Variable Coils for Surface Mounting
表面贴装型可变线圈
TYPE 5CCEG
For Reflow Soldering
适合回流焊接
Frequency Range
频率范围：
20
½
120 MHz
Inductance Range
电感值范围：
0.05
½
2.7 μH
Q Approx
概略Q值：
70 (at 100MHz)
Recommended patterns
推荐焊盘尺寸
*1
6.2
0.6×1.1
5.6
R1
.8
3.4
5.7
0.9
φ3.1
+0.05
-0.1
R0.1
0.
6
3.6
max.
3°
45ﾟ ±
0.15
max.
1.2
0.15
(Unit: mm)
*2
±0.15
0.6
(Unit: mm)
Features
特 点
•
符合½½½½用的高可靠性
•
符合AEC-Q200
•
High reliability conforms to automotive applications.
•
AEC-Q200 compliant.
Applications
应
用
•
适 用于½½½音响调谐器用的射频匹配变压器
•
½用温度范围：－40 ½ ＋85°C
•
Suitable as a RF matching transformer for car tuner.
•
Operating temperature (− 40½+85°C)
SELECTION GUIDE FOR STANDARD TRANSFORMERS
TYPE 5CCEG
零件号码
Part Number
#A1313AN-0001GGH=P3
#A1313AN-0002GRG=P3
#A1313AN-0003GRG=P3
#A1313AN-0004GGH=P3
测试频率
Test Frequency
(MHz)
100
100
100
100
C可变范围
C Range
(pF)
11.4 +3/-3％
11.4 +5/-2%
11.4 +2/-4%
11.7 +3/-3%
Q
Unloaded Q
72 +/-20%
61 +/-20%
54 +/-20%
72 +/-20%
内部连接
*
Winding
Connection *
A
B
B
A
*Connection A (Bottom View)
* Connection B (Bottom View)
5CCEG type is custamized item. Please feel free to contact us for details.
5CCEG
型号是按客户规格订制生产的产品。敬请咨询详细信息。
