P10LU-0505Z Overview

3KV ISOLATED 2W UNREGULATED DUAL OUTPUT SIP7

P10LU-0505Z Parametric

Parameter Name	Attribute value
Maker	PEAK electronics
package instruction	,
Reach Compliance Code	unknow

Preview

Download Datasheet

View All

Telefon: +49 (0) 6135 931069

Telefax: +49 (0) 6135 931070

www.peak-electronics.de

info@peak-electronics.de

M3 SERIES

P10LU-XXXXZ 3KV ISOLATED 2W UNREGULATED DUAL OUTPUT SIP7

Available Inputs:

5, 12, 24 and 48 VDC

Available Outputs:

(+/-) 5, 7.2, 12 and 15 VDC

Other specifications please enquire

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Derating

Humidity

Cooling

Physical Characteristics

Dimensions SIP

Weight

Case material

+/- 10 %

Capacitors

3000 VDC

1 mA

Ohm

60 pF typ.

+/- 5 %, max.

75 mV p-p, max.

Momentary

+/- 1,2 % / 1,0 % of Vin

+/- 8 %, load = 20 ~ 100 %

+/- 0,02 % / °C

70 % to 85 %

85 KHz, typ.

- 40° C to + 85° C

- 55 °C to + 125 °C

See graph

Up to 90 %, non condensing

Free air convection

19,50 x 6,00 x 9,50 mm

0,76 x 0,24 x 0,37 inches

2,5 g 3,5 g for 48 VDC

Non conductive black plastic

Examples of Partnumbers/Modelcode

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

P10LU-0505Z

P10LU-0512Z

P10LU-0515Z

P10LU-1205Z

P10LU-1212Z

P10LU-1215Z

P10LU-2405Z

P10LU-247R2Z

P10LU-2412Z

P10LU-2415Z

555

500

494

225

208

111

107

102

+/- 5

+/- 12

+/- 15

+/- 5

+/- 12

+/- 15

+/- 5

+/- 7,2

+/- 12

+/-15

+/- 200

+/- 84

+/- 67

+/- 200

+/- 84

+/- 67

+/- 200

+/- 139

+/- 84

+/- 67
