SR
www.vishay.com
Vishay Dale
Wirewound Resistors, Open Air, Current Sense, Low Value
FEATURES
• Open air design
• Low resistance values for all types of current
Available
sensing,
voltage
division
and
pulse
applications including switching and linear
supplies, instrumentation and power amplifiers
• All welded construction
Available
• Solid metal nickel-chrome or copper-nickel
alloy resistive element
Available
• Solderable terminations
• Very low inductance
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are RoHS-compliant and / or parts that are non RoHS-compliant. For example, parts
with lead (Pb) terminations are not RoHS-compliant. Please see the information / tables in this datasheet for details
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
SR3
SR5
POWER RATING
P
70 °C
W
3.0
5.0
RESISTANCE RANGE
0.0025 to 0.10
0.0025 to 0.05
TOLERANCE
±%
1, 2, 3, 5, 10
1, 2, 3, 5, 10
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
+25°C / -55°C;
+25°C / +125°C
Operating Temperature Range
Maximum Continuous Current
UNIT
SR RESISTOR CHARACTERISTICS
± 400 = 0.0025
to 0.0199
;
± 300 = 0.02
to 0.049
;
± 250 = 0.05
to 0.99
;
± 200 = 0.1
and above
-65 to +275
(P/R)
1/2
ppm/°C
°C
A
GLOBAL PART NUMBER INFORMATION
Global Part Numbering example: SR55L000JE66
S
R
5
5
L
0
0
0
J
E
6
6
GLOBAL MODEL
SR3
SR5
VALUE
L
= m
(below 0.01
)
R
= decimal
5L000
= 0.005
R0100
= 0.01
TOLERANCE
F
= ± 1.0 %
G
= ± 2.0 %
H
= ± 3.0 %
J
= ± 5.0 %
K
= ± 10 %
PACKAGING
E66
= lead (Pb)-free bulk
SPECIAL
(dash number)
(up to 3 digits)
from
1 to 999
as
applicable
Revision: 20-Sep-2018
Document Number: 31067
1
For technical questions, contact:
ww2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SR
www.vishay.com
DIMENSIONS
in inches [millimeters]
Vishay Dale
B
C
A
E
F
MODEL
SR3
DIMENSIONS
in inches [millimeters]
A
0.600 + 0.040/- 0.020
[15.24 + 1.020/- 0.508]
0.800 + 0.040/- 0.020
[20.32 + 1.020/- 0.508]
B
C
E
F
1.0 maximum
[25.4 maximum]
0.125 ± 0.030
[3.18 ± 0.762]
0.065 + 0.010/- 0.005
[1.65 + 0.254/- 0.127]
0.040 ± 0.002
[1.02 ± 0.051]
SR5
MATERIAL SPECIFICATIONS
Element:
nickel-chrome or copper-nickel alloy depending
on resistance value
Terminals:
tinned copper
Encapsulation:
none
Marking:
none
DERATING
RATED POWER IN %
120
100
80
60
40
20
0
- 65
- 25
25
125
175
225
275
75
70
AMBIENT TEMPERATURE IN °C
PERFORMANCE
TEST
Temperature Cycling
Low Temperature Storage
Mechanical Shock
Vibration
Load Life
Resistance to Solder Heat
Short Time Overload
Damp Heat
CONDITIONS OF TEST
-55 °C to +125 °C, 5 cycles, 15 min at each extreme
-65 °C for 24 h
100
g’s
for 11 ms, 5 pulses
Frequency varied 10 Hz to 2000 Hz in 1 min, 3 directions, 12 h
1000 h at rated power, +70 °C, 1.5 h “ON”, 0.5 h “OFF”
+260 °C solder, 10 s to 12 s dwell
5x rated power for 5 s
103B of MIL 202F and test condition “D”,
humidity chamber per 1300 h
TEST LIMITS
± (2.0 % + 0.0005
) R
± (0.5 % + 0.0005
) R
± (0.2 % + 0.0005
) R
± (0.2 % + 0.0005
) R
± (2.75 % + 0.0005
) R
± (0.2 % + 0.0005
) R
± (1.25 % + 0.0005
) R
± (0.5 % + 0.0005
) R
no mechanical damage
Revision: 20-Sep-2018
Document Number: 31067
2
For technical questions, contact:
ww2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
