Data Sheet
1.0 Amp ULTRA-FAST
SWITCHING MEGARECTIFIERS
Mechanical Dimensions
JEDEC
D0-41
.080
.107
.205
.160
1.00 Min.
GUF10A . . . 10M Series
Description
.031 typ.
Features
n
HIGH TEMPERATURE METALLURGI-
CALLY BONDED CONSTRUCTION
n
SINTERED GLASS CAVITY-FREE
JUNCTION
n
1.0 AMP OPERATION @ T
A
= 55°C, WITH
NO THERMAL RUNAWAY
n
TYPICAL I
R
< 0.2
µAmp
Electrical Characteristics @ 25
o
C.
Maximum Ratings
Peak Repetitive Reverse Voltage...V
RRM
RMS Reverse Voltage...V
R(rms)
DC Blocking Voltage...V
DC
Average Forward Rectified Current...I
F(av)
Current 3/8" Lead Length @ T
A
= 55°C
Non-Repetitive Peak Forward Surge Current...I
FSM
8.3mS, ½ Sine Wave Superimposed on Rated Load
Forward Voltage @ Rated Forward Current
and 25°C...V
F
Full Load Reverse Current...I
R
(av)
Full Cycle Average @ T
A
= 55°C
DC Reverse Current...I
R
@ Rated DC Blocking Voltage
T
A
= 25°C
T
A
= 125°C
GUF10A . . . 10M Series
GUF
GUF
GUF
GUF
GUF
10A
10B
10D
10F
10G
50
35
50
100
70
100
200
140
200
300
210
300
400
280
400
Units
GUF
10J
600
420
600
GUF
10K
800
560
800
GUF
10M
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
............................................. 1.0 ...............................................
............................................. 3 0 ...............................................
< ............. 1.1 .......... > < ...... 1.4 ..... > < .......... 1.7 ......... >
............................................. 5 0 ...............................................
µAmps
............................................. 1 0 ...............................................
............................................. 5 0 ...............................................
< ......................... 1 7 ........................ > < .......... 1 5 .......... >
< ......................... 5 0 ........................ > < .......... 6 0 .......... >
< ......................... 5 0 ........................ > < .......... 7 5 .......... >
......................................... -65 to 175 ..........................................
µAmps
µAmps
pF
°C
/ W
nS
°C
Typical Junction Capacitance...C
J
(Note 1)
Typical Thermal Resistance...R
θJC
(Note 2)
Typical Reverse Recovery Time...t
RR
(Note 3)
Operating & Storage Temperature Range...T
J
, T
STRG
Page 6-30
Data Sheet
1.0 Amp ULTRA-FAST
SWITCHING MEGARECTIFIERS
Forward Current Derating Curve
RESISTIVE OR
INDUCTIVE LOAD
0.375″ (9.5mm) LEAD LENGTH
″
T
A
= Ambient Temperature (°C)
°
Non-Repetitive
Peak Forward Surge Current
T
J
= T
J
max.
8.3 mS Single Half Sine Wave
(Jedec Method)
Typical Junction Capacitance
T
J
= 25°C
°
f = 1.0 MHZ
V
SIG
= 50mVp-p
Amps
pF
Number of Cycles @ 60 HZ
Typical Instantaneous Forward Characteristics
Reverse Voltage (Volts)
Typical Reverse Characteristics
µ
Amps
T
J
= 25°C
°
Pulse Width = 300µS
µ
1% Duty Cycle
Ratings at
25 Deg. C ambient
temperature
unless otherwise
specified.
Single Phase Half
Wave, 60 HZ
Resistive or
Inductive Load.
Amps
Volts
Percent of Rated Peak Voltage
NOTES:
1. Measured @ 1 MHZ and applied reverse voltage of 4.0V.
2. Thermal Resistance from Junction to Ambient at 3/8" Lead Length, P.C. Board Mounted.
3. Reverse Recovery Condition I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A.
For Capacitive
Load, Derate
Current by 20%.
Page 6-31
GUF10A . . . 10M Series
Amps
