5310F Series T-1 LED Circuit Board Indicator
DESCRIPTION AND FEATURES
Features
• Block mounting, height and spacing alignment saves
assembly cost and time.
• Standoffs prevent flux entrapment.
• Press-in mounting pin secures assembly to PC board
while soldering.
Housing: Black Nylon, UL94V-O
.020 S T AND-OF F
F OR P OS T
C LE ANING
.115±.015
DIM "A"
±.
020
.020 S Q.
TYP.
.150 MIN.
Alternate LEDs are available in this package as
standard variations.
Mounting hole pattern on page 1-X6.
P ANE L
ANODE (+)
ÿ. 200
ANODE (+)
All dimens ions in inches .
ELECTRO-OPTICAL CHARACTERISTICS AND RATINGS
Typ.
Intensity
(mcd)
10
7
16
6.3
10
7
6.3
10
7
6.3
Part
Number
5310F1
5310F3
5310F5
5310F7
5312F1
5312F5
5312F7
5315F1
5315F5
5315F7
Color
Red
Amber
Green
Yellow
Red
Green
Yellow
Red
Green
Yellow
Rated
Current
(mA)
10
10
10
10
10
10
10
10
10
10
Continuous
Reverse
Forward
Forward
Forward
Break-down
Current Max.
Voltage Typ. Voltage Max.
Voltage Min.
(V)
(V)
(mA)
(V)
30
2.0
5
3.0
30
30
30
30
30
30
30
30
30
2.2
2.2
2.1
2.0
2.2
2.1
2.0
2.2
2.1
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
5
5
5
5
5
5
5
5
5
Peak
Wavelength
(nm)
650
603
562
585
650
562
585
650
562
585
DIM A
(inches)
.580
.580
.580
.580
.810
.810
.810
.550
.550
.550
America:
CML Innovative Technologies,Inc.
147 Central Avenue
Hackensack -NJ 07601 -USA
Tel:1-201-489 -8989
Fax:1-201-489 -6911
e-mail:americas@cml-it.com
Europe:
CML Technologies GmbH &Co.KG
Robert-Bunsen-Str.1
67098 Bad Dürkheim -GERMANY
Tel:+49 (0)6322 9567-0
Fax:+49 (0)6322 9567-88
e-mail:europe@cml-it.com
Asia:
CML Innovative Technologies,Inc.
61 Aida Street
Singapore 459975
Tel:(65)9630 -5003
e-mail:asia@cml-it.com
CML-IT reserves the right to make specification revisions that enhance the design and/or performance of the product
