse Voltage
Maximum Average On-State Current
Peak Forward Surge Current 8.3mS
Maximum I
2
T for Fusing 8.3ms
Maximum Storage Temperature Range
Maximum Junction Temperature Range
100
200
400
600
800
1000
1200
1400
1600
70 at tj = 140
O
C
1250
6450
-65 to +180
-65 to +180
70 at tj = 110
O
C
1250
6450
-65 to +150
-65 to +150
A
2
/S
O
C
C
O
ELECTRICAL CHARACTERISICS atTj = 25
O
C Maximum. Unless stated Otherwise
Parameter
Symbol
Maximum Forward Voltage
Maximum Forward Voltage
Repetitive Peak Reverse Current
Repetitive Peak Reverse Current
Repetitive Peak Reverse Current
Thermal Resistance (Junction to Case)
Mounting Torque
Weight
V
FM
V
FM
I
RRM
I
RRM
I
RRM
R
TH (J-c)
M
T
Wt
I
FM
=220 Amps (100 -1200V )
I
FM
=220 Amps (1400 -1600V )
V
R
= V
RRM,
tj= tj Max (100 -400V )
V
R
= V
RRM,
tj= tj Max (600 -1200V )
V
R
= V
RRM,
tj= tj Max (1400 -1600V )
Condition
Min
Value
Typ
Max
1.35
1.46
15
9.0
4.5
0.45
3.4
17
Unit
Volt
Volt
mA
mA
mA
O
C/W
NM
grms
Mechanical Outline
0.90
(0.03)
17.25
(0.68)
0 4.0 (0.16) Min
7.0 (0.27) max
6.1 (0.84) min
10.20 (0.401) min
11.4 (0.45) max
14.86 (0.585) Max
12.80 (0.0.503) Min
C
L
4.0 (0.16) min
25.4 (1.00) max
10.6 (0.42) min
11.4 (0.46) max
1/4" 28 UNF - 2A
Metric M6 x 1
Case: DO-203AB (DO-5)
Case: Metal/ Glass to Metal Seal
All Dimensions in Millimeters (Inches)
