Technical Data Sheet - DRAFT
N 50
Surge Arrester
Jack – Jack (Fine protection)
53EK565-K220N1
Dieses Dokument ist urheberrechtlich geschützt
●
This document is protected by copyright
●
Rosenberger Hochfrequenztechnik GmbH & Co. KG
All dimensions are in mm; tolerances according to ISO 2768 m-H
Interface
According to
IEC 60169-16, MIL-PRF-39012, CECC 22210
B 13
Documents
Panel piercing
Material and plating
Connector parts
Center contact
Outer contact
Body
Dielectric
Gasket
Gasket
Material
Spring bronze
Brass
Brass
PTFE
Silicone
NBR
Plating
Silver, 3-6 µm
Flash white bronze over silver(e.g. Optargen®)
Flash white bronze over silver(e.g. Optargen®)
RF_35/05.10/6.0
Rosenberger Hochfrequenztechnik GmbH & Co. KG
P.O.Box 1260
D-84526 Tittmoning
Germany
www.rosenberger.de
Tel. : +49 8684 18-0
Fax : +49 8684 18-499
Email : info@rosenberger.de
Page
1/2
Technical Data Sheet - DRAFT
N 50
Surge Arrester
Jack – Jack (Fine protection)
53EK565-K220N1
50
698 to 2500 MHz
21 dB, 698 to 800 MHz
26 dB, 800 to 960 MHz
24 dB, 960 to 1700 MHz
26 dB, 1700 to 2200 MHz
24 dB, 2200 to 2500 MHz
21 dB, 2500 to 2700 MHz
0.1 dB
5 m
5 m
30 W (at 20 °C, sea level, VSWR 1.0)
128 dB up to 1 GHz
-117 dBm @ 2 x 20 W
2A
+ 15 V, nom.
40 V @ 4 kV 1.2/50 µs, 2 kA 8/20 µs
min. 500
450 N
28 N
3 Ncm
0.7 to 1.1 Nm
max. 1.7 Nm
-45°C to +85°C
MIL-STD-202, Meth. 107, Cond. B
MIL-STD-202, Meth. 101, Cond. B
MIL-STD-202, Meth. 204, Cond. B
MIL-STD-202, Meth. 213, Cond. I
MIL-STD-202, Meth. 106
IEC 60529, IP68 2.5 bar (mated condition)
compliant
231 g/pce
Electrical data
Impedance
Operating frequency
Return Loss
Dieses Dokument ist urheberrechtlich geschützt
●
This document is protected by copyright
●
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Insertion loss
Center contact resistance
Outer contact resistance
Power handling
RF-leakage
Intermodulation (3rd order)
DC current
DC voltage
Resuidual voltage
Mechanical data
Mating cycles
Coupling nut retention
Center contact captivation: axial
radial
Coupling torque (recommended)
Proof torque
Environmental data
Temperature range
Thermal shock
Corrosion
Vibration
Shock
Moisture resistance
Degree of protection
RoHS
Weight
Weight
