Produktdatenblatt | Version 1.1
LE B Q8WP
www.osram-os.com
LE B Q8WP
OSRAM OSTAR
®
Projection Compact
Compact light source in SMT technology, glass win-
dow on top, RoHS compliant
Applications
—
Projection Home LED & Laser
—
Projection Professional LED & Laser
—
Stage Lighting (LED & Laser)
Features:
—
Package: compact lightsource in SMT technology with glass window on top
—
Chip technology: UX:3
—
Typ. Radiation: 120° (Lambertian emitter)
—
Color:
λ
dom
= 459 nm (● blue)
—
Corrosion Robustness Class: 3B
—
ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
Ordering Information
Type
Total radiant flux
1)
I
F
= 1400 mA
Φ
e
1590 ... 2500 mW
1590 ... 2500 mW
Ordering Code
LE B Q8WP-8A7B-24
LE B Q8WP-8A7B-VW
Q65112A4116
Q65112A4115
1
Version 1.10
| 2018-09-20
LE B Q8WP
Characteristics
I
F
= 1400 mA; T
S
= 25 °C
Parameter
Peak Wavelength
Dominant Wavelength
3)
Symbol
λ
peak
λ
dom
typ.
min.
typ.
max.
typ.
typ.
typ.
typ.
min.
typ.
max.
min.
max.
typ.
max.
typ.
max.
Values
455 nm
444 nm
459 nm
465 nm
27 nm
120 °
1.5 x 1.2 mm²
0.82
2.80 V
2.95 V
3.50 V
45 V
1.2 V
2.6 K / W
3.6 K / W
1.6 K / W
2.3 K / W
Spectral bandwidth at 50% I
rel,max
Viewing angle at 50 % I
V
Radiating surface
Partial Flux acc. CIE 127:2007
4)
Φ
E/V 120°
= x * Φ
E/V 180°
Forward Voltage
5)
I
F
= 1400 mA
Reverse voltage (ESD device)
Reverse voltage
2)
I
R
= 20 mA
Real thermal resistance junction/solderpoint
6)
Electrical thermal resistance junction/solderpoint
6)
with efficiency η
e
= 37 %
∆λ
2φ
A
color
Φ
E/V, 120°
V
F
V
R ESD
V
R
R
thJS real
R
thJS elec.
3
Version 1.10
| 2018-09-20
