2. The LED indication color is green for the DC coil and red for the AC coil.
–1–
ASCTB6E 201709-T
HJ
TYPES
1. Au plating type
1) Plug-in type
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-DC 12V-6
HJ2-DC 24V-6
HJ2-DC 48V-6
HJ2-DC110V-6
HJ2-AC 12V-6
HJ2-AC 24V-6
HJ2-AC 48V-6
HJ2-AC100V-6
HJ2-AC120V-6
HJ2-AC200V-6
HJ2-AC220/240V-6
4 Form C
Part No.
HJ4-DC 12V-6
HJ4-DC 24V-6
HJ4-DC 48V-6
HJ4-DC110V-6
HJ4-AC 12V-6
HJ4-AC 24V-6
HJ4-AC 48V-6
HJ4-AC100V-6
HJ4-AC120V-6
HJ4-AC200V-6
HJ4-AC220/240V-6
To Be Discontinued
Last time buy: September 30, 2018
2) Plug-in type (with LED indication)
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-L-DC 12V-6
HJ2-L-DC 24V-6
HJ2-L-DC 48V-6
HJ2-L-DC110V-6
HJ2-L-AC 12V-6
HJ2-L-AC 24V-6
HJ2-L-AC 48V-6
HJ2-L-AC100V-6
HJ2-L-AC120V-6
HJ2-L-AC200V-6
HJ2-L-AC220/240V-6
4 Form C
Part No.
HJ4-L-DC 12V-6
HJ4-L-DC 24V-6
HJ4-L-DC 48V-6
HJ4-L-DC110V-6
HJ4-L-AC 12V-6
HJ4-L-AC 24V-6
HJ4-L-AC 48V-6
HJ4-L-AC100V-6
HJ4-L-AC120V-6
HJ4-L-AC200V-6
HJ4-L-AC220/240V-6
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
3) Plug-in type (with diode)
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
2 Form C
Part No.
HJ2-DC 12V-D-6
HJ2-DC 24V-D-6
HJ2-DC 48V-D-6
HJ2-DC110V-D-6
4 Form C
Part No.
HJ4-DC 12V-D-6
HJ4-DC 24V-D-6
HJ4-DC 48V-D-6
HJ4-DC110V-D-6
4) Plug-in type (with diode and LED indication)
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
2 Form C
Part No.
HJ2-L-DC 12V-D-6
HJ2-L-DC 24V-D-6
HJ2-L-DC 48V-D-6
HJ2-L-DC110V-D-6
4 Form C
Part No.
HJ4-L-DC 12V-D-6
HJ4-L-DC 24V-D-6
HJ4-L-DC 48V-D-6
HJ4-L-DC110V-D-6
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
5) Plug-in type (with CR)
Nominal coil
voltage
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-AC100V-R-6
HJ2-AC120V-R-6
HJ2-AC200V-R-6
HJ2-AC220/240V-R-6
4 Form C
Part No.
HJ4-AC100V-R-6
HJ4-AC120V-R-6
HJ4-AC200V-R-6
HJ4-AC220/240V-R-6
6) Plug-in type (with CR and LED indication)
Nominal coil
voltage
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-L-AC100V-R-6
HJ2-L-AC120V-R-6
HJ2-L-AC200V-R-6
HJ2-L-AC220/240V-R-6
4 Form C
Part No.
HJ4-L-AC100V-R-6
HJ4-L-AC120V-R-6
HJ4-L-AC200V-R-6
HJ4-L-AC220/240V-R-6
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
2. Without Au plating type
1) Plug-in type
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-DC 12V
HJ2-DC 24V
HJ2-DC 48V
HJ2-DC110V
HJ2-AC 12V
HJ2-AC 24V
HJ2-AC 48V
HJ2-AC100V
HJ2-AC120V
HJ2-AC200V
HJ2-AC220/240V
4 Form C
Part No.
HJ4-DC 12V
HJ4-DC 24V
HJ4-DC 48V
HJ4-DC110V
HJ4-AC 12V
HJ4-AC 24V
HJ4-AC 48V
HJ4-AC100V
HJ4-AC120V
HJ4-AC200V
HJ4-AC220/240V
2) Plug-in type (with LED indication)
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-L-DC 12V
HJ2-L-DC 24V
HJ2-L-DC 48V
HJ2-L-DC110V
HJ2-L-AC 12V
HJ2-L-AC 24V
HJ2-L-AC 48V
HJ2-L-AC100V
HJ2-L-AC120V
HJ2-L-AC200V
HJ2-L-AC220/240V
4 Form C
Part No.
HJ4-L-DC 12V
HJ4-L-DC 24V
HJ4-L-DC 48V
HJ4-L-DC110V
HJ4-L-AC 12V
HJ4-L-AC 24V
HJ4-L-AC 48V
HJ4-L-AC100V
HJ4-L-AC120V
HJ4-L-AC200V
HJ4-L-AC220/240V
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
3) Plug-in type (with a test button)
Nominal coil
voltage
12V DC
24V DC
100/110V AC
200/220V AC
2 Form C
Part No.
HJ2-T-DC 12V
HJ2-T-DC 24V
HJ2-T-AC100V
HJ2-T-AC200V
4 Form C
Part No.
HJ4-T-DC 12V
HJ4-T-DC 24V
HJ4-T-AC100V
HJ4-T-AC200V
4) Plug-in type (with LED indication and a test button)
Nominal coil
voltage
12V DC
24V DC
100/110V AC
200/220V AC
2 Form C
Part No.
HJ2-L-T-DC 12V
HJ2-L-T-DC 24V
HJ2-L-T-AC100V
HJ2-L-T-AC200V
4 Form C
Part No.
HJ4-L-T-DC 12V
HJ4-L-T-DC 24V
HJ4-L-T-AC100V
HJ4-L-T-AC200V
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
–2–
ASCTB6E 201709-T
To Be Discontinued
Last time buy: September 30, 2018
HJ
6) Plug-in type (with diode and LED indication)
4 Form C
Part No.
HJ4-DC 12V-D
HJ4-DC 24V-D
HJ4-DC 48V-D
HJ4-DC110V-D
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
2 Form C
Part No.
HJ2-L-DC 12V-D
HJ2-L-DC 24V-D
HJ2-L-DC 48V-D
HJ2-L-DC110V-D
4 Form C
Part No.
HJ4-L-DC 12V-D
HJ4-L-DC 24V-D
HJ4-L-DC 48V-D
HJ4-L-DC110V-D
5) Plug-in type (with diode)
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
2 Form C
Part No.
HJ2-DC 12V-D
HJ2-DC 24V-D
HJ2-DC 48V-D
HJ2-DC110V-D
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
7) Plug-in type (with CR)
Nominal coil
voltage
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-AC100V-R
HJ2-AC120V-R
HJ2-AC200V-R
HJ2-AC220/240V-R
4 Form C
Part No.
HJ4-AC100V-R
HJ4-AC120V-R
HJ4-AC200V-R
HJ4-AC220/240V-R
8) Plug-in type (with CR and LED indication)
Nominal coil
voltage
100/110V AC
110/120V AC
200/220V AC
220/240V AC
2 Form C
Part No.
HJ2-L-AC100V-R
HJ2-L-AC120V-R
HJ2-L-AC200V-R
HJ2-L-AC220/240V-R
4 Form C
Part No.
HJ4-L-AC100V-R
HJ4-L-AC120V-R
HJ4-L-AC200V-R
HJ4-L-AC220/240V-R
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
RATING
1. Coil data
1) AC coils (50/60Hz)
Nominal coil
voltage
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
220/240V AC
80%V or less of
nominal voltage
(Initial)
30%V or more of
nominal voltage
(Initial)
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal coil current [±20%]
50Hz
102.9mA
54.5mA
30.7mA
11.8mA/13.9mA
10.9mA/12.5mA
6.8mA/8.1mA
6.8mA/7.8mA
60Hz
85.4mA
45.6mA
25.9mA
10.0mA/11.6mA
9.1mA/10.3mA
5.7mA/6.7mA
5.6mA/6.4mA
Nominal operating power
50Hz
60Hz
Max. applied voltage
(at 70°C
158°F)
Approx. 1.2 to
1.5 V A
Approx. 1.0 to
1.3 V A
110%V of
nominal voltage
2) DC coils
Nominal coil
voltage
12V DC
24V DC
48V DC
100/110V DC
Pick-up voltage
(at 20°C
68°F)
80%V or less of
nominal voltage
(Initial)
Drop-out voltage
(at 20°C
68°F)
10%V or more of
nominal voltage
(Initial)
Nominal coil current
75mA [±10%]
37mA [±10%]
18mA [±15%]
9.1mA/10mA [±15%]
Coil resistance
(at 20°C
68°F)
160Ω
650Ω
2,600Ω
11,000Ω
Nominal operating
power
0.9W
1.1W
Max. applied voltage
(at 70°C
158°F)
110%V of
nominal voltage
–3–
ASCTB6E 201709-T
HJ
2. Specifications
Characteristics
Contact
Item
Arrangement
Contact resistance (Initial)
Contact material
Nominal switching capacity (resistive load)
Max. switching power (resistive load)
Max. switching voltage
Max. switching current*
4
Nominal operating power
Min. switching capacity Au plating type
(Reference value)*
1
Without Au plating type
Insulation resistance (Initial)
Between open contacts
Between contact sets
Between contact and coil
Temperature rise (coil) (at 70°C
158°F)
Breakdown voltage
(Initial)
Operate time*
2
Release time*
2
Shock resistance
Vibration resistance
Mechanical
Expected life
Electrical (resistive load) (at 20 times/min.)
Conditions for operation, transport and storage*
3
(Not freezing and condensing at low temperature)
Max. Operating speed
Unit weight
Functional
Destructive
Functional
Destructive
To Be Discontinued
Last time buy: September 30, 2018
Rating
Specifications
2 Form C
4 Form C
Max. 50 mΩ (By voltage drop 6 V DC 1A)
Au plating type: Au plating Ag Without Au plating type: Ag
7 A 250V AC, 7 A 30V DC
5 A 250V AC, 5 A 30V DC
1,750 VA
1,250 VA
250V AC, 125V DC
7A
5A
0.9W 1.2 VA
1mA 1V DC
1mA 5V DC
Min. 100MΩ (at 500V DC) Measurement at same location as “Breakdown voltage” section.
1,000 Vrms for 1min. (Detection current: 10mA.)
2,000 Vrms for 1min. (Detection current: 10mA.)
2,000 Vrms for 1min. (Detection current: 10mA.)
Max. 60°C
140°F
(By resistive method, nominal coil voltage)
Max. 20ms (Nominal coil voltage applied to the coil, excluding contact bounce time.)
Max. 20ms (Nominal coil voltage applied to the coil, excluding contact bounce time.)
(without diode)
Min. 100 m/s
2
(Half-wave pulse of sine wave: 11 ms; detection time: 10μs.)
Min. 1,000 m/s
2
(Half-wave pulse of sine wave: 6 ms.)
10 to 55 Hz at double amplitude of 1.0 mm (Detection time: 10μs.)
10 to 55 Hz at double amplitude of 1.0 mm
Min. 2×10
7
(at 180 times/min.)
Min. 10
5
(5A 250V AC)
Min. 10
5
(7A 250V AC)
5
(5A 250V AC)
Min. 5×10
Min. 2×10
5
(3A 250V AC)
5
(7A 30V DC)
Min. 10
Min. 10
5
(5A 30V DC)
Ambient temperature: –40°C to +70°C
–40°F to +158°F
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
20 times/min. (at nominal switching capacity)
Approx. 34g
1.20 oz
Electrical
characteristics
Mechanical
characteristics
Conditions
Notes: In accordance with the Electrical Appliance and Material Safety Law, you cannot exceed a voltage of 150V AC when using the 4 Form C type.
For more information, please inquire.
When using low level loads, contact instability may result depending on conditions of use (switching frequency and ambient conditions, etc.); therefore, please use
the Au plating type.
*1. This value can change due to the switching frequency, environmental conditions and desired reliability level, therefore it is recommended to check this with the
actual load.
*2. For the AC coil types, the operate/release time will differ depending on the phase.
*3. The upper limit of the ambient temperature is the maximum temperature that can satisfy the coil temperature rise value. Refer to Usage, transport and storage
conditions in NOTES.
*4. When using the socket and terminal socket, be sure to verify the max. continuous current.
Download osxMotionFXhttp://www.st.com/content/st_com/en/products/embedded-software/mems-and-sensors-software/open-mems/osxmotionfx.htmlFind en.osxMotionFX_Software.zip, unzip and installAfter the inst...
I just started learning ARM. The manual says that the registers are all R15, R**, but I see that the code uses C0, C. Why is this? Is there a corresponding relationship? Thank you....
[i=s]This post was last edited by ddllxxrr on 2020-1-6 20:48[/i]2019 was a busy year for me. The nature of my company meant I was busy. I think 2020 will be the same. Otherwise, I will quit the compan...
There is very little information about RTL8309. I found some information on the Internet about operating registers through the SMI interface protocol. Can I communicate through I2C between the main ch...
Today I saw two videos online. They were amazing, but I felt that the principle didn't work. I copied the video and used an ammeter or a voltmeter but couldn't measure any data. There was no response ...
Bus Hound 5.00 capture. Complements of www.perisoft.netDevice - Device ID (followed by the endpoint for USB devices)(34) USB Composite Device(35) PHILOG USB Serial CDC Trace (COM2)(36) PHILOG USB Seri...
Ever since the Tesla fire incident, electric cars, already known for their poor reputation, have been subjected to even more scathing criticism. Despite this, many people are still willing to buy t...[Details]
introduction
Sonar imaging is of great significance in marine resource development and defense. Its long range, intuitive display of the observed area, and target identification make it widely...[Details]
As AI accelerates across industries, the demand for data center infrastructure is also growing rapidly.
Keysight Technologies, in collaboration with Heavy Reading, released the "Beyo...[Details]
One of the most core components of electric vehicles is the motor. The power supply provides electrical energy to the motor, which converts this electrical energy into mechanical energy, which in t...[Details]
"We have successfully launched the first version of our dedicated chip for EMB brake-by-wire. Second-generation samples have also been successfully completed, and we are actively planning a third-g...[Details]
China, August 21, 2025 – STMicroelectronics (NYSE: STM), a world-leading semiconductor company serving a wide range of electronics applications, has published its IFRS 2025 semi-annual financial re...[Details]
A tubular motor is an electric motor that is typically used to control the movement of machines and equipment. Tubular motors are generally divided into two categories: linear tubular motors and ro...[Details]
A pure sine wave inverter has a good output waveform with very low distortion, and its output waveform is essentially the same as the AC waveform of the mains power grid. In fact, the AC power prov...[Details]
A scale, a large, ground-mounted scale, is typically used to measure the tonnage of truck cargo. It's the primary weighing device used in factories, mines, and businesses for bulk cargo measurement...[Details]
Renesas Electronics' new ultra-low-power RA4C1 MCU features advanced security and a dedicated peripheral set, making it ideal for metering and other applications.
The new product mee...[Details]
introduction
The rapid adoption of computers has led to a growing number of tasks being performed on them. People from all walks of life, especially programmers and writers, are spending incre...[Details]
Facial recognition, a biometric technology that uses facial features to authenticate identity, has rapidly become a global market hotspot in recent years as the technology has entered practical use...[Details]
introduction
The OMAP-L138 dual-core processor is a new generation of low-power single-chip systems (SoCs) from TI. It is widely used in communications, industrial, medical diagnostic, and aud...[Details]
The Waveshare ESP32-P4-ETH is a compact ESP32-P4 development board with Ethernet and PoE support. It looks very similar to the Olimex ESP32-P4-DevKit, minus the pUEXT connector. However, we've also...[Details]
In microwave amplification circuits, the power chip is the core of the entire circuit. A large number of semiconductor devices in the chip will generate a lot of heat when working. If the heat diss...[Details]
MEMS sensors
京公网安备 11010802033920号
EEWORLD
