3 Pin XLR Comparison
Configuration
Product
Part number
Number of Conductors
IO-XLR3-XX-E*
2 plus shield
20/0.12
24 AWG
PE
Red and White
Spiraled 60/0.12
6.0mm
PVC
Black
IO-XLR3-XX-P*
2 plus shield
IO-XLR3-XX-X*
4 plus double shield
Conductors
Details
Size
Insulation
Material
Colors
Shield
Jacket
O.D.
Material
Color
Electrical and Mechanical
Characteristics
Conductor DC Resistance (ohm/m)
Shield DC Resistance (ohm/m)
Voltage Breakdown
Flex Life
Tensile Strength
Applicable Temperature
Peak Temperature
60/0.08
23 AWG
XLPE
Blue and White
Braided 16*9/0.10 TC
20/0.12
24 AWG
LDPE
2 Blue and 2 White
1 Braided TC and 1 Braided OFC
6.0mm
PVC
Black
7.6mm (8.4mm with Nylon Sleeve)
PVC with Nylon Braided Sleeve
Black
0.075 +/- 5%
0.025
300V
> 17,700
> 656.2N
-20°C ~ +60°C (-4°F ~ +140°F)
-40°C ~ +70°C (-40°F ~ +158°F)
0.062 +/- 1%
0.021 +/- 1%
300V
> 17,700
> 923N
-20°C ~ +60°C (-4°F ~ +140°F)
-40°C ~ +70°C (-40°F ~ +158°F)
0.073 +/- 1%
0.007 +/- 1%
500V
> 17,700
> 1,159N
-20°C ~ +60°C (-4°F ~ +140°F)
-40°C ~ +70°C (-40°F ~ +158°F)
