P8SG-1212ZH52 Overview

5.2 KV ISOLATED 1.5 W REGULATED DUAL OUTPUT DIP24

P8SG-1212ZH52 Parametric

Parameter Name	Attribute value
Maker	PEAK electronics
package instruction	,
Reach Compliance Code	unknow

Preview

Download Datasheet

View All

Telefon: +49 (0) 6135 931069

Telefax: +49 (0) 6135 931070

www.peak-electronics.de

info@peak-electronics.de

M5 SERIES

P8SG-XXXXZH52 5.2 KV ISOLATED 1.5 W REGULATED DUAL OUTPUT DIP24

Available Inputs:

5, 12 and 24 VDC

Available Outputs:

(+/-) 3.6, 5, 7.2, 12, 15 and 18 VDC

Other specifications please enquire.

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Derating

Humidity

Cooling

Physical Characteristics

Dimensions

Weight

Case material

+/- 10 %

Pi Network

5200 Vdc

1 mA

10

9

Ohm

60 pF typ.

+/- 2 %, max.

75 mV p-p, max.

Continuous , restart automatic

+/- 0,5 % max.

+/- 0,02 % / °C

65 % to 85 %

125 KHz, typ.

-25°C to +71°C

- 55 °C to + 125 °C

See graph

Up to 90 %, non condensing

Free air convection

31,75 x 20,32 x 10,16 mm

1,25 x 0,80 x 0,40 inches

12,2 g

Non conductive black plastic

Examples of Partnumbers/Modelcode

PART

NO.

INPUT

VOLTAGE

(VDC)

Nominal

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

P8SG-053R6ZH52

P8SG-0505ZH52

P8SG-1205ZH52

P8SG-1212ZH52

P8SG-2405ZH52

P8SG-247R2ZH52

P8SG-2415ZH52

5

12

24

78

75

70

67

32

29

26

443

454

184

181

96

91

+/- 3,6

+/- 5

+/- 12

+/- 5

+/- 7.2

+/- 15

+/- 200

+/- 150

+/- 63

+/- 150

+/- 100

+/- 50

65

66

68

69

65

66

69
